Connection method
1. Download the Joycune APP iPhone OS and search Lite sports in the Apple Store to select Lite version and click Download. Android version may
search it in the 360, Mi, and Huawei apps, and download Lite sports.
2. Click the Joycune sports icon to enter the registration page, log in it with the mobile phone or QQ or WeChat.
3. After successful login, click the “My” menu in the lower right corner, and click the device icon in the “My” menu to enter the Device Add page.
4. On the Device Add page, click Scanning Device under the smart code table.
5. Long press SET+MODE button for 3 seconds in any interface of code table to enter the mobile phone connection page, and then long press
the right button for 3 seconds to start connecting to the phone.
6. After the mobile phone connection is successful, the view data is appeared in the APP smart code table. Click the code table name, and the
parameter setting pops up at the bottom.
7. Click the parameter setting to enter the code table parameter setting page to set all parameters and functions of code table. The time and
date adopts the default value of mobile phone. After the setting is completed, click “Complete Write-in” in the upper right corner to change
the data of code table.
Instructions for connection of Joycune APP
and Bluetooth code table
Sweep and download
Register or log in with a third party
Register according to the prompt
Click "Mine" after successful login
Click " BLE Device”
Click on "Scanning Device" in
the column of smart code table. Long press the MODE button of
code table for 3 seconds on any
interface to start the Bluetooth
code table broadcast mode.
After the name of Bluetooth code
table appears, click name.
Continue to click the device
name after connecting.
Click "Parameter Settings" to set
parameters of code table.
www.joycune.com
Set parameters according to needs
Slide up more settings When setting is complete,
click “write Device”.
Click "Down Data" to set
parameters of code table.
Click to read data
Set parameter description
The time and date adopts the current default of mobile phone.
The operating mode is divided into main mode and slave mode.
Main mode: The code table is connected to the main equipment and
the accessories, and the riding data is uploaded to mobile phone
after collection.
Slave mode: Mobile phone and accessories are connected. The
motion data generated by the code table GPS and accessories are
transmitted to the code table and displayed on the screen. As the
slave unit of mobile phone, the code table only performs the display
function, and does not participate in other motion data collection
outside of total mileage and total time.
Code table parameter setting
Click the language menu to pop up menu to select Chinese, English,
German, French, Italian, Spanish, Swiss and Dutch.
Click the weight unit to pop up menu to select the kg/lb unit.
Click the weight to pop up menu to set the value of body weight.
The weight is 65kg in default, and the setting range is 0-299kg.
Click the wheel circumference to pop up menu to set the wheel
circumference, and select the required circumference according to
the bicycle tire model and comparison table. Setting range is:
0000mm~4999mm.
Click the wheel circumference unit to pop up menu for setting.
Set the bicycle's transmission parameters according to the riding.
The code table will calculate the gear ratio and recommend
parameters of chain wheel and free wheel according to riding speed
and the cadence.
Click the temperature unit to pop up menu to select the Celsius/
Fahrenheit unit.
Click the mileage countdown to pop up menu to set the mileage
countdown. The setting range is 0~999.99km/mile.
Click the time countdown line to pop up menu to set the time
countdown, and the setting range is 0~99:59 hours.
Excess-value alarm setting
Set a heart rate maximum value when the heart rate exceeds the
maximum value. The heart symbol flickers to prevent the heart
from being damaged by a high heart rate.
The optimum cadence is 75~95/min. When a maximum value is
set, the cadence symbol flashes and jumps after the current cadence
exceeds the setting value.
Click the vehicle inspection mileage to pop up menu to set the
vehicle inspection mileage. The default value of vehicle inspection
mileage is 200, and the setting range is 200~899KM.
Menu
Click the menu cycle to pop up menu to set the menu cycle. All
functions can be set to join or exit the cycle mode. The menu that is
added to cycle mode can cycle and display in 4s, and blanked
menus must be blanked before they can be added to cycle mode.
Click the menu blanking to pop up menu to set the menu blanking.
According to use condition, undesired menus can be blanked. The
blanked menu does not display, but the data from the riding will be
recorded in the background. The first page of panoramic display
cannot be blanked.
Panoramic Display Mode allows for the selection of up to three
different functions to be displayed concurrently on the screen.
First function is displayed by default, while second and third are
hidden by default.
Date and time
Operating mode
Language
Weight unit
Weight unit
Wheel circumference
Wheel circumference unit
Transmission
Temperature unit
Distance Countdown Setting
Time Countdown Setting
Excessive heart rate alarm
Excessive cadence alarm
Maintenance Distance
Menu Cycle
Menu Hidden
Panoramic Display
Initial Value Set
Click the initial distance to pop up menu to set the initial distance,
and the setting range is 0~99999 km/mile.
Initial distance
Initial Time
Click the initial time to pop up menu to set the initial time, and the
setting range is 0~99999 hrs.
www.joycune.com
Instructions for connection of Joycune APP
and Bluetooth code table
