S M A R T A U D I O V I D E O I N N O VAT I O N
www.smartavi.com
AMade in the US
The DVN-8P is a cross-platform KVM capable of sharing a DVI Monitor, USB 2.0
Keyboard, USB 2.0 Mouse, Stereo Audio and IR between eight computers. It is RS-232
and Infrared compliant, capable of being controlled remotely via software.
• Supports Mac, PC, Linux and Sun DVI
• Supports High Resolution1920x1200 60Hz WUXGA
• Uses universal DVI Single Link connectors
• Zero pixel loss with TMDS signal correction
• Supports all USB 2.0 Devices (Flash Drives, Printers, Cameras, Scanners, etc.)
• Supports USB 2.0 keyboard and mouse
• Balanced stereo audio output
• Front panel tactile switch with LED indicator
• Full IR and RS-232 control
DVN-8P 8-PORT DVI-D, USB 2.0
AND AUDIO SWITCH
Control 8 Computers, PC or Mac on one Display Up To 20 Feet Away
with USB 2.0 Keyboard and Mouse, Stereo Audio and IR Control
8-Port Cross-platform DVI-D KVM
with USB 2.0, Stereo Audio, RS-232 and IR Control
DVNET FAMILY
S M A R T A U D I O V I D E O I N N O VAT I O N
www.smartavi.com
SmartAVI, Inc. / Twitter: smartavi - 2840 N. Naomi Ave. Burbank, CA 91504 - Tel: (818) 565-0011 Fax: (818) 565-0020 - http://www.SmartAVI.com
AMade in the US
Many leading companies have recognized and embraced the innovation of
SmartAVI’s technologies and have successfully incorporated them into their
organizations. Users of SmartAVI include:
SPECIFICATIONS
ORDERING INFORMATION
Part No. Description
DVN-8PS DVNET-8P, 8X1 DVI-D, USB2.0, Audio switch Includes: [DVN-
8P & (PS5VD4A)]
Application Diagram
• Home Theater Integration
• Digital Signage Deployment
• Information Kiosks/Displays
• Film/Recording Studios
Applications
Mac
PC
VIDEO
Format DVI-D Single Line
Maximum Pixel Clock 165 MHz
Input Interface (8) DVI-D 29-pin female
Output Interface (1) DVI-D 29-pin female
Resolution Up to 1920 x 1200 @60Hz
DDC 5 volts p-p(TTL)
Input Equalization Automatic
Input Cable Length Up to 20 ft.
Output Cable Length Up to 20 ft.
AUDIO
Frequency Response 20 Hz to 20 KHz
Impedance 600 ohm
Nominal Level 0-1.0 V
Common Mode Rejection at 60dB
Input Interface (8) 3.5 mm Stereo Audio
Output Interface (1) 3.5 mm Stereo Audio
USB
Signaling USB 2.0, 1.1 and 1.0 w/ Internal Hub
Input Interface (8) USB Type B
Output Interface (2) USB Type A
CONTROL
Front Panel Tact Switch
RS232 Via Software @ 9600 bps
IR Via Remote Control with IR-EYE Type 3
OTHER
Power External 100-240 VAC/5VDC4A @20W
Dimensions 10.5”W x 1.875”H x 6”D
Weight 7 lbs.
Approvals UL, CE, ROHS Compliant
Operating Temp. 32-131°F (0-55 °C)
Storage Temp. -4-185 °F (-20-85 °C)
Humidity Up to 95%
Emulation NO KEYBOARD OR MOUSE EMULATION
In the medical or industrial eld, where
it may not be practical (or safe) to have
one or more CPUs in the general vicinity,
SmartAVI’s DVI Switch Series is the perfect
solution, allowing for either PC or Mac
signals to be extended from computer to
monitor (20 feet from computer to DVI
Switch, and then 20 feet from DVI Switch
to remote monitor/display point).
P Front Rear
