Strona 1/16
www.waterco.com
WARNING
!
MICRON HORIZONTAL
COMMERCIAL FILTER
Notice to Installer
This manual contains important information about the installation, operation
and safe use of this product. Once the product has been installed this manual
must be given to the owner/operator of this equipment.
This equipment must be installed and serviced by a qualified technician.
Improper installation may result in property damage, serious injury or death.
Improper installation and/or operation will void the warranty.
Technical
Manual
Table of
DESCRIPTION ------------------------------------------------ 01
CONSTRUCTION -------------------------------------------- 01
Basic Principles of Operation ---------------------------- 02
FILTER INSTALLATION -------------------------------------- 04
Positioning Filter ------------------------------------------ 04
Pipe Run --------------------------------------------------- 04
Isolation Valve --------------------------------------------- 04
Exposure --------------------------------------------------- 04
Adding the Media ----------------------------------------- 05
Filter Lid Installation -------------------------------------- 06
Multiport Valve Operation -------------------------------- 07
Independent Valving -------------------------------------- 08
Normal ltration ---------------------------------------- 08
Backwash ---------------------------------------------- 08
Rinsing/Flushing ------------------------------------------- 08
Waste ------------------------------------------------------ 08
STANDARD OPERATION ----------------------------------- 09
Start Up ---------------------------------------------------- 09
Regular Operation ----------------------------------------- 09
Backwash -------------------------------------------------- 10
MAINTENANCE ---------------------------------------------- 10
Fault Eliminators ------------------------------------------- 11
Insufcient Filtration --------------------------------------- 11
Disassembly, Re-assembly, Multi-port Valve ------------ 12
(not for UGI Filters)
Media Loading Chart -------------------------------------- 13
Pressure Drop Curve -------------------------------------- 13
Waterco Micron Horizontal Commercial Filter
DESCRIPTION
The Micron Horizontal lters have a lter media bed depth of 16” minimum up to 48” and a
50 PSI standard pressure rating. The lters can be used with a variety of medias, to provide
everything from sediment removal to the elimination of minerals and odours from water.
Combining lter housings and various lter media, media lters can be tted in congurations
to provide multi-stage water treatment. With easy access for lter media lling and removal, the
Micron series sand lters are versatile and can be used in most water treatment applications.
CONSTRUCTION
The Micron series of lters embody the latest in lament wound breglass; Waterco’s digitally
controlled lament winding machine faultlessly winds continuous strands of high quality
breglass lament under controlled tension to create a seamless one-piece vessel with
rened consistency and superior quality making it very resistant to corrosion and abrasion.
There are no welds or seams or special tank linings, which can corrode or undergo electrolytic
reactions. The fabrication technique involved in making the Micron Horizontal media lters
ensures that it will stand up very well to environmental and operation extremes.
I pg 01
