Important information

about the AC power adapter

Model DYS824-140150W-K

Input 100-240V~50/60Hz 0.7A MAX

Output 14.0V 1.5A

Class II, Eciency Level VI

•This AC adapter is for audio & video equipment use

only and complies with IEC 62368 safety standard.

•The supplied 3-pin plug adapter complies with

BS 1363-1 and the supplied 2-pin plug adapter

complies with EN 50075.

•Before using the AC adapter, ensure the mains

voltage is within the rated supply voltage range.

•The output power taken from this AC adapter must

not exceed its rated output power.

•DO NOT disassemble or modify the AC adapter.

•DO NOT drop or throw the AC adapter.

•The external exible cable cannot be replaced and

if the cord is damaged, the AC adapter must be

replaced.

•DO NOT expose the AC adapter to dripping or

splashing water, and do not place objects lled with

liquids, such as vases, on or near the device.

•DO NOT leave the AC adapter in a hot location, such

as near re or under strong sunlight.

•DO NOT cover ventilation openings on the device.

•Unplug the AC adapter during lightning storms or

when unused for long periods of time to prevent

damage.

•Ensure that the AC adapter is readily accessible when

plugged into the mains. If an abnormal condition

occurs while using it, immediately turn off the

connected device and disconnect the mains adapter

from the mains.

•DO NOT dispose this AC adapter as general

household waste or unsorted municipal waste,

dispose of it according to local regulations.

1. Controls

2. Colour display

3. Remote receiver

4. 75mm NS+ driver

5. Ambientlightsensor

1. Kontroller

2. Farveskærm

3. Fjernbetjeningsmodtager

4. 75mm NS+ højttaler

5. Lysdetektor

1. Kontrollen

2. Farbdisplay

3. Fernbedienungsempfänger

4. 75mm NS+ Lautsprecher

5. Lichtdetektor

1. Controles

2. Pantalla a color

3. Receptor de control remoto

4. Altavoz NS+ de 75mm

5. Detectordeluz

1. Contrôles

2. Écran couleur

3. Récepteur de télécommande

4. Haut-parleur NS+ 75mm

5. Détecteur de lumière

1. Controlli

2. Schermo a colori

3. Ricevitore telecomando

4. Altoparlante NS+ 75mm

5. Rilevatore di luce

1. コントロール

2. カラー液晶

3. リモコン受信機

4. 75mmNS+スピーカー

5. 光検出器

 󼽑󼖸󾘥󻾴󻂄

 󼲈󻖈

 󼑬󺩅󾘥󼖸󼍐󾘥󻾴󼁼󺯌

 󼁀󽋘󼲀

 󻯷󾘥󺦬󼝜󺯌

1. Besturing

2. Kleurenscherm

3. Afstandsbediening ontvanger

4. 75mm NS+ luidspreker

5. Licht detector

1. Kontroller

2. Fargeskjerm

3. Fjernkontrollmottaker

4. 75mm NS+ høyttaler

5. Lysdetektor

1. Sterownik

2. Kolorowy wyświetlacz

3. Odbiornik pilota

4. Głośnik 75 mm NS+

5. Detektor światła

1. 控制项

2. 彩色显示

3. 光探测器

4. 75毫米NS+扬声器

5. 光探测器

7 8 9 10 11

6. DAB-FMantenna

7. USBC

8. DCinput

9. Lineinput

10.Headphoneoutput

11.Securityslot

6. DAB-FM-antenne

7. USBC

8. DC-indgang

9. Linjeindgang

10. Hovedtelefonudgang

11. Sikkerhedsplads

6. DAB-FM-Antenne

7. USBC

8. Gleichstromeingang

9. Audio-Eingang

10. Kopfhörerausgang

11. Sicherheitsschlitz

6. AntenaDAB-FM

7. USBC

8. EntradadeCC

9. Entradadelínea

10. Tomadeauriculares

11. Ranuradeseguridad

6. AntenneDAB-FM

7. USBC

8. EntréeCC

9. Prisedeligne

10. Sortiecasque

11. Fentedesécurité

6. AntennaDAB-FM

7. USBC

8. IngressoCC

9. Ingressodilinea

10. Presapercu󽘂e

11. Slotdisicurezza

6. DAB-FMアンテナ

7. USBC

8. DC入力

9. ライン入力

10. ヘッドフォンソケット

11. セキュリティスロット

 󼋤󼻨󺸴

 

 󼔡󻗁

 󻔘󼔔󾘥󼔡󻗁

 󽎀󻉸󽆌󾘥󻼨󼲯

 󻪐󼋤󾘥󼁈󻘋

6. DAB-FM-antenne

7. USBC

8. DC-ingang

9. Lijningang

10. Koptelefoonuitgang

11. Beveiligingssleuf

6. DAB-FM-antenne

7. USBC

8. DC-inngang

9. Linjeinngang

10. Hodetelefonutgang

11. Sikkerhetsspor

6. Antena DAB-FM

7. USB C

8. Wejście DC

9. Wejście liniowe

10. Wyjście słuchawkowe

11. Gniazdobezpieczeństwa

6. DAB-FM天线

7. USBC

8. 直流输入

9. 线路输入

10. 耳机输出

11. 安全插槽

1 2

3 4

100-240VAC

50/60Hz

14V DC 1.5A

5 6

Setup wizard

Follow the setup wizard to

congure your R1.

Rotate the until CONTROL KNOB

your preferred choice is shown,

then press the to CONTROL KNOB

SELECT.

Need more help?

For more information, see

www.ruarkaudio.com/support

App control

You can also control your R1

using OKTIV. Find it on the Apple/

Android app store.

For more information visit

www.ruarkaudio.com/app

Connect a dierent device

MENU > Connect device

Select or select one of the existing devices in the New

pairing list.

You can pair up to 8 devices, although you will only be

able to play audio from one device at a time.

Clear paired devices list

MENU > Forget devices

Clearing the paired devices list removes all

remembered devices and allows you to start a new

list by connecting the ones you want remembered.

Device name

You can change the device name of your R1 to

something more descriptive like “Ozzie’s R1”, so then

it will show on Bluetooth searches and networks as

“Ozzie’s R1”.

You can do this from the companion app OKTIV.

www.ruarkaudio.com/app

Troubleshooting

Ensure the Bluetooth function on your device is

on, and select “Ruark R1” from the list of available

devices.

It may take a few seconds for your R1 to appear in the

list on your device, and in some cases you may need

to input “0000” as the pairing password.

If you are having trouble connecting your Bluetooth

device, we recommend you clear the paired devices

list.

You will also need to delete “Ruark R1” from the

paired devices list on your Bluetooth device before

pairing it to your R1 again. For more information,

refer to your Bluetooth device’s documentation.

For help with using Bluetooth, please visit

www.ruarkaudio.com/support

You cannot use the Bluetooth function on your R1 to

connect to Bluetooth headphones

Safety information

• Read this user guide and follow all instructions, it will help you set up

and operate your product properly.

• Heed all warnings and keep this user guide for future reference.

• Do not attempt to use a damaged device as this could result in a

dangerous electric shock.

• Do not open the unit or remove any panels to expose the electronics.

No user serviceable parts inside.

• Refer all servicing to qualied service personnel. Servicing is required

when the device has been damaged in any way, such as when any

power cord, or power plug is damaged, liquid has been spilled or

objects have fallen into the device, the device has been exposed to rain

or moisture, does not operate normally, or has been dropped.

• This device is intended to be operated ONLY from the AC voltages

listed on the back panel or included AC mains adapter. Operation from

voltages other than those indicated may cause irreversible damage to

the device and void the product warranty.

• Ensure that the mains plug or mains connector into the unit is readily

accessible in case disconnection from the mains is required.

• The AC mains adapter, mains plug, or mains connector must be

removed from the socket to completely disconnect the system from AC

mains power.

• Do not place any naked ame sources, such as lighted candles, on or

near the device. Do not install near any heat sources such as radiators,

stoves, or other devices that produce heat.

• Avoid exposure to extreme heat or cold.

• Only use attachments/accessories specied for this device. Make no

modications to the system or accessories. Unauthorised alterations

may compromise safety, regulatory compliance, and system

performance.

• Only use the supplied aerial or an approved replacement.

• To reduce the risk of re or electrical shock, do not expose the device

to rain or moisture. Do not expose this device to dripping or splashing,

and do not place objects lled with liquids, such as vases, on or near the

device. As with any electronic products, use care not to spill liquids into

any part of the system. Liquids can cause a failure and/or a re hazard.

• Disconnect this device from AC mains power during lightning storms or

when unused for long periods of time to prevent damage to this device.

• To prevent risk of re or electric shock, avoid overloading AC mains

power outlets or extension cords.

• Long-term exposure to loud music may cause hearing damage. It is

best to avoid extreme volume when using headphones, especially for

extended periods.

• Do not install this device in a conned space. Always leave a space of at

least 10cm around the device for ventilation and ensure that curtains or

other objects never cover ventilation openings on the device.

Regulatory information

This device is labelled in accordance with European Directive

2012/19/EU concerning waste electrical and electronic

equipment. This symbol indicates that the product or associated

batteries should not be disposed of as general household waste.

As with any electrical equipment, please dispose of it according

to local regulations.

CE COMPLIANCE INFORMATION

This product conforms to all EU Directive requirements as applicable by

law. Hereby, Ruark Audio, declares that this device complies with the

essential requirements and other relevant provisions of the European

Radio Equipment Directive 2014/53/EU. You can download the full CE

Declaration of Conformity at www.ruarkaudio.com/doc/R1Sdoc.pdf

UK CONFORMITY ASSESSMENT INFORMATION

This product conforms to all UK Conformity Assessment regulations

as applicable by law. You can download the full UKCA Declaration of

Conformity at www.ruarkaudio.com/doc/R1SUKCA.pdf

Guarantee

extended three-year guarantee.

As standard, this product is guaranteed to be free

from defects for a period of two years from date of

purchase, but this is extended to three years if you

This guarantee remains valid providing this product

has been treated with due care and attention. Product

failure through accidental damage, excessive wear and

tear, negligence or unauthorised modication will void

this guarantee.

If this product was purchased in the UK and it

develops a fault, please contact the retailer from which

it was purchased, or contact us directly via our website

www.ruarkaudio.com/support.

For products purchased outside the UK the

distributor in the country of purchase guarantees the

product. For details, please contact the local Ruark

distributor or outlet.

If returning this product, please ensure it is packed

in its original packaging and a proof of purchase is

included.

This guarantee in no way varies or removes the

purchaser’s statutory rights.

Errors and omissions excepted.

General care

● Clean with a soft, lint-free duster or slightly

dampened cloth. Do not use wax sprays or other

substances as these may damage the surface nish

or impair performance.

● Do not expose your unit to direct sunlight, high

humidity, dust, excessive vibration or extreme

temperatures, all of which can affect the nish,

performance and reliability of the unit.

● Recommended operating temp. range is 5°C to 40°C.

● Natural wood nishes will vary and lighten or darken

with age, particularly when exposed to sunlight.

the Ruark Audio logo, and other Ruark Audio marks

are owned by Ruark Audio and may be registered.

Ruark Audio assumes no responsibility for any errors

that may appear in this manual and the information

contained in it may change without notice.

Bluetooth® and associated logos are registered

trademarks owned by Bluetooth SIG, Inc.

The Spotify Software is subject to third party licenses:

www.spotify.com/connect/third-party-licenses

All other trademarks are the property of their

respective owners.

Fællesfunktioner

Tænd og gå i standby

Tryk på STANDBY for at tænde for radioen. Tryk igen

for at skifte til standby.

Spiller nu-skærme

Medmindre en indstilling bliver justeret, vil skærmen

se ud som eksemplet nedenfor.

1. Lydkilde

2. Alarm ikon

3. Station / spor information

4. Statusikoner, f.eks. wi, gentagelse af spor/shue

5. Ur

6. Sleep timer ikon

Menu-skærme

For at ændre en indstilling tryk på MENU for at

vise listen over tilgængelige muligheder, drej

KONTROLKNAPPEN for at rulle igennem listen og tryk

derefter på knappen for at bekræfte dit valg.

7. Menunavn

8. Menuvalg

For at skifte indstillinger – tryk på MENU

For at rulle igennem valg – drej KONTROLKNAPPEN

For at vælge valg – tryk på KONTROLKNAPPEN

For at gå tilbage eller afslutte – tryk på MENU for

at gå tilbage til den forrige skærm, indtil du kommer

tilbage til skærmen Spiller nu, eller vent et par

sekunder

Specyfikacje produktu

Marka:	Ruark Audio
Kategoria:	radio
Model:	R1S

Potrzebujesz pomocy?

Jeśli potrzebujesz pomocy z Ruark Audio R1S, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą

Twoje imię*

Twój email*

Napisz tutaj swoje pytanie

Instrukcje radio Ruark Audio

Ruark Audio R7 Mk1 / Mk2 Instrukcja

29 Września 2024

Ruark Audio R1S Instrukcja

29 Września 2024

Ruark Audio R5 Instrukcja

28 Września 2024

Ruark Audio R1 Mk2 Instrukcja

28 Września 2024

Ruark Audio BackPack RA-R1BP Instrukcja

28 Września 2024

Ruark Audio R7 Mk3 Instrukcja

28 Września 2024

Ruark Audio R1 DAB Instrukcja

28 Września 2024

Ruark Audio R1 Mk3 Instrukcja

28 Września 2024

Ruark Audio Rseven Instrukcja

28 Września 2024

Ruark Audio R2i Mk2 Instrukcja

28 Września 2024

Instrukcje radio

Najnowsze instrukcje dla radio

Difrnce DBB300 Instrukcja

2 Kwietnia 2025

Denver CRQ-110 Instrukcja

2 Kwietnia 2025

Audiosonic CL-1489 Instrukcja

1 Kwietnia 2025

Muse MF-060 VB Instrukcja

1 Kwietnia 2025

Muse MF-060 AG Instrukcja

1 Kwietnia 2025

RoadKing 56 Instrukcja

29 Marca 2025

Bush DS982 Instrukcja

26 Marca 2025

DeWalt DCA2203C Instrukcja

24 Marca 2025

MOOOV Bamboo 477320 Instrukcja

14 Marca 2025

MB Quart RVM-10V1 Instrukcja

11 Marca 2025
