Professional On-Line & Line-Interactive UPS Solutions

True Double Conversion 1.0kVA - 20kVA & 30kVA - 800kVA

Output Power Factor 0.9 - Rack/Tower 2 in 1 Design - LCD Display - Perfect Battery Pack

IndusPower Online UPS Systems

40kVA/60kVA/80kVA with battery bank solution, 3-Phase Input / 3-Phase Output

Induspower Series, applied with state-of-the-art PWM-transformerless technology, can easily adapt to all kinds of diverse and

complicated loads, such as the non-linear systems (IT systems), strongly inductive or capacitive loads, discharge lamps, and

induction motors. It is designed in terms of criteria of maximum efficiency and energy savings with highly compact format. Each

unit also has a wide range of communication possibilities and a large variety of options to fill out customers’ diverse inquiries. To

facilitate expansion easily, this unit can be set up in parallel-redundant systems without any need for additional hardware in the

near future.

Features & Advantages

●

Online double conversion technology with DSP control

Advanced control with Adaptive Feed Forward Cancellation (AFC) technology for very low harmonic

distortion

Very low input current distortion (THDi < 1%)

Input power factor 0.99 at 10% load

Output efficiency up to 95%

Space-saving compact design

Over 60% materials recyclable

Front access makes maintenance and replacement easily

Highly flexibility in single phase/ three-phase set-UPS

Parallel redundant operation with up to 4 units

Variety of communications and options available

Remaining backup time calculation

Induspower Series

40 / 60 / 80 kVA

Battery Bank Battery Bank Size (mm) Battery Capacity Battery Brand

BB-744/18T 1150 x 470 x 1190 744V / 18Ah Yuasa

BB-744/26T 780 x 880 x 1190 744V / 26Ah Yuasa

BB-744/65T 1500 x 900 x 1370 744V / 65Ah Yuasa

BB-744/100T 1500 x 900 x 1370 744V / 100Ah Yuasa

Backup Time Table

UPS + Battery Bank Capacity Bacup Tim (min) Battery Brand

100% Load 75% Load

Induspower

IN-3340TL

Tower

40.0kVA

+ 1 x BB-744/18T - 744V/18Ah 9,5 17,1 Yuasa

+ 1 x BB-744/38T - 744V/38Ah 33 47 Yuasa

+ 1 x BB-744/65T - 744V/65Ah 61 80,5 Yuasa

+ 1 x BB-744/100T - 744V/100Ah 93,5 130 Yuasa

Induspower

IN-3360TL

Tower

60.0kVA

+ 1 x BB-744/26T - 744V/26Ah 9,4 14 Yuasa

+ 1 x BB-744/38T - 744V/38Ah 15,9 23 Yuasa

+ 1 x BB-744/65T - 744V/65Ah 26,6 38 Yuasa

+ 1 x BB-744/100T - 744V/100Ah 61 87 Yuasa

Induspower

IN-3380TL

Tower

80.0kVA

+ 1 x BB-744/26T - 744V/26Ah 6 9,4 Yuasa

+ 1 x BB-744/38T - 744V/38Ah 9,3 15,2 Yuasa

+ 1 x BB-744/65T - 744V/65Ah 18,2 25 Yuasa

+ 1 x BB-744/100T - 744V/100Ah 27,1 41 Yuasa

P Model kVA Datasheet Manual SNMP Card Software Inquiry

1 IN-3340-TL 40.0 kVA

2 IN-3360-TL 60.0 kVA PDF PDF Go to SNMP Go to Software To join FSP

3 IN-3380-TL 80.0 kVA

Specification

Model IN-3340-TL IN-3360-TL IN-3380-TL

Phase 3 phase in / 3 phase out

Capacity 40.0 kVA / 32kW 60.0 kVA / 48kW 80.0 kVA / 64kW

Input

Nominal Voltage 3x 400V (3Ph + N)

Acceptable Voltage Range +15% / -20%

Frequency Range 50/60Hz ± 5%

Total Harmonic Distortion (THD)

< 1.5% @ 100% load

< 2.5% @ 50% load

< 6.5% @ 10% load

< 1.0% @ 100% load

< 2.0% @ 10% load

< 5.0% @ 50% load

< 1.5% @ 100% load

< 2.0% @ 50% load

< 6.0% @ 10% load

Current Limitation High overload: PFC Limit (discharging batteries)50 / 60 Hz ±5 %

Power Factor 1.0

Inverter

Nominal Voltage 3x400 VAC (3Ph + N) 208/220/230/240VAC

Precision Stationary: ±1% ; Transitory: ±2% (load variations 100-0-100%)

Frequency 50/60 Hz synchronised ±4 % With mains absent ±0.05%

Max. Synchronisation Speed ±10 Hz/s

Waveform Pure Sinewave

Total Harmonic Distortion (THD) ≦ 0.5% THD (Linear Load) ; ≦ 1.5% THD (Non-linear Load)

Phase Displacement 120º ±1% (balanced load) ; 120º ±2% (imbalances 50% of the load)

Dynamic Recovery Time 10 ms. at 98 % of the static value Pure Sinewave

Admissible Overload 125% for 10 min., 150% for 60 s

Admissible Crest Factor 3.2:1 2.8:1

Admissible Power factor 0.7 inductive to 0.7 capacitive

Imbalance Output Voltage

@ 100% Unbalanced Load <1%

Current Limit High overload, short-circuit: RMS Voltage Limit ; High Crest-Factor current: Peak Voltage Limit

Static Bypass

Type Solid State

Voltage 3x400V (3Ph + N)

Frequency 50/60 Hz

Activation Criterion Microprocessor Control

Transfer Time Zero

Admissible Overload 400% for 10sec.

Transfer to Bypass Immediate, for overloads above 150%

Retransfer Automatic after alarm clear

AC Input & Output Connectors

AC Input Connector Ter mina l

AC Output Connector Ter mina l

Standards

IEC 62040-1 (safety) Yes

IEC-62040-2 (EMC) Yes

CE Yes

Maintenance Bypass

Type Without Interruption

Voltage 3x400V (3Ph + N)

Frequency 50/60 Hz

Overall Efficiency (Line Mode) 92.5% 93% 94%

Physical dimensions

Long-Run

Model

Dimension (mm) 805 (D) x 590 (W) x 1320 (H) 805 (D) x 590 (W) x 1320 (H) 805 (D) x 590 (W) x 1320 (H)

Net Weight (kgs) 180 210 230

Induspower Series Backup Time Table

Induspower 40.0 kVA - 62 Batteries, Battery Voltage 744V, Charging Current 0,2C

External Battery Type Sets 100% Full Load (in min.) 75% Load (in min.)

17 Ah (CSB GP12170)

1 8,5 14,1

2 28,2 41,1

3 49 71

26 Ah (CSB GP12260)

1 16,7 24,5

2 42,5 60,9

3 70,9 98,5

40 Ah (CSB GP12400)

1 23,9 35,2

2 60,9 86,8

3 102,3 145,8

65 Ah (CSB GP12650)

1 40,4 61,2

2 114 172,7

3 204 288

100 Ah (CSB GP121000)

1 75,5 115

2 210 293

3 347 489

Induspower 60.0 kVA - 62 Batteries, Battery Voltage 744V, Charging Current 0,2C

External Battery Type Sets 100% Full Load (in min.) 75% Load (in min.)

26 Ah (CSB GP12260)

1 9,4 14

2 24,9 36

3 42,6 61

40 Ah (CSB GP12400)

1 13,2 19,8

2 35,8 51,6

3 61 87

65 Ah (CSB GP12650)

1 22 33,4

2 62,3 94,4

3 114,4 174,3

100 Ah (CSB GP121000)

1 42,8 62,5

2 117 180

3 211 297

Induspower 80.0 kVA - 62 Batteries, Battery Voltage 744V, Charging Current 0,2C

External Battery Type Sets 100% Full Load (in min.) 75% Load (in min.)

26 Ah (CSB GP12260)

1 6 9,4

2 16,9 24,7

3 29,6 42,3

40 Ah (CSB GP12400)

1 8,5 13,1

2 24,1 35,6

3 42,1 60,6

65 Ah (CSB GP12650)

1 14,5 22

2 40,8 61,8

3 75 113,

100 Ah (CSB GP121000)

1 30,4 42,6

2 76,3 116

3 142 210
