Instrukcja obsługi Heatmiser PRTHW-N

Heatmiser Termostaty PRTHW-N

Przeczytaj poniżej 📖 instrukcję obsługi w języku polskim dla Heatmiser PRTHW-N (17 stron) w kategorii Termostaty. Ta instrukcja była pomocna dla 22 osób i została oceniona przez 11.5 użytkowników na średnio 4.8 gwiazdek

Pobierz PDF

Strona 1/17

1Model: PRTHW / PRTHW-N

Model: PRTHW / PRTHW-N

2 Slimline Series 2

Model: PRTHW / PRTHW-N

Table of Contents

3-4

5-6

7-8

11-12

Product Image

Table of Contents

What is a Programmable

Room Thermostat?

Installation Procedure

LCD Display

Setting the Clock

Temperature Display

Setting the Comfort Levels

Locking the Thermostat

Setting the Temperature

Model: PRTHW / PRTHW-N

Slimline Series1

Temperature Hold

Holiday Programming

Frost Protection

Power On / O

Setting the Hot Water

Switching Times

Hot Water Override

Optional Features

Re-calibrating the Thermostat

Factory Reset

Wiring Diagram

21-24

27-29

43 Slimline Series Model: PRTHW / PRTHW-N

The best way to do this is to set the room thermostat to a low temperature

– say 18°C , and then turn it up by 1°C each day until you are comfortable with the

temperature. You won’t have to adjust the thermostat further. Any adjustment above

this setting will waste energy and cost you more money.

If your heating system is a boiler with radiators, there will usually be only one

programmable room thermostat to control the whole house. But you can have

dierent temperatures in individual rooms by installing thermostatic radiator valves

(TRVs) on individual radiators.

If you don’t have TRVs, you should choose a temperature that is reasonable for the

whole house. If you do have TRVs, you can choose a slightly higher setting to make

sure that even the coldest room is comfortable, then prevent any overheating in other

rooms by adjusting the TRVs.

You are able to temporarily adjust the heating program by overriding or using the

temperature hold feature. These features are explained further on pages 14 and 15 of

this manual.

Programmable room thermostats need a free ow of air to sense the temperature,

so they must not be covered by curtains or blocked by furniture. Nearby electric

res, televisions, wall or table lamps may also prevent the thermostat from working

properly.

What is a Programmable Room Thermostat?

A programmable room thermostat is both a programmer and a room thermostat.

The programmer allows you to set “On” and “O” periods to suit your own lifestyle.

The room thermostat works by sensing the air temperature, switching on the heating

when the air temperature falls below the thermostat setting, and switching it o once

this set temperature has been reached.

So a programmable room thermostat lets you choose what times you want the heating

to be on, and what temperature it should reach while it is on. It will allow you to select

dierent temperatures in your home at dierent times of the day (and days of the week)

to meet your particular needs and preferences.

Setting a programmable room thermostat to a higher temperature will not make the

room heat up any faster. How quickly the room heats up depends on the design & size

of the heating system.

Similarly reducing the temperature setting does not aect how quickly the room cools

down. Setting a programmable room thermostat to a lower temperature will result in the

room being controlled at a lower temperature, and saves energy.

The way to set and use your programmable room thermostat is to nd the lowest

temperature settings that you are comfortable with at the dierent times you have

chosen, and then leave it alone to do its job.

Specyfikacje produktu

Marka:	Heatmiser
Kategoria:	Termostaty
Model:	PRTHW-N
Kolor produktu:	Black,White
Wysokość produktu:	265 mm
Szerokość produktu:	175 mm
Głębokość produktu:	191 mm
Waga produktu:	4100 g
Impedancja:	6 Ω
Moc wyjściowa (RMS):	100 W
Kanały wyjścia audio:	1.0 kan.
Zasięg częstotliwości:	65 - 24000 Hz
Rozmieszczenie głośników:	Plansza/półka
Ilość przetworników:	2
Głośnik wysokotonowy:	Tak
Głośnik niskotonowy:	Tak
Czułość:	86 dB
Moc szczytowa (PMPO):	150 W
Typ głośnika:	2-drożny
Liczba głośników wysokotonowych:	1
Liczba głośników niskotonowych:	1
Średnica głośnika wysokotonowego:	1 "
Średnica głośnika niskotonowego (imperial):	4 "
Średnica głośnika niskotonowego:	101.6 mm
