Aruba 570 Series Outdoor Access Points
Installation Guide
Rev 03 | May 2023 1
The Aruba 570 Series outdoor wireless access points (AP-574, AP-575 and AP-577) are high-performance, multi-
radio wireless devices that can be deployed in either controller-based (ArubaOS) or controllerless (Aruba Instant)
network environment.
The Aruba 570 Series access points support IEEE 802.11ax standard, delivering high performance with the MU-
MIMO (Multi-User Multiple-Input, Multiple-Output) technology, while also supporting 802.11a/b/g/n/ac wireless
services.
Package Contents
570 Series access point
Cable gland x 2
USB Type-C console cable x 1
Grounding lug and M4x6 screw x 1
Tools Required
Phillips screwdriver (#2 for M4x6 screw)
Flat blade screwdriver (Ethernet cable gland covers)
8mm allen or hex key (USB console cover)
The weatherproof caps for Ethernet and Console interfaces are connected to the access point, not loose in the
package.
Mounting kits for use with the 570 Series access points are sold separately. Contact your Aruba sales
representative for details.
Inform your supplier if there are any incorrect, missing, or damaged parts. If possible, retain the carton,
including the original packing materials. Use these materials to repack and return the unit to the supplier if
needed.
2Aruba 570 Series Outdoor Access Points | Installation Guide
Hardware Overview
Figure 1 AP-574 Front View (with Aesthetic Cover)
Figure 2 AP-574 Rear View (with Aesthetic Cover)
The antenna connectors of AP-574 are covered by an aesthetic cover. The aesthetic cover can be removed
when necessary.
USB Console Port
& Reset Button
System LED
E1Grounding Point E0
Aruba 570 Series Outdoor Access Points | Installation Guide 3
Figure 3 AP-575 Front View
Figure 4 AP-575 Rear View
USB Console Port
& Reset Button
E1
Grounding Point
E0
System LED
