Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: January 16, 2023 9:41 AM
Product ID
109B-USBC-HDMI
Component Function
1HDMI Output 1 • Connect to an HDMI Display
2HDMI Output 2 Connect to an • HDMI Display
3USB-C Host Connection Connect to a • USB-C Enabled Computer
4USB-C to USB-A Adapter • Connect to the to use USB-C Host Connection
with a USB-A Enabled Computer
5Power Delivery Pass-
through Port
• Connect a USB-C Power Adapter
• USB Power Delivery 3.0 (up to 100W, with up to
90W available for host charging)
USB-C/USB-A to Dual HDMI - 4K 60Hz - 100W Power Delivery
Requirements
For the latest drivers/software, technical specications, and declarations of
conformance, please visit: www.StarTech.com/109B-USBC-HDMI
Package Contents
• USB-C/USB-A to HDMI Adapter x 1
• Quick-Start Guide x 1
Driver Installation
Installation is automatic for Windows 10 & up, and ChromeOS. If the drivers do
not auto-install, contact your IT administrator. If you are using macOS or another
supported operating system, the latest drivers are available at:
www.StarTech.com/109B-USBC-HDMI
Note: Operating system requirements are subject to change. For the latest
requirements, please visit: www.StarTech.com/109B-USBC-HDMI
Installation
Installing the Video Adapter
1. (Optional) Connect a (up to 100W) from an to the USB-C Power Adapter AC Outlet
USB-C Power Delivery Pass-through Port, USB Video Adapterlocated on the , to
charge the host computer.
Note: A with on the host is required for PD Pass-through USB-C Port Power Delivery
to charge the host. When using the to connect to a USB-C to USB-A Adapter USB-A
Host, PD Pass-through is not available.
2. Connect the to an available on the USB Host Connection USB-C or USB-A Port Host
Computer.
3. Connect an (sold separately) from the on the HDMI Cable HDMI Output 1 USB
Video Adapter HDMI Display, to an .
4. Connect an (sold separately) from the on the HDMI Cable HDMI Output 2 USB
Video Adapter HDMI Display, to an .
5. Arrange the display using the operating system’s .Display Settings
1
2
3
4
5
Regulatory Compliance
FCC - Part 15
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could
void the user’s authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two
conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
Warranty Information
This product is backed by a three-year warranty.
For further information on product warranty terms and conditions, please refer to www.startech.com/warranty.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)
for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss
of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the
product. Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the
limitations or exclusions contained in this statement may not apply to you.
FR: startech.com/fr
DE: startech.com/de
ES: startech.com/es
NL: startech.com/nl
IT: startech.com/it
JP: startech.com/jp
StarTech.com
Ltd.
45 Artisans Cres
London, Ontario
N5V 5E9
Canada
StarTech.com Ltd.
Unit B, Pinnacle 15
Gowerton Rd,
Brackmills
Northampton
NN4 7BW
United Kingdom
StarTech.com LLP
4490 South Hamilton
Road
Groveport, Ohio
43125
U.S.A.
StarTech.com Ltd.
Siriusdreef 17-27
2132 WT Hoofddorp
The Netherlands
