Strona 1/33
LiteMax™ 35
Owner’s Manual
Rear-facing Child
Restraint System
Keep for future use
To reduce the risk of serious injury
or death, read this owner’s manual prior
to installing and using this child restraint.
WARNING:
© 2015 Evenflo Company, Inc. 25701013 11/15
Rear-facing*
1.8 to 15.8 kg
(4 to 35 lbs)
43 to 81 cm
(17 to 32 in.)
Para instrucciones en Español,
llamar al: 1-800-233-5921
b u c
sto
Recline Indica t or
Indicateur d’inclinaison
1.8 -9 k g (4-
20
lbs)
9-
15.8 k g (2
0-3 5 lbs)
* See page 1
for complete
requirements.
1
More children are killed every year as passengers in car crashes
than by any other type of injury. To reduce the risk of SERIOUS
INJURY DEATH or , read this owner’s manual and your vehicle owner’s
manual before installing and using this child restraint. Using a child
restraint makes a big difference. By properly using this child restraint
and following these instructions (and the instructions that accompany
your vehicle), you will greatly reduce the risk of serious injury or death to
your child from a crash. Do not be misled by the commonly used term
“safety seat”; no restraint system can prevent all injuries in all crashes.
Many properly restrained adults and children are injured in motor vehicle
crashes, including relatively minor crashes. A properly used child restraint
is the best way to minimize injuries to your child and to increase the
chances for your child’s survival in most crashes.
Table of Contents
bucklestora ge
Harness straps at, or
below, the shoulder.
At least 25 mm
(1 inch)
Premature Infant Use ............................................................ 2
Warnings ............................................................................... 3
LATCH Warnings .................................................................... 7
Safe Practices ........................................................................ 9
Recall Information for U.S. Customers ................................... 9
Public Notice for Canadian Customers ................................ 10
Motor Vehicle/Aircraft Usage .............................................. 10
Care and Cleaning ............................................................... 10
Storing Your Instructions ..................................................... 11
Visual Glossary ..................................................................... 12
Using the LiteMax Handle ................................................... 16
Proper Installation WITH the Convenience Base
Installation Checklist ......................................................... 19
Installing the Convenience Base with
the Lower Anchor Connector Assembly ......................... 20
Installing the Convenience Base with
the Vehicle Seat Belt ...................................................... 26
Placing the Carrier in the Base .......................................... 30
Releasing the Carrier from the Base .................................. 31
Proper Installation WITHOUT the Convenience Base
Installation Checklist ........................................................ 33
Installing the Carrier without the Convenience Base ......... 34
Securing the Child in the Carrier .......................................... 37
Removing the Child from the Carrier ................................... 39
Changing the Harness Position ........................................... 40
Changing the Crotch Strap Position .................................... 42
Changing the Waist Strap Position ...................................... 44
Removing the Lower Anchor Connector Assembly ............... 48
Using as an Infant Carrier .................................................... 50
Securing Your Child Restraint in Aircraft .............................. 52
Installing Carrier without Convenience Base in Aircraft ......... 53
Installing the Canopy ........................................................... 56
Installing the Accessories ..................................................... 56
Replacement Parts ............................................................... 58
Limited Warranty ................................................................. 60
Child Requirements
• No restraint can guarantee absolute protection from
injury in every crash.
• This child restraint is designed for use ONLY by children in
rear-facing position. To use this child restraint properly,
children meet weight/size specifications as follows:MUST
For Rear-facing Use ONLY
• 1.8 – 15.8 kg (4 – 35 lbs)
• 43 – 81 cm (17 – 32 inches)
• Top of head is at least 25 mm (1 inch) below
the top of the child restraint seat back.
U.S. REGULATORY NOTICE
This child restraint meets all the requirements of
Federal Motor Vehicle Safety Standard 213.
For Canadian Models
CANADIAN REGULATORY NOTICE
(MODEL NUMBERS ENDING IN “C”)
This child restraint meets all the applicable requirements
of Canadian Motor Vehicle Safety Standard 213.1.
Symbol Legend
Airbag Symbol – Alerts you to important
information about airbag safety.
LATCH Symbol – Alerts you to important
information about LATCH safety.
Tether Anchor Symbol – Alerts you to
important information about tether anchor safety.
Aircraft Symbol – Alerts you to important
information about aircraft safety.
2 3
PREMATURE INFANT USE
Before using this child restraint for preterm or low birth weight
infants, you must read and follow the guidelines in this section.
According to the U.S. National Highway Traffic Safety
Administration, a properly installed child restraint reduces the
risk of death by over 70% for infants involved in crashes. Federal
Motor Vehicle Safety Standard (FMVSS) 213 establishes design
and dynamic performance requirements for child restraint
systems. However, the standard has no minimum weight limit
and does not address the special medical needs of preterm or
low birth weight infants. To ensure that preterm and low birth
weight infants are transported safely, the guidelines published
by the American Academy of Pediatrics (AAP) in Pediatrics
2009;123:1424–1429 must be followed.
All children should ride rear-facing in the vehicle as long as
possible. Preterm and low birth weight infants are at additional
risk of breathing difficulties and heart problems when placed
in a child restraint. Evenflo requires that the evaluation
recommended by the AAP be conducted for all infants born
earlier than 37 weeks and all newborn infants who weigh
less than 5 lb at birth before their first car trip to check for
breathing difficulties or heart rate problems when traveling in a
rear-facing child restraint.
The AAP recommends that appropriate hospital staff observe
your infant in the child restraint for a period of 90 to 120
minutes or the duration of travel, whichever is longer. This
period of observation must be performed with the infant
properly positioned as described in these instructions and with
the child restraint placed at an angle that is approved for use
in the vehicle. The hospital staff will check for any breathing
difficulties or heart rate problems. Your child’s pediatrician will
let you know if there are any special considerations for travel.
The number of trips and the duration of time the infant is
seated in the child restraint should be minimized. A caregiver
should ride in the back seat to monitor the infant during travel.
PREMATURE INFANT USE - continued
You can learn more about the AAP’s recommendations
for observation of newborns and the guidelines for safe
transportation of preterm and low birth weight infants, as well
as other resources for parents and medical professionals, at
http://www.aap.org/healthtopics/carseatsafety.cfm
General Warnings
• Child restraints should be used only for travel. Potential
adverse health effects from excessive use of infant child
restraints have been documented. You should limit
the time spent each day in a child restraint as much as
possible. You must use your child restraint as a NEVER
sleeping environment in the home. leave your NEVER
infant unattended in a child restraint in or out of the
vehicle.
• Failure to follow installation instructions can result in
your child striking the vehicle’s interior during a sudden
stop or crash. Serious injury or death may result. These
instructions and the instructions in your vehicle owner’s
manual must be followed carefully. If there is a conflict
between the two, the vehicle owner’s manual regarding
child restraint installation must be followed.
• This child restraint MUST ALWAYS face the rear
of the vehicle. Serious injury or death can occur if used
forward-facing.
• leave child unattended.NEVER
• use child restraint if it is damaged, broken, DO NOT
or missing parts.
• use this restraint if it has been involved in a DO NOT
crash. It must be replaced.
• attach additional padding, toys or other devices DO NOT
not made by Evenflo, or described in these instructions,
to the child restraint. Items not tested with the child
restraint could injure the child.
• Be sure that the handle is firmly locked in Position 1
(Carry) before lifting the child restraint
(see pages 16-17).
• This child restraint must be securely belted to the vehicle
at all times, even when unoccupied. An unsecured child
restraint may injure someone if a crash occurs.
Premature Infants
• use this or any other child restraint with a DO NOT
premature infant until after consulting your doctor.
Premature infants may have difficulty breathing when in
a sitting position.
WARNING
WARNING
