Quick Start Guide

You Should Have

The following item should be included in your product package:

• One Allegro USB-C PCIe adapter card

• One low-proﬁle mounting bracket

• Quick Start Guide

The following may be required for installation:

• Medium Phillips screwdriver

System Requirements

Allegro USB-C PCIe card requires the following in order to

operate in your system:

• One available PCI Express slot

Computer Compatibility

• Mac Pro® (3,1, 4,1, 5,1, or 7,1 [2019])

• Windows® computer with PCIe slots

• Linux® computer with PCIe slots

OS Compatibility

• macOS 10.10.5, 10.12.6+; not compatible with macOS 10.11

• Windows® 10, 8.1, 7

• Windows Server 2016, 2012, 2008 (64-bit editions)

• Linux Kernel 5.0+

Thunderbolt™ Compatibility

• Mac®, Windows, or Linux computer via a Thunderbolt 2 or

Thunderbolt 3 to PCIe card expansion system (not compatible

with Thunderbolt 1 to PCIe card expansion system)

• macOS 10.12.6+

• Windows 10 (64-bit Edition Version 1809 or newer)

Supported Cables

You may use the following cable types with this product:

• USB-C 10Gbps

• USB-C 5Gbps

• Thunderbolt 3 40Gbps (0.5- or 0.7-meter only)

• Thunderbolt 3 20Gbps

Remember to register your product online at https://registration.sonnettech.com to be informed of future upgrades and product releases.

Software updates and links are available from the Sonnet Web site at https://www.sonnettech.com.

Sonnet Technologies Customer Service hours are Mon.-Fri., 9 a.m.–5 p.m. Pacific Time • Customer Service Phone: 1-949-472-2772 • E-mail: support@sonnettech.com

Sonnet Technologies, Inc., California USA • Tel: 1-949-587-3500

ALLEGRO™ USB-C® PCIe®

Dual-Port SuperSpeed USB-C 10Gbps PCIe 3.0 Adapter Card With USB-C Charging

Support Note: This document was up to date at the

time of printing. However, changes to the hardware or

software may have occurred since then. Please check the Sonnet

Web site for the latest documentation.

1. Go to https://www.sonnettech.com/support/kb/kb.php

2. Click the Computer Cards link.

3. Click the PCIe Cards link.

4. Click the Allegro USB-C PCIe link, and then click the Manual

link.

5. Click the Allegro USB-C PCIe Quick Start Guide [English] link,

and then check the Document Version information. If the

version listed is later than this document (this is version E),

click the Download Now button for the latest version.

Hardware Installation Steps—All Users

This section covers the installation of the Allegro USB-C PCIe card

into your computer or Thunderbolt-to-PCIe expansion chassis.

1. Shut down your computer or Thunderbolt-to-PCIe expansion

chassis, and then open it to access the expansion card area

(PCIe slots); refer to the user’s manual for speciﬁc information.

2. Locate an available PCIe slot and remove its access cover.

3. Remove the Sonnet card from its packaging, and then install

it into the PCI Express slot; make sure the card is firmly

seated and secured.

4. Close the computer or Thunderbolt-to-PCIe expansion chassis.

Driver Information

For Mac users, the standard drivers that enable the Allegro card

to work in your computer or Thunderbolt expansion chassis are

installed as part of macOS 10.10.5, and 10.12.6 and later; the

Allegro card is ready to use when you power on your computer.

For Windows users, the drivers that enable the Allegro card to work

in your computer running supported versions of Windows except

Windows 7 (32- and 64-bit versions) are installed automatically.

For Windows 7 users, please go to https://www.sonnettech.com/

support/kb/kb.php, click the Computer Cards link, and then the

PCIe Cards link. Locate and click Allegro USB-C PCIe link, and

then click the Driver link. Locate, download, and install the appro-

priate drivers. For all other users, update Windows to the latest ver-

sion to ensure full support and performance.

For Linux users, the drivers that enable the Allegro card to work in

your computer running Linux Kernel 5.0 and later are installed

automatically; the Allegro card is ready to use when you power

on your computer.

Allegro USB-C PCIe Quick Start Guide

Known Limitations and Advice—All Users

USB peripherals have some limitations you should be aware of,

and we have listed some additional advice here. Refer to the

peripheral manufacturers’ Web sites for more information.

• USB 3.2 (formerly 3.1) devices come in two varities, Gen 1 and

Gen 2. Gen 1 devices support data transfer speeds up to 5Gbps,

while Gen 2 devices (such as this Sonnet adapter card) support

data transfer speeds up to 10Gbps.

• The use of USB-C to USB-A cables is supported, but data transfer

speeds are limited to the speeds supported by the device and

cable.

• 1-meter or longer Thunderbolt 3 (40Gbps) cables DO NOT

support USB 3.0 (3.1 Gen 1 and 3.2 Gen1) by design, only

Thunderbolt 3 & USB 2.0.

• The Allegro USB-C PCIe card does not support Thunderbolt 3

only peripheral devices, even though they use the same

connector. If the peripheral device only has the Thunderbolt

icon ( ) next to its port(s), or on the connector of an attached

cable, it will not work with the Sonnet card.

• Many peripherals require additional drivers and application

software to operate or have full functionality. Software should

be included with the device, or available to download from the

manufacturer’s Web site. Check the peripheral’s user’s manual

for information about necessary software.

• While your computer is on, always “eject”, “stop”, “unplug”,

or “put away” any drive (hard drive, SSD, etc.) before

disconnecting it from its cable or the Sonnet card.

• While your computer is on, always “eject” any memory card

before removing it from the USB card reader, or disconnecting

the card reader (with the card inserted in it) from its cable or

the Sonnet card.

• Disconnecting drives while they are transferring or receiving

data, may result in damage to the ﬁle(s) being transferred or

cause your system to hang.

• Although many peripherals may draw power directly from the

Sonnet card, other devices require an external power source.

Remember to use external power supplies when necessary.

Support Note: When handling computer products, you

must take care to prevent components from being

damaged by static electricity. Before opening your computer

or removing parts from their packages, always ground yourself

first by touching a metal part of the computer, such as a port

access cover, and work in an area free of static electricity; avoid

carpeted areas. Handle all electronic components by their edges,

and avoid touching connector traces and component pins.
