user manual

guide de l’utilisateur

RC107

v4.0 (1.0.4.0) (EN/F)

Before you begin Clock

EN/F

It is important to read this user manual prior to using your new product for the ﬁ rst time.

Nous vous recommandons de lire ce manuel d’instructions avant d’utiliser votre

nouveau produit pour la première fois.

Plugging in for power

• Connect the supplied power adapter

to the unit’s AC IN jack at the back,

and connect to a convenient wall

outlet.

• Refer to the “Clock” section and

follow the instructions to set the

clock.

Battery back-up operation

• This clock radio is equipped with

a timekeeping system that can be

powered with a 9-volt alkaline

battery (not included). The power

failure protection circuit will not

operate unless battery is installed.

• When normal household power

is interrupted, or AC line cord

is unplugged, the batteries will

power the clock radio to keep

track of time and alarm settings

programmed into memory.

• When the battery backup functions,

the digital display will not light,

however, the function of alarm

still occurs during the power

interruption if remaining battery

power is adequate.

• Normal operation will resume after

AC power is restored so you will not

have to reset the time or the alarm.

To install the battery:

1. Remove battery compartment door

(located at the bottom of the radio)

by applying thumb pressure to the

tab on battery door and then lift

the door out and off the cabinet.

2. Connect a 9-volt alkaline battery

(not included) to the connector

plug.

3. Replace the compartment door.

Power failure indicator

When AC power is interrupted

(disconnected) for a short period of

time, both time and alarm settings

will be lost (unless batteries are

installed). After AC power is restored

(reconnected), the Digital Display

will blink to indicate that power was

interrupted and you should re-adjust

the time and alarm settings.

General controls

To set the clock:

1. Slide the / WAKE 1 / WAKE 2

/ switch to to enter the clock

setting mode.

2. Press or to set the time.

• Press and hold to decrease or

increase the time value quickly.

• The “:” ﬂ ashes on the display in

clock setting mode.

3. Slide the / WAKE 1 / WAKE 2 /

switch to .

• The clock is in 12 hour

format. The AM indicator

lights to show AM time.

• The clock time blinks

if it is not set or after power

interruption (without back-up

battery installed).

Alkaline (NEDA 1604A/

IEC 6LR61) battery is

recommended. Carbon-zinc

battery may be used but memory

holding time will be substantially

reduced. Memory holding time

for a fresh alkaline battery is

approximately 8 hours (if alarm

is not operated) which should

take care of short, nuisance-type

AC power failures. To preserve

battery life, the unit should remain

plugged into an AC outlet. As the

battery gets older, its voltage drops

and memory may be lost. Be sure

to replace the battery periodically.

Battery should be removed if the

unit will be stored for more than

one month. Leaky battery can

badly damage the clock radio.

FCC Information

IMPORTANT SAFETY INSTRUCTIONS

PLEASE READ AND SAVE THIS FOR FUTURE REFERENCE

Some of the following information may

not apply to your particular product;

however, as with any electronic product,

precautions should be observed during

handling and use.

• Read these instructions.

• Keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near

water.

• Clean only with dry cloth.

• Do not block any ventilation

openings. Install in accordance with

the manufacturer’s instructions.

• Do not install near any heat sources

such as radiators, heat registers,

stoves, or other apparatus (including

ampliﬁ ers) that produce heat.

• Do not defeat the safety purpose

of the polarized or grounding-type

plug. A polarized plug has two

blades with one wider than the

other. A grounding type plug has

two blades and a third grounding

prong. The wide blade or the third

prong is provided for your safety. If

the provided plug does not ﬁ t into

your outlet, consult an electrician

for replacement of the obsolete

outlet.

• Protect the power cord from being

walked on or pinched particularly at

plugs, convenience receptacles, and

the point where they exit from the

apparatus.

• Only use attachments/accessories

speciﬁ ed by the manufacturer.

• Use only with

the cart, stand,

tripod, bracket,

or table

speciﬁ ed by the

manufacturer,

or sold with

the apparatus.

When a cart is used, use caution

when moving the cart/apparatus

combination to avoid injury from

tip-over.

• Unplug this apparatus during

lightning storms or when unused

for long periods of time.

• Refer all servicing to qualiﬁ ed

service personnel. Servicing is

required when the apparatus has

been damaged in any way, such

as power-supply cord or plug is

damaged, liquid has been spilled

or objects have fallen into the

apparatus, the apparatus has been

exposed to rain or moisture, does

not operate normally, or has been

dropped.

ADDITIONAL SAFETY INFORMATION

• The AC/AC adapter supplied with

this product is intended to be

correctly oriented in a vertical or

ﬂ oor mount position.

• Do not use unauthorized chargers

or power adapters. Use only

chargers or power adapters that

came with your product or that is

listed in the user’s guide.

• Apparatus shall not be exposed to

dripping or splashing and no objects

ﬁ lled with liquids, such as vases,

shall be placed on the apparatus.

• Always leave sufﬁ cient space around

the product for ventilation. Do

not place product in or on a bed,

rug, in a bookcase or cabinet that

may prevent air ﬂ ow through vent

openings.

• Do not place lighted candles,

cigarettes, cigars, etc. on the

product.

• Care should be taken so that objects

do not fall into the product.

• Do not attempt to disassemble

the cabinet. This product does

not contain customer serviceable

components.

• The marking information is located

at the bottom of apparatus.

• To be completely disconnect the

power input, the AC/AC adapter

of apparatus shall be disconnected

from the mains.

• AC/AC adapter is a disconnect

device. The AC/AC adapter should

not be obstructed OR should be

easily accessed during intended use.

• The ventilation should not be

impeded by covering the ventilation

openings with items such as

newspaper, table-cloths, curtains etc.

• No naked ﬂ ame sources, such as

lighted candled, should be placed

on the apparatus.

• Attention should be drawn to the

environmental aspects of battery

disposal.

• The use of apparatus in moderate

climates.

Important battery

precautions

• Any battery may present a risk of

ﬁ re, explosion, or chemical burn

if abused. Do not try to charge a

battery that is not intended to be

recharged, do not incinerate, and

do not puncture.

• Non-rechargeable batteries, such as

alkaline batteries, may leak if left in

your product for a long period of

time. Remove the batteries from the

product if you are not going to use

it for a month or more.

• If your product uses more than one

battery, do not mix types and make

sure they are inserted correctly.

Mixing types or inserting incorrectly

may cause them to leak.

• Discard any leaky or deformed

battery immediately. They may

cause skin burns or other personal

injury.

• Please help to protect the

environment by recycling or

disposing of batteries according to

federal, state, and local regulations.

WARNING: The battery (battery or

batteries or battery pack) shall not

be exposed to excessive heat such as

sunshine, ﬁ re or the like.

Ecology

Help protect the environment - we

recommend that you dispose of used

batteries by putting them into specially

designed receptacles.

Note: This equipment has been tested

and found to comply with the limits

for a Class B digital device, pursuant

to Part 15 of FCC Rules. These limits

are designed to provide reasonable

protection against harmful interference

in a residential installation. This

equipment generates, uses, and can

radiate radio frequency energy and, if

not installed and used in accordance

with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee

that interference will not occur in a

particular installation. If this equipment

does cause harmful interference to

radio or television reception, which

can be determined by turning the

equipment off and on, the user is

encouraged to try to correct the

interference by one or more of the

following measures:

• Reorient or relocate the receiving

antenna.

• Increase the separation between the

equipment and receiver.

• Connect the equipment into an

outlet on a circuit different from

that to which the receiver is

connected.

• Consult the dealer or an

experienced radio/TV technician for

help.

Changes or modiﬁ cations not expressly

approved by Audiovox could void

the user’s authority to operate the

equipment.

]

Portable Cart Warning

This Class B digital apparatus

complies with Canadian ICES-003.

Cet appareil numérique de la classe

B est conforme à la norme NMB-003

du Canada.

Electrical power

information

AC/AC adapter power supply:

120 V ~ 60 Hz

AC output: 10.5V @ 1 A

Right view Left view

• – VOLUME + – To adjust volume

• TUNING – To adjust radio frequency

• USB Charging – To charge your cell

phones via this USB connector

Top view

• ON/OFF – To turn radio on or off;

cancel the wake function.

• / WAKE 1 / WAKE 2 / – To

select setting mode ( : lock

mode, : wake WAKE 1 / WAKE 2

setting mode, : clock setting

mode)

• SNOOZE/SLEEP OFF – To quiet

the wake alarm or wake radio

temporarily (default: 9 minutes);

cancel the sleep function

• – To decrease value when setting

clock, wake, snooze and sleep

modes.

• – To increase value when setting

clock, wake, snooze and sleep

modes.

• WAKE 1 MODE – To activate the

Wake 1 settings; change wake 1

mode (radio/alarm).

• WAKE 2 MODE – To activate the

Wake 2 settings; change wake 2

mode (radio/alarm).

• SLEEP – To activate the sleep

function

• AM/FM – To select radio band

• AM – AM time

• 1 – Wake time 1 to alarm

• 1 – Wake time 1 to radio

• 2 – Wake time 2 to alarm

• 2 – Wake time 2 to radio

Display

Indicator

Setting wake time

1. Slide the / WAKE 1 / WAKE 2 /

switch to select or WAKE 1

WAKE 2 setting mode.

2. Press or to set the wake time.

• Press and hold to decrease or

increase the time value quickly.

• The “:” ﬂ ashes on the display in

wake time setting mode.

3. Slide the / WAKE 1 / WAKE 2 /

switch back to .

Selecting wake source

• Press WAKE 1 or WAKE 2

repeatedly to select a wake source

(alarm / radio ).

• A green indicator will light next to

the corresponding wake setting icon

when the wake source is selected.

Wake to alarm

When wake to alarm is selected, the

green indicator will light next to the

icon.

• The unit is equipped with GRAD-

U-WAKE. The alarm volume will

increase gradually to its maximum

in about 30 to 45 seconds.

• Note that the Alarm mode is not

affected by the volume control. If

you set the SLEEP function with a

low volume setting for the Radio

before going to bed, it is advisable

to use Wake to Alarm mode to

In sleep mode, the unit will turn off

automatically after a speciﬁ ed time.

To set sleep time:

1. Press . The time display will SLEEP

show “0:59” and the radio will turn

on.

2. While holding , press SLEEP or

to set the time for sleep mode.

• The time range is from 1 minute

to 2 hours. (The default time is 59

minutes.)

3. Release and the display will SLEEP

revert to the current time.

• You may select radio stations as

usual in sleep mode. The radio

will turn off when the preset time

elapses.

To cancel the sleep function:

• If you decide to turn off the radio

sooner, press SNOOZE/SLEEP OFF

or .ON/OFF

To view remaining time in sleep

mode:

• Press SLEEP once.

The last setting in SLEEP

mode is saved for future use.

Use the USB charging port to charge

your smartphone or to power usb

powered devices such as a USB type

lamp or fan.

If you are using a smartphone:

The unit can charge your smartphone if

its jack for charging is a micro USB jack.

If its jack for charging is not a micro

USB jack, the unit may not be able to

charge it.

If you are using an iPhone:

The unit can charge iPhone 2G, iPhone

3G, iPhone 3GS and iPhone 4G.

To connect your cell phone for

charging:

Use a USB cable (not included) to

connect your cell phone to the USB

connector of the unit. Your cell phone

should start charging.

Sleep function USB charging

Warranty information

12 Month Limited Warranty

Applies to RCA Clock Radios

AUDIOVOX ACCESSORIES CORP. (the

Company) warrants to the original retail

purchaser of this product that should

this product or any part thereof, under

normal use and conditions, be proven

defective in material or workmanship

within 12 months from the date of

original purchase, such defect(s) will be

repaired or replaced with reconditioned

product (at the Company’s option)

without charge for parts and repair

labor.

To obtain repair or replacement

within the terms of this Warranty, the

product is to be delivered with proof

of warranty coverage (e.g. dated bill

of sale), speciﬁ cation of defect(s),

transportation prepaid, to the Company

at the address shown below.

This Warranty does not extend to the

elimination of externally generated

static or noise, to correction of

antenna problems, loss/interruptions of

broadcast or internet service, to costs

incurred for installation, removal or

reinstallation of product, to corruptions

caused by computer viruses, spyware or

other malware, to loss of media, ﬁ les,

data or content, or to damage to tapes,

discs, removable memory devices or

cards, speakers, accessories, computers,

computer peripherals, other media

players, home networks or vehicle

electrical systems.

This Warranty does not apply to any

product or part thereof which, in the

opinion of the Company, has suffered

or been damaged through alteration,

improper installation, mishandling,

misuse, neglect, accident, or by removal

or defacement of the factory serial

number/bar code label(s). THE EXTENT

OF THE COMPANY’S LIABILITY UNDER

THIS WARRANTY IS LIMITED TO THE

REPAIR OR REPLACEMENT PROVIDED

ABOVE AND, IN NO EVENT, SHALL THE

COMPANY’S LIABILITY EXCEED THE

PURCHASE PRICE PAID BY PURCHASER

FOR THE PRODUCT.

This Warranty is in lieu of all other

express warranties or liabilities. ANY

IMPLIED WARRANTIES, INCLUDING

ANY IMPLIED WARRANTY OF

MERCHANTABILITY, SHALL BE LIMITED

TO THE DURATION OF THIS WRITTEN

WARRANTY. ANY ACTION FOR BREACH

OF ANY WARRANTY HEREUNDER

INCLUDING ANY IMPLIED WARRANTY

OF MERCHANTABILITY MUST BE

BROUGHT WITHIN A PERIOD OF 24

MONTHS FROM DATE OF ORIGINAL

PURCHASE. IN NO CASE SHALL THE

COMPANY BE LIABLE FOR ANY

CONSEQUENTIAL OR INCIDENTAL

DAMAGES FOR BREACH OF THIS OR

ANY OTHER WARRANTY. No person or

representative is authorized to assume

for the Company any liability other than

expressed herein in connection with the

sale of this product.

Some states do not allow limitations on

how long an implied warranty lasts or

the exclusion or limitation of incidental

or consequential damage so the above

limitations or exclusions may not apply

to you. This Warranty gives you speciﬁ c

legal rights and you may also have

other rights which vary from state to

state.

Recommendations before returning

your product for a warranty claim:

• Properly pack your unit. Include

any remotes, memory cards, cables,

etc. which were originally provided

with the product. However DO NOT

return any removable batteries,

even if batteries were included

with the original purchase. We

recommend using the original

carton and packing materials. Ship

to the address shown below.

• Note that product will be returned

with factory default settings.

Consumer will be responsible to

restore any personal preference

settings.

Audiovox Electronics Corp.

Attn: Service Department.

150 Marcus Blvd.

Hauppauge N.Y. 11788

1-800-645-4994

For Canada Customers, please ship to:

Audiovox Return Centre

c/o Genco

6685 Kennedy Road,

Unit#3, Door 16,

Mississuaga, Ontario

L5T 3A5

Illustrations contained within this

publication are for representation only

and subject to change.

The descriptions and characteristics

given in this document are given as

a general indication and not as a

guarantee. In order to provide the

highest quality product possible,

we reserve the right to make any

improvement or modiﬁ cation without

prior notice.

111 Congressional Blvd., Suite 350

Carmel, IN 46032

Trademark(s) ® Registered

Printed in China

Visit http://store.audiovox.com to find the best

accessories for your products.

wake you up since the Alarm will be

at a louder volume setting than the

Radio mode.

Wake to radio

When wake to radio is selected, the

green indicator will light next to the

icon.

To set wake station:

1. Select radio band.

2. Select desired station.

3. Adjust the volume by + VOL –.

Turning off alarm

To silence the alarm momentarily:

• Press SNOOZE/SLEEP OFF or any

one of the SmartSnoozeTM buttons

( / ). The alarm will sound again

when the snooze period is over.

(Read “SmartSnoozeTM”)

To stop the alarm completely:

• Press ON/OFF. The alarm will

activate again at the same time on

the following day.

To disable the wake function

completely:

• Press WAKE 1 WAKE 2 or MODE

MODE repeatedly until no indicator

lights next to the wake icons

( / ) on the display.

• Charging function may

not be supported for

all phones or electronic

devices.

• Charging function is not

available in AM mode.

• Before charging your cell

phone, please ensure the radio

is connected to the supplied AC

adapter.

Radio Wake function

Turning on/off the Radio

Press the button on the top ON/OFF

of the unit to turn on the radio. Press

again to turn off the radio.

Switching bands

Slide the band switch on the top of

the unit to select between AM and FM

band.

Tuning to stations

Rotate the knob on the TUNING

right of the unit to adjust the radio

frequency with reference to the tuning

dial scale.

Built-in AFC

The Built In Automatic Frequency

Control (AFC) works only on FM. It helps

to reduce drift on FM reception and

keeps the radio locked in on the FM

station to which it is tuned.

When tuning in FM stations, you may

notice that the station you are tuning

can be well-tuned on two or three

nearby points on the dial. Always tune

carefully at the loudest and clearest

point.

SmartSnoozeTM

• This operation allows extra sleep

time when the alarm sounds. The

alarm can be turned off temporarily

by pressing SNOOZE/SLEEP OFF

or any one of the SmartSnoozeTM

buttons until the snooze period is

over.

• SmartSnoozeTM buttons include:

/ / SNOOZE/SLEEP OFF.

• Snooze function can be used

repeatedly up to 2 hours. After this,

the alarm will turn off until the

next alarm conditions are met.

• SmartSnoozeTM will be activated

only when the / WAKE 1 /

WAKE 2 / switch is set to .

To set the “quiet” period with

Snooze:

1. Press and hold SNOOZE/SLEEP

OFF in clock mode, radio mode,

clock setting mode or alarm setting

mode.

2. Press or to adjust snooze time.

Then release SNOOZE/SLEEP OFF

button to save the setting.

• The Snooze Period range can be

from 1 to 30 minutes. (The default

time is 9 minutes)

AM antenna

A built-in ferrite rod antenna eliminates

the need for an outside antenna for

AM reception. Rotating the unit slightly

may improve reception of distant AM

stations.

You can activate the

previously set alarm time by

pressing the WAKE 1 MODE

or button.WAKE 2 MODE

your cell phone

USB cable (not included)

Specyfikacje produktu

Marka:	Audiovox
Kategoria:	radio
Model:	RC107

Potrzebujesz pomocy?

Jeśli potrzebujesz pomocy z Audiovox RC107, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą

Twoje imię*

Twój email*

Napisz tutaj swoje pytanie

Instrukcje radio Audiovox

Audiovox RC105 Instrukcja

1 Października 2024

Audiovox RC85i Instrukcja

1 Października 2024

Audiovox AVXSXDH3 Instrukcja

1 Października 2024

Audiovox iHDP01A Instrukcja

1 Października 2024

Audiovox RC127I Instrukcja

1 Października 2024

Audiovox RC107 Instrukcja

1 Października 2024

Audiovox RC100 Instrukcja

1 Października 2024

Audiovox RC117 Instrukcja

1 Października 2024

Audiovox RC130i Instrukcja

1 Października 2024

Instrukcje radio

Najnowsze instrukcje dla radio

Ruarkaudio Rseven Instrukcja

15 Października 2024

Ruarkaudio MR1 Instrukcja

15 Października 2024

Denver TWE-55B Instrukcja

15 Października 2024

Audiosonic CL-1486 Instrukcja

14 Października 2024

Sangean DPR-39 Instrukcja

13 Października 2024

Roberts Stream 93i Instrukcja

13 Października 2024

Sangean RCR-9 Instrukcja

13 Października 2024

Uniden UH45CP Instrukcja

12 Października 2024

Muse M-178 P Instrukcja

10 Października 2024

Sencor SIR 5000WDB Instrukcja

10 Października 2024
