Instruction Manual
Bedienungsanleitung
Manuel d’utilisation
Manuale di Istruzioni
UMX™ AS3Xtra
2
EN
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the
product before operating. Failure to operate the product correctly can result in damage to the product,
personal property and cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and requires
some basic mechanical ability. Failure to operate this product in a safe and responsible manner could
result in injury or damage to the product or other property. This product is not intended for use by
children without direct adult supervision. Do not use with incompatible components or alter this product
in any way outside of the instructions provided by Horizon Hobby, Inc. This manual contains instructions
for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings
in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or
serious injury.
Meaning of Special Language:
The following terms are used throughout the product literature to indicate various levels of potential
harm when operating this product:
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND
little or no possibility of injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage
AND a possibility of serious injury.
WARNING: Procedures, which if not properly followed, create the probability of property damage,
collateral damage, and serious injury OR create a high probability of superfi cial injury.
NOTICE
All instructions, warranties and other collateral documents are subject to change at the sole discretion
of Horizon Hobby, Inc. For up-to-date product literature, visit www.horizonhobby.com and click on the
support tab for this product.
Age Recommendation: Not for children under
14 years. This is not a toy.
Safety Precautions and Warnings
• Always keep a safe distance in all directions
around your model to avoid collisions or injury.
This model is controlled by a radio signal subject
to interference from many sources outside your
control. Interference can cause momentary loss
of control.
• Always operate your model in open spaces away
from full-size vehicles, traffi c and people.
• Always carefully follow the directions and
warnings for this and any optional support equip-
ment (chargers, rechargeable battery packs, etc.).
• Always keep all chemicals, small parts and
anything electrical out of the reach of children.
• Always avoid water exposure to all equipment
not specifi cally designed and protected for this
purpose. Moisture causes damage to electronics.
• Never place any portion of the model in your
mouth as it could cause serious injury or
even death.
• Never operate your model with low transmitter
batteries.
• Always keep aircraft in sight and under control.
• Always use fully charged batteries.
• Always keep the transmitter powered on while
aircraft is powered.
• Always remove batteries before disassembly.
• Always keep moving parts clean.
• Always keep parts dry.
• Always let parts cool after use before touching.
• Always remove batteries after use.
• Always ensure failsafe is properly set
before fl ying.
• Never operate aircraft with damaged wiring.
• Never touch moving parts.
3
EN
T
he E-fl ite® UMX™ AS3Xtra takes Ultra Micro eXtreme to the next level. Constructed of laser-cut fl at
foam with carbon reinforcement and micro-thin fi lm, this aircraft was specifi cally engineered to
optimize super-low wing loading, strength and durability, plus AS3X
® technology to provide outstanding 3D
performance in tight fl ight spaces. Based on the ground-breaking original UMX Extra 300 3D, the addition of
AS3X technology makes it possible to be even more successful whether it’s performing the simplest loop or
the latest extreme 3D moves.
Please be sure to read through this manual carefully so that you are equipped to successfully enjoy all the
benefi ts this outstanding ultra micro model has to offer.
To register your product online, go to www.e-fl iterc.com
Installed
Motor: Ultra Micro Brushed Motor
8.5mm x 23mm (EFLU5152)
Receiver : DSM2/DSMX UM AS3X
Receiver/Servos/ESC, UMX AS3Xtra
(EFLU5164)
(2) 2.3-Gram Performance Linear Long
Throw Servo (SPMSA2030L)
Needed to Complete
Battery: 150mAh 1S 3.7V 25C/45C
Li-Po, (EFLB1501S25 or EFLB1501S45)
Battery Charger:
Celectra™ 4-Port 1S 3.7V 0.3A DC
Li-Po Charger (EFLC1004)
Recommended Transmitter:
Full range Spektrum™ DSM2®/DSMX®
with dual-rates (DX4e and up)
19.8 in (503mm)
16.8 in (426mm)
1.25 oz
(36.5 g)
Prefl ight Checklist ..................................................4
The Incredible AS3X® system
Aerobatics Experience ...........................................4
Low Voltage Cutoff (LVC) ........................................4
Transmitter and Receiver Binding ...........................5
Alternate Flight Mode Programming .......................6
ESC/Receiver Arming, Battery Installation and
Center of Gravity ....................................................7
Optional Side Force Generators (SFGs) Installation .8
Control Direction Test .............................................8
Control Centering ..................................................9
Trimming ...............................................................9
Control Horn Settings .............................................9
Dual Rates .............................................................9
Flying Tips and Repairs ........................................10
Post Flight Checklist ............................................10
Power Components Service .................................11
Troubleshooting Guide .........................................12
Limited Warranty .................................................13
Warranty and Service Information ........................15
Compliance Information for the European Union ...15
Replacement parts ...............................................58
Optional parts and Accessories ............................59
Table of Contents
Specifi cations
