SB573 Quick Start Guide & User Manual
FEATURES
PRODUCT FEATURE
IN THE BOX
• SB573 Wireless Stereo Speaker
• MicroUSB Charging Cable
• 3.5mm Audio Cable
• User Guide
Wireless
Crystal Clear
Sound
Deep Bass HD
Built-In
Microphone
Up to 12 Hrs
Playback Time
Built-in 3.5 AUX
CHARGING YOUR SPEAKER
SAFETY INSTRUCTIONS
All trade names are registered trademarks of respective manufacturers listed.
All rights reserved.
Keep the unit away from heat sources direct sunlight, humidity, water and any other
liquids. Do no operate the unit if it has been exposed to water, moisture or any other
liquids to prevent electric shock, explosion and/or injury to yourself and damage to
the unit.
Do not use the unit if it has been dropped or damaged in any way.
Do not puncture or disassemble the exterior surface of the product in any way.
Keep the unit free from dust, lint, .. etc. Do not use this unit for anything other
than it’s intended use or purpose.
Keep the product out of reach of children. Do not use the speaker at excessive
volume level as it may damage hearing.
Do not expose batteries or battery pack to excessive heat, such as direct
sunlight or open flame.
www.SoundBot.com
CONTROLLING YOUR MUSIC
ANSWERING CALLS
USING THE LINE-IN AUDIO JACK
If your media device is not Wireless enabled, SB573 can still be connected to
SB573 via 3.5m line-in audio jack.
Tips: TALK, PLAY/ PAUSE, PREVIOUS & NEXT, only work when SB573 is
connected wirelessly. In case of wired connection, the soundtrack
can only be controlled from the media player device.
BATTERY STATUS ON IPHONE AND IPAD
When the speaker is connected to iPhone/iPad via Wireless, the battery status of
the speaker can be displayed on the iPhone/iPad screen.
SPECIFICATIONS
Wireless Version: 3.0
Wireless Transmission Distance: 10 meters
Supporting Profiles: AVRCP, A2DP, Hands-Free Profile (HFP)
and Headset Profile (HSP)
Frequency Range: 2.4-2.48Ghz
Output Power: 2x3 Watts
Distortion: ≤ 1.0%
Frequency Response: 180Hz-20Khz
Microphone Sensitivity: -40dB
Playback Time: Music Time up to 6 hours, Talk Time up to 10 hours
Charging Input Power: DC 5V (MicroUSB)
Battery Charging Time: 3 hours
Dimensions: 145 x 45 x 60MM
Weight: 320g
SB573 can function as a portable speakerphone for incoming calls when
connected wirelessly.
To answer a call - Press the button.
To end a call - Press the button again.
To make a new call - Dial the number and press the send button on your mobile
phone, the call is automatically transferred to the speaker.
To refuse an incoming call - Double clicking the button.
To re-dial the last number called - Double clicking the button.
Before the initial first use, please charge the speaker for full 3 hours
The LED indicator light will turn red when it is being charged and go off when it’s
fully charged.
PAIRING YOUR DEVICE
1. Be sure that SB573 is fully charged.
2. Turn on Wireless connectivity of your Wireless enabled media device,
such as iPhone, iPad, iTablet, Smartphone, Computers...etc. And set
the media device to be “visible” or “discoverable.”
3. Turn on SB573 by switching the power button on the back of the speaker.
4. After turning on the SB573, the LED lights will alternate between red and blue to
indicate that the speaker is in “pairing mode.”
5. Choose “add new Wireless device” or “setup Wireless device” on your media
player device to search for Wireless devices. Select SB573 to pair and connect.
6. If the pairing attempt fails or times out (roughly 3 minutes), delete all the paired
devices from the paired Wireless devices on your media player and reboot both
device before repeating pairing process from step 2 to 6 again.
7. Once paired successfully, the LED indicator lights will turn blue and blink twice
every 3 seconds.
8. If pairing with another Wireless enabled device is required, press the Play/Pause
button for 3 seconds, the speaker will be disconnected from the previous paired
Wireless device, followed by an alert tone “paring.” then you can repeat
the paring process again (Steps 2-6)
9. Repeat step 2 to step 6 again to pair with the new Wireless enabled media
player device such as tablet, smartphone, iPhone, computer,...etc.
USING SIRI
When the speaker is connected to an iPhone/iPad via Wireless, press and hold the
TALK button for 3 seconds to activate the SIRI function on iPhone/iPad. Then talk
to the speaker after hearing “SIRI” alert.
Tips:
1. iPhone/iPad may not be able to recognize speech commend with noisy
background.
2. SIRI may not work if iPhone/iPad is not connected to the internet.
Do not expose the speaker to liquid, moisture, or humidity to avoid damage to
the products internal
Do not expose the speaker to extremely high or low temperatures as this may
shorten the life of the electronic device, destroy the battery, and/or distort certain
plastic parts.
Do not dispose of the speaker in fire as they circuitry may explode.
Avoid using SB573 with sharp objects, as it may cause scratches and damages.
Do not attempt to disassemble the speaker.
CARE AND MAINTENANCE
Once SB573 speaker is connected to a Wireless enabled device,
press the or button to skip to the next soundtrack or play
the previous soundtrack.
Press and hold the or button on the speaker to increase/
decrease the volume on the speaker.
Press the button on the speaker to start or pause songs.
Note: To reach the maximum or minimum volume, please adjust
the volume from both the wireless enabled media device's
volume control and SoundBot SB573 wireless speaker.
Volume up/ Next track
Volume down/ Pevious track
Press once
to switch
between
wireless and
TF card.
Play/ Pause/ Phone
AUX input
MicroUSB charging port
M
/
/
M
TF card slot
