Strona 1/18

1K/2K/3K Online UPS

Uninterruptible Power Supply System

User Manual

Table of Contents

1. Important Safety Warning ............................................................................................... 1

1-1. Transportation ..................................................................................................... 1

1- Preparation 2. ......................................................................................................... 1

1-3. Installation .......................................................................................................... 1

1-4. Operation ............................................................................................................ 1

1-5. Maintenance, service and faults ............................................................................ 2

2. Installation and setup ..................................................................................................... 3

2-1. Rear panel view ................................................................................................... 3

2-2. Setup the UPS ..................................................................................................... 4

3. Operations ..................................................................................................................... 6

3-1. Button operation .................................................................................................. 6

3-2. LCD Panel ........................................................................................................... 6

3-3. Audible Alarm ...................................................................................................... 8

3-4. LCD display wordings index .................................................................................. 8

3-5. UPS Setting ......................................................................................................... 8

3-6. Operating Mode Description ............................................................................... 11

3-7. Faults Reference Code ........................................................................................ 11

3-8. Warning indicator .............................................................................................. 12

4. Troubleshooting ............................................................................................................ 13

5. Storage and Maintenance .............................................................................................. 15

6. Specifications ............................................................................................................... 16

1. Important Safety Warning

Please comply with all warnings and operating instructions in this manual strictly. Save this

manual properly and read carefully the following instructions before installing the unit. Do not

operate this unit before reading through all safety information and operating instructions

carefully

1-1. Transportation

 Please transport the UPS system only in the original package to protect against shock

and impact.

1-2. Preparation

 Condensation may occur if the UPS system is moved directly from cold to warm

environment. The UPS system must be absolutely dry before being installed. Please

allow at least two hours for the UPS system to acclimate the environment.

 Do not install the UPS system near water or in moist environments.

 Do not install the UPS system where it would be exposed to direct sunlight or near

heater.

 Do not block ventilation holes in the UPS housing.

1-3. Installation

 Do not connect appliances or devices which would overload the UPS system (e.g. laser

printers) to the UPS output sockets.

 Place cables in such a way that no one can step on or trip over them.

 Do not connect domestic appliances such as hair dryers to UPS output sockets.

 The UPS can be operated by any individuals with no previous experience.

 Connect the UPS system only to an earthed shockproof outlet which must be easily

accessible and close to the UPS system.

 Please use only VDE-tested, CE-marked mains cable (e.g. the mains cable of your

computer) to connect the UPS system to the building wiring outlet (shockproof outlet).

 Please use only VDE-tested, CE-marked power cables to connect the loads to the UPS

system.

 When installing the equipment, it should ensure that the sum of the leakage current of

the UPS and the connected devices does not exceed 3.5mA.

1-4. Operation

 Do not disconnect the mains cable on the UPS system or the building wiring outlet

(shockproof socket outlet) during operations since this would cancel the protective

earthing of the UPS system and of all connected loads.

 The UPS system features its own, internal current source (batteries). The UPS output

sockets or output terminals block may be electrically live even if the UPS system is not

connected to the building wiring outlet.

 In order to fully disconnect the UPS system, first press the OFF/Enter button to

disconnect the mains.

 Prevent no fluids or other foreign objects from inside of the UPS system.

Specyfikacje produktu

Marka:	FSP/Fortron
Kategoria:	UPS
Model:	Knight KN-1103TS Tower
Kolor produktu:	Czarny
Typ wyświetlacza:	LCD
Wysokość produktu:	318 mm
Szerokość produktu:	119 mm
Głębokość produktu:	419 mm
Waga produktu:	28000 g
Czas ładowania:	4 h
Poziom hałasu:	50 dB
Certyfikaty:	IEC 62040-1\r\nIEC-62040-2\r\nCE
Napięcie operacyjne wejścia (maksymalne):	300 V
Pojemność baterii:	9 Ah
Wydajność:	90 %
Zakres temperatur (eksploatacja):	0 - 40 °C
Zakres wilgotności względnej:	20 - 90 %
Układ:	Tower
Częstotliwość danych wejściowych:	47/63 Hz
Diody LED:	Tak
Rodzaj chłodzenia:	Aktywne
Liczba baterii:	6
Napięcie baterii:	12 V
Moc rzeczywista:	2400 W
Maksymalna możliwa do konfiguracji moc:	3 kVA
Napięcie operacyjne wejścia (minimalne):	110 V
Napięcie operacyjne wyjścia (maksymalne):	208 V
Napięcie operacyjne wyjścia (minimalne):	240 V
Słyszalny alarm:	Tak
Ilość gniazd sieciowych:	7 x gniazdo sieciowe
Typy wyjść AC:	C13 coupler, C19 coupler
Typowy czas podtrzymania przy połowie obciążenia:	- min
Typowy czas podtrzymania przy pełnym obciążeniu:	- min
Wtyczka:	C20 panel
Współczynnik mocy:	0.99
Liczba faz wejściowych:	1
Poziom THD prądu wyjściowego:	2 %
Przebieg falowy:	Sinus
Regulacja napięcia wyjściowego:	1 %
Współczynnik mocy wyjściowej:	0.8
Współczynnik szczytu:	3:1
