Sunding Bicycle Computer
SD-536B (14Functions)
FUNCTIONS
- SPD CURRENT SPEED
- ODO ODOMETER 0.00 99999km/m) （ 1～
- DST TRIP DISTANCE
- MXS MAXIMUM SPEED
- AVS AVERAGE SPEED
- TM ELAPSED TIME
- CLK CLOCK 12H/24H （ ）
- SCAN
- ” ” COMPARATOR “+ “－
- SETTING SPEED SCALE km/h,m/h （ ）
- SETTING TYRE CIRCUMFERENCE : (0mm ～
9999mm)
- SETTING THE LAST VALUE OF
ODOMETER/ODO
- FREEZE FRAME MEMORY
- AUTO ON/OFF
Battery Installation
Remove the battery cover from the bottom of the computer
by using a at blade screwdriver, install an AG13 battery
with the positive (+) pole facing the battery cover and
replace the cover. Should the LCD show irregular gures,
take out the battery and re-install it.
Speedometer Sensor
Attach the speedometer sensor
bracket to the left fork blade,
using the shims to adjust the
diameter, and using the cable
ties to tie it with the fork.
Position the sensor and magnet
as shows; make sure that the arc of the magnet intersects the
alignment mark on the sensor with 1mm clearance.
Mounting Shoe
Attach the mounting shoe with the
cable ties to the handlebar; adjust
the mounting shoe on the handlebar
with the shims to hold its position
.
Sensor Wiring
Route the sensor wire up the fork
blade, using cable ties to secure it
at the bottom and crown to avoid it
hinder the movement of the front wheel.
Computer
Attach the computer to the mounting shoe by sliding the
unit until it snaps rmly into its position. To remove it,
press the button on it in the opposite direction. To check for
proper speed function and sensor alignment, spin the front
wheel with computer in speed mode. Adjust the position of
sensor and magnet when there is no or weak reaction.
Wheel Size Input
‘2060’ appears on the screen when the battery has been
installed, with one gure ashing, choose the correct wheel
circumference from the table below. Press RIGHT button to
advance digits as needed and LEFT button to conrm and
advance. (The circumference ranges 0mm 9999mm),press ～
LEFT button to enter KM/M mode.
TIRE SIZE
CIRC TIRE SIZE CIRC
700c x 38mm
2180 26” x 2.25” 2115
700c x 35mm
2168 26” x 2.1” 2095
700c x 32mm
2155 26” x 2.0” 2074
700c x 30mm
2145 26” x 1.9”/1.95” 2055
700c x 28mm
2136 26” x 1.75” 2035
700c x 25mm
2124 26” x 1.5” 1985
700c x 23mm
2105 26” x 1.25” 1953
700c x 20mm
2074 26” x 1.0” 1913
700c Tubulari
2130 24” x 1.9”/1.95” 1916
650c x 23mm
1990 20” x 1-1/4” 1618
650c x 20mm
1945 16” x 2.0” 1253
27” x 1-1/4”
2161 16” x 1.95” 1257
27” x 1-1/8”
2155 16” x 1.5” 1206
26” x 2.3” 2135
Setting（
（（
（ ）km/h））
） （/（（
（ ）m/h））
）
Press the RIGHT button to choose km/h or
m/h. Press the LEFT button to enter the
CLOCK mode.
CLK Mode(12H/24H)
In CLOCK Mode, press the LEFT button
for 3 seconds to enter 12/24H selection.
Re-press the LEFT button for 12/24
exchanging. Press the RIGHT button to
enter Hour setting mode, when the gure
indicating HOUR start to ash, press the LEFT button to
adjust it.
Continue to press the RIGHT button to enter Minute setting
mode, when the gure indicating MINUTE start to ash,
press the LEFT button to adjust it and RIGHT button to
conrm, press the RIGHT button again to enter
Mileage(ODO) mode.
Setting the Last value of Odometer
In ODO mode, pres s the LEFT bu tton for 2 se conds
to set th e ODO value, its initial value is 0000 .0.
when one figure flashing , press RIGHT butt on to
adjust it and LEFT bu tton to confirm it, and start to
set the next figure.(after re-install the battery, latest
value can be inputted accord ing to th e valu e exists
before the battery is re-installed).
Reset of Mileage Parameter
Press and hold both RIGHT and LEFT button
simultaneously for 3 seconds to clear the circumference and
(km/m) setting. The user need to reset the tyre
circumference and (km/m), the original ODO value and
CLOCK will remain unaffected.
Speedometer
Speed is shown all the time on the
screen, its maximum reading is
99.9km/h (m/h), and it’s accurate to +/-
0.1km/h (m/h).
Speed Comparator
During riding , ‘+’and ‘－’ indicates the current speed
is higher or lower than average speed(AVS) .
Odometer
In ODO mode , the total distance is
indicated on the screen, its mileage range
is 0.00 99999km(m). The display will 1～
be back to 0 when value exceeds its
maximum limit, press the RIGHT button
to enter DST mode.
Trip Distance (DST)
In DST mode, the distance for one trip is
indicated on the bottom line. DST
ranges 0 9999km(m), when the value ～
exceed the range limit, it restarts from 0
automatically. Both the time and the
distance will be cleared when the time of one trip exceed the
range limits.
press the LEFT button for 5 seconds to clear the records of
DST,MXS,AVS,TM.
Press the RIGHT button to enter MXS mode.
Maximum Speed (MXS)
In MXS mode, maximum speed is
indicated on the bottom line. Press the
LEFT button for 5 seconds to clear the
records of MXS,DST,AVS,TM.
Press the RIGHT button to enter AVS
mode.
Average Speed
In AVS mode, average speed is indicated
on the bottom line. Press the LEFT
button for 5 seconds to clear the records
of AVS,DST,MXS,TM.
Press RIGHT button again to enter TM
mode.
Trip Time
In TM mode, trip time is indicated on the
bottom line.TM ranges 0 :00 :00 ～
99:59 :59. It will be back to 0 when value
exceed the limits.
Press the LEFT button for 5 seconds to
clear the records of TM, DST, MXS and AVS.
Press the RIGHT button to enter SCAN mode.
SCAN
In Scan mode , DST, MXS, AVS and TM mode are
indicated in turn every 4 seconds.
Press the RIGHT button to enter CLOCK Mode.
Sleep Mode
If no signal has been inputted for 300 seconds, computer
will enter into Sleep Mode, CLK value remains. It will turn
back to the former mode with all the data collected then
when any signal is inputted or any button is pressed.
FREEZE FRAME MEMORY
Press the LEFT button in any time will enter into freeze
frame memory mode. Flashing TM data will appear on the
screen. Press the RIGHT button to view the records of
DST,MXS,AVS and TM.
Press the LEFT button to end it.
Buttons Instruction
Press the RIGHT button to choose any mode below :
ODO, DST, MXS, AVS, TM, SCAN（ 、DST MXS AVS、 、
TM and CLOCK. It’s unnecessary to press the LEFT ）
button except choosing the Freeze frame Memory mode.
In Freeze Frame Momery mode, press the RIGHT button,
several data will display, re-press LEFT button to turn back
to other modes.
Malfunctions and Problems
Malfunctions Problems
No speedometer Improper magnet/sensor alignment
Inaccurate value is
indicated
Improper input, such as wheel
circumference.
Slow d isp lay
resp onse
Temperature exceeds operating
limits(0℃～ ℃55 ).
Black display
Temperature too high, or put in
direct sunlight for too long time,
need to take back to shadow for a
period.
Weak display Poor battery contact or dead battery
Display shows
irregular gures
Take out battery and reinstall it after
10 seconds.
