INSTALLATION INSTRUCTIONS
Product
Revision
Form
If you need assistance or have questions, call Gamber-Johnson at 1-800-456-6868
Printing Spec:
PS-001
GETAC- RX10H MEDICAL DOCK
7160-0880
This instruction sheet is for the RX10H docking station only. For instructions on
features, set-up, and operation of the RX10 computer, please refer to the manual
provided by Getac with the computer.
This docking station is designed to be used with a variety of Gamber-Johnson
mounting systems. Installation instructions for other Gamber-Johnson products
are provided with each individual product.
This instruction sheet is for the following products:
For Vehicle Mounting Applications (M4 X 0.7 Mounting Hardware):
Item No. 7160-0880-00 DOCK - GETAC - RX10H -No RF
Item No. 7160-0880-03 DOCK - GETAC - RX10H -Tri-RF
Conduct a "Bench Test"
Gamber-Johnson strongly advises a "bench test" be conducted to verify all
electronic and software issues are resolved prior to installation:
Make sure the computer is operational by itself.
1.
Insert computer into the docking station and verify that the computer is
2.
operating in the dock.
Interconnect entire assembly and verify start-up of all components,
3.
including other equipment (printers, modems, scanners, etc.)
Gamber-Johnson recommends positioning of all mounts and equipment in the
vehicle prior to the actual install to verify that mounting locations are safe and
practical.
PRE-INSTALLATION RECOMMENDATOINS
During Installation:
DO NOT
connect this docking station to the vehicle battery until:
All other electrical connections are made
1.
Mounting of all components is complete
2.
Verification that no shorts exist in the entire system
3.
DO NOT
install equipment or route wiring or cords in the deployment path of any air bag.
When drilling into the vehicle, DO make sure that both sides of the surface are clear of
anything that could be damaged.
CAUTION:
If wiring is shorted to the frame, high current conductors can cause hazardous
sparks resulting in electrical fires or flying molten metal.
After installation:
Test the docking station to ensure that it is working properly.
File these instructions in a safe place and refer to them when performing maintenance or re-
installing.
WARNING
: Failure to follow all safety precautions and instructions may result in property
damage, serious injury, or death.
Safety is dependent on the proper installation and servicing of this docking station. It is
important to read and follow all instructions before installing this product.
To properly install a Gamber-Johnson docking station you must have a good understanding of
automotive electrical procedures and systems, along with proficiency in the installation and
service of aftermarket vehicle equipment.
There are no adjustments required at any time of the electrical components within the
docking station.
Opening the docking station will void the product warranty.
IMPORTANT SAFETY INFORMATION FOR INSTALLERS
2/5
Thumb Knob
Latch
Lock
Through Holes
for mounting to
a wall
Guide Pins
Docking Connector
Triangle Alignment Mark
TRI-RF
Connector
GPS
WLAN
WWLAN
VGA PORT
Ethernet
19 Vdc Input
(1) USB 3.0
HDMI
(3) USB 2.0
Part#/Serial #
Label
Vesa 75mm Hole Pattern
M4 X 0.7 Threaded Inserts
Warranty Label
Port Identification Label
Cable Restraint Bracket
RX10H DOCKING STATION FEATURE IDENTIFICATON
