Strona 1/4
1
MobileCam/Light (Plus)
Quick Installation Guide
System Requirements
• Pentium-class notebook or desktop computer with an
available USB port
• Windows 98/98SE/ME/2000/XP
Package Contents
• One MobileCam/Light or MobileCam/Light Plus (with base)
• One Driver/Utility CD
• This quick installation guide
Serial # Sticker
For future product return or exchange, this serial # is required.
Please keep it for your reference.
04-0258B
Software Installation
Important: Make sure the driver is installed before connecting
the MobileCam to the USB port. If prompted for Windows
Installation CD, please insert it and follow on-screen instructions.
Windows 98/98SE Driver Installation
1. Boot up to Windows and insert the driver CD.
2
2. Click Start, Run, then Browse. Browse your CD-ROM
drive, Driver & Utilities folder, then double click
Setup.exe. Click OK to start installation.
3. During installation, you'll be prompted for additional files.
Please point to your CD-ROM drive\Driver &
Utilities\Application folder for this file.
4. Restart Windows when prompted to complete installation.
Windows ME/2000/XP Driver Installation
1. Boot up to Windows and insert the driver CD.
2. Click Start, Run, then Browse. Browse your CD-ROM
drive, Driver & Utilities folder, then double click
Setup.exe. Click OK to start installation.
3. Follow on-screen instructions and restart Windows to
complete driver installation.
Installing Ulead Photo Explorer 7.0 SE utility
Ulead Photo Explorer combines easy to use tools for acquiring,
viewing, organizing, adjusting, and sharing digital images. The
manual for this utility can be found in the Ulead Photo Explorer
7.0SE folder of the driver CD.
1. Boot up to Windows and insert the driver CD.
2. Click Start, Run, then Browse. Browse your CD-ROM
drive, Ulead Photo Explorer 7.0SE folder, then double
click Setup.exe. Click OK to start installation.
3. Follow on-screen instructions and enter the serial number
when prompted to complete installation.
Connecting the MobileCam
Important: Make sure the driver is installed before connecting
3
the MobileCam to your system.
For the MobileCam/Light model
1. Plug the MobileCam into an available USB port and the
driver will automatically install.
2. Press the button on top of the MobileCam to activate the
video mode. Make sure Preview (located under Option) is
checked.
Note: You can also activate the video mode by clicking
Start/Programs/Icm532, then AMCAP. However,
activating the video mode this way doesn't give you
option for Snapshot.
3. To capture, click Capture, then Start Capture.
4. To take a snapshot, either click Snapshot or press the
button on top of the Mobile Cam.
For the MobileCam/Light Plus model
1. Connect one end of the included cable to the base and the
other end to an available USB port. Plug the MobileCam
into either USB port on the base and the driver will
automatically install.
Note: There are two USB ports on this base, but only one
port has USB functions, the other port provides power for
devices that only draw power from the USB bus. This is
all automatic.
2. Steps 2, 3, and 4 are the same as the MobileCam/Light
model.
Important: The MobileCam can also be connected directly to the
system's USB port instead of going through the base.
