Strona 1/23

Instruction Manual

Bedienungsanleitung

Manuel d’utilisation

Manuale di Istruzioni

UMX™ Carbon Cub SS

Age Recommendation: Not for children under 14 years. This is not a toy.

WARNING: Read the ENTIRE instruction manual to become familiar with the features of the

product before operating. Failure to operate the product correctly can result in damage to the product,

personal property and cause serious injury.

This is a sophisticated hobby product. It must be operated with caution and common sense and

requires some basic mechanical ability. Failure to operate this product in a safe and responsible

manner could result in injury or damage to the product or other property. This product is not intended

for use by children without direct adult supervision. Do not attempt disassembly, use with incompatible

components or augment product in any way without the approval of Horizon Hobby, Inc. This manual

contains instructions for safety, operation and maintenance. It is essential to read and follow all the

instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly

and avoid damage or serious injury.

Meaning of Special Language:

The following terms are used throughout the product literature to indicate various levels of potential

harm when operating this product:

NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND

little or no possibility of injury.

CAUTION: Procedures, which if not properly followed, create the probability of physical property damage

AND a possibility of serious injury.

WARNING: Procedures, which if not properly followed, create the probability of property damage,

collateral damage, and serious injury OR create a high probability of superﬁ cial injury.

NOTICE

All instructions, warranties and other collateral documents are subject to change at the sole discretion

of Horizon Hobby, Inc. For up-to-date product literature, visit www.horizonhobby.com and click on the

support tab for this product.

The E-ﬂ ite® UMX™ Carbon Cub SS BNF is a feature-rich scale BNF model that’s an escape from the ordinary.

Its high-output brushless power system will allow you to leap from tight spots and, with its fully-functional

ﬂ aps, is simply a joy to ﬂ y. Large credit for its gentle manners go to the onboard AS3X

™ system, which

makes handling super-smooth, even in moderate winds, and provides rock solid control agility. Even though

your new model is fully assembled, please read and follow this manual completely to be sure you’re ready

to take full advantage of what this awesome RC aircraft has to offer.

To register your product online, go to www.e-ﬂ iterc.com

Table of Contents

Preﬂ ight Checklist .................................................4

AS3X™ System Delivers

Breakthrough Performance ..................................4

Charging Warnings................................................4

Charging the Battery .............................................5

Transmitter and Receiver Binding .........................6

Installing the Flight Battery ..................................6

Arming the ESC ....................................................7

Low Voltage Cutoff (LVC) .......................................7

Control Centering ..................................................8

Settings for Control Horns .....................................8

Adjusting Center of Gravity (CG) ............................9

Optional Tow Plate Installation ............................10

Towing ................................................................10

Tips for Towing ...................................................11

Optional Float Installation ....................................12

Flying Tips and Repairs .......................................13

Additional Safety Precautions and Warnings ........14

Service of Power Components ............................15

Opening the Fuselage .........................................16

Troubleshooting Guide ........................................16

Troubleshooting Guide (Continued) ......................17

Limited Warranty ................................................18

Warranty and Service Information .......................19

Compliance Information for the European Union ..19

Replacement Parts ..............................................75

Optional Parts and Accessories ...........................76

Parts Contact Information ...................................77

BL180 (Brushless) Outrunner Motor,

2500Kv (EFLUM180BL2)

DSM2®/DSMX® 6Ch Ultra Micro

AS3X™ Receiver BL-ESC (EFLU4864)

(3) 2.3-Gram Performance Linear

Long Throw Servos (SPMSA2030L)

(2) 2.3-Gram Linear Long Throw

Offset Servos (SPMSA2030LO)

Battery: 180mAh 2S 20C Li-Po

(EFLB1802S20)

Battery Charger: 2S 7.4V Li-Po

(EFLUC1007)

Recommended Transmitter:

Full Range DSM2®/DSMX® (DX4e and up)

Needed to Complete

Installed

15.7 in (398mm)

24 in (610mm)

3.17 oz (90 g)

Specyfikacje produktu

Marka:	E-flite
Kategoria:	zabawka sterowana radiowo
Model:	UMX Carbon Cub SS BNF
Kolor produktu:	Grey, Red
Szerokość produktu:	610 mm
Waga produktu:	90 g
Pojemność baterii:	180 mAh
