User Manual

DFI 44800

www.teka.com

NOTE:

Reviewing the section on will help you solve some

common problems by yourself.

If you cannot solve the problems by yourself, please ask for help from a

professional technician.

The manufacturer, following a policy of constant development and updating of

the product, may make modifications without giving prior notice.

If lost or out-of-date, you can receive a new user manual from the manufacturer

or responsible vendor.

Troubleshooting Tips

SAFETY INFORMATION

CONTENTS

PRODUCT OVERVIEW

USING YOUR DISHWASHER

Loading The Salt Into The Softener

Basket Loading Tips

MAINTENANCE AND CLEANING

External Care

Internal Care

Caring For The Dishwasher

INSTALLATION INSTRUCTION

Power Connection

Water Supply And Drain

Connection Of Drain Hoses

Built-In Installation (for the integrated model)

Positioning The Appliance

TROUBLESHOOTING TIPS

LOADING THE BASKETS

27 Availability Of Spare Parts

SAFETY INFORMATION

WARNING

When using your dishwasher, follow the

precautions listed below:

Installation and repair can only be carried out by a

qualified technician

This appliance is intended to be used in household

and similar applications such as:

working environments;

-farm houses;

-by clients in hotels, motels and other residential type

environments;

-bed and breakfast type environments.

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

Children shall not play with the appliance. Cleaning

and user maintenance shall not be done by children

without supervision. (For EN60335-1)

This appliance is not intended for use by persons

(including children) with reduced physical, sensory or

mental capabilities, or lack of experience and

knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a

person responsible for their safety.

staff kitchen areas in shops, offices and other

This appliance can be used by children aged from 8

years and above and persons with reduced physical

(For IEC60335-1)

Packaging material could be dangerous for children!

This appliance is for indoor household use only.

To protect against the risk of electrical shock, do not

immerse the unit, cord or plug in water or other liquid.

Please unplug before cleaning and maintenance the

appliance .

Children should be supervised to ensure that they do

not play with the appliance.

Use a soft cloth moisten with mild soap,

and then use a dry cloth to wipe it again.

If the supply cord is damaged, it must be replaced by

the manufacturer or its service agent or a similarly

qualified person in order to avoid a hazard.

Earthing Instructions

This appliance must be earthed. In the event of a

malfunction or breakdown, earthing will reduce the

risk of an electric shock by providing a path of least

resistance of electric current. This appliance is

equipped with an earthing conductor plug.

The plug must be plugged into an appropriate

outlet that is installed and earthed in accordance

with all local codes and ordinances.

Improper connection of the equipment-earthing

conductor can result in the risk of an electric shock.

Check with a qualified electrician or service

representative if you are in doubt whether the

appliance is properly grounded.

Do not modify the plug provided with the appliance

if it does not fit the outlet.

Have a proper outlet installed by a qualified

electrician.

Do not abuse, sit on, or stand on the door or dish

rack of the dishwasher.

Do not operate your dishwasher unless all enclosure

panels are properly in place.

Open the door very carefully if the dishwasher is

operating, there is a risk of water squirting out.

Do not place any heavy objects on or stand on the

door when it is open. The appliance could tip

forward.

When loading items to be washed:

1) Locate sharp items so that they are not likely to

damage the door seal;

2) Warning: Knives and other utensils with sharp

points must be loaded in the basket with their

points facing down or placed in a horizontal

position.

Some dishwasher detergents are strongly alkaline.

They can be extremely dangerous if swallowed.

Avoid contact with the skin and eyes and keep

children away from the dishwasher when the door

is open.

Check that there are no detergent residues after

completion of the wash cycle.

Do not wash plastic items unless they are marked

“dishwasher safe” or the equivalent.

For unmarked plastic items not so marked, check the

manufacturer's recommendations.

Use only detergent and rinse agents recommended for

use in an automatic dishwasher.

Never use soap, laundry detergent, or hand washing

detergent in your dishwasher.

The door should not be left open, since this could

increase the risk of tripping.

During installation, the power supply must not be

excessively or dangerously bent or flattened.

Do not tamper with controls.

The appliance needs to be connected to the main

water valve using new hose sets. Old sets should not be

reused.

To save energy, in stand by mode, the appliance will

switch of automatically after 15 minutes without any

user interaction.

The maximum number of place settings to be washed

is 10.

The maximum permissible inlet water pressure is 1MPa.

The minimum permissible inlet water pressure is

0.04MPa.

Disposal

For disposing of package and the

appliance please go to a recycling center.

Therefore cut off the power supply cable

and make the door closing device

unusable.

Cardboard packaging is manufactured from recycled

paper and should be disposed in the waste paper

collection for recycling.

By ensuring this product is disposed of correctly, you

will help prevent potential negative consequences

for the environment and human health, which could

otherwise be caused by inappropriate waste

handling of this product.

For more detailed information about recycling of this

product, please contact your local city office and

your household waste disposal service.

DISPOSAL: Do not dispose this product as

unsorted municipal waste. Collection of such

waste separately for special treatment is

necessary.

PRODUCT OVERVIEW

To get the best performance from your dishwasher, read all operating instructions

before using it for the first time.

Dispenser

Salt container Filter assembly

Lower spray arm

Inner pipe

IMPORTANT:

Cutlery basket Lower basket

Pictures are only for reference, different models may be different.

NOTE:

Top spray arm

Upper basket

Upper spray armCutlery rack Cup rack

Loading The Salt Into The Softener

Only use salt specifically designed for dishwashers use!

Every other type of salt not specifically designed for dishwasher use,

especially table salt, will damage the water softener. In case of damages

caused by the use of unsuitable salt the manufacturer does not give any

warranty nor is liable for any damages caused.

Only fill with salt before running a cycle.

This will prevent any grains of salt or salty water, which may have been

spilled, remaining on the bottom of the machine for any period of time,

which may cause corrosion.

WARNING

Always use salt intended for dishwasher use.

The salt container is located beneath the lower basket and should be filled as

explained in the following:

Please check the section 1 “Water Softener” of PART

Please check the section 1 “Water Softener” of PART Special Version,

Special Version,

Ⅱ:

If you need to set the water softener

If you need to set the water softener .

Please check the section 1 “Water Softener” of PART Special Version, Ⅱ:

If you need to set the water softener .

If your model does not have any water softener, you may skip this section.

NOTE:

USING YOUR DISHWASHER

Before using your dishwasher :

Inside Outside

1. Set the water softener

2. Loading the salt Into the softener

3. Loading the basket

4. Fill the dispenser

detergent

Folding back the cup shelves

To make room for taller items in the upper basket, raise the cup rack upwards.

You can then lean the tall glasses against it. You can also remove it when it is not

required for use.

Folding back the rack shelves

The spikes of the lower basket are used for holding plates and a platter.

They can be lowered to make more room for large items.

raise upwards fold backwards

Sliding cutlery rack

The cutlery rack can slide to the right or left at will.

Basket Tips

MAINTENANCE AND CLEANING

External Care

The door and the door seal

Clean the door seals regularly with a soft damp cloth to remove food deposits.

When the dishwasher is being loaded, food and drink residues may drip onto the

sides of the dishwasher door. These surfaces are outside the wash cabinet and are not

accessed by water from the spray arms. Any deposits should be wiped off before the

door is closed.

The control panel

If cleaning is required, the control panel should be wiped with a soft damp cloth only.

To avoid penetration of water into the door lock and electrical components,

do not use a spray cleaner of any kind.

Never use abrasive cleaners or scouring pads on the outer surfaces because

they may scratch the finish. Some paper towels may also scratch or leave

marks on the surface.

WARNING

Internal Care

Filtering system

NOTE:

Pictures are only for reference, different models of the filtering system and spray

arms may be different.

The filtering system in the base of the wash cabinet retains coarse debris from the

washing cycle, including foreign objects such as tooth picks or shards. The collected

coarse debris may cause the filters to clog. Check the condition of the filters regularly,

carefully remove foreign objects and clean the parts of the filtering system if necessary

with water. Follow the steps below to clean the filter.

1 2Hold the coarse filter and rotate it

anticlockwise to unlock the filter.

Lift the filter upwards and out of

the dishwasher.

The fine filter can be pulled off the

bottom of the filter assembly.

The coarse filter can be detached

from the main filter by gently

squeezing the tabs at the top and

pulling it away.

3 4

Larger food remnants can be

cleaned by rinsing the filter under

running water.

For a more thorough clean, use a

soft cleaning brush.

Reassemble the filters in the reverse

order of the disassembly, replace the

filter insert, and rotate clockwise to

the close arrow.

Do not over tighten the filters. Put the filters back in sequence securely,

otherwise coarse debris could get into the system and cause a blockage.

Never use the dishwasher without filters in place. Improper replacement of

the filter may reduce the performance level of the appliance and damage

dishes and utensils.

WARNING

Main filter

Coarse filter

Fine filter

Open

Spray arms

Wash the arms in soapy and warm

water and use a soft brush to clean

the jets. Replace them after rinsing

them thoroughly.

It is necessary to clean the spray arms regularly for hard water chemicals will clog the

spray arm jets and bearings.

To clean the spray arms, follow the instructions below:

To remove the lower spray arm, pull

out the spray arm upward.

To remove the upper spray arm,

hold the nut in the center still and

rotate the spray arm counterclockwise

to remove it.

Caring For The Dishwasher

Frost precaution

Please take frost protection measures on the dishwasher in winter. Every time after

washing cycles, please operate as follows:

1. Cut off the electrical power to the dishwasher at the supply source.

2. Turn off the water supply and disconnect the water inlet pipe from the water valve.

3. Drain the water from the inlet pipe and water valve. (Use a pan to gather the water)

4. Reconnect the water inlet pipe to the water valve.

5. Remove the filter at the bottom of the tub and use a sponge to soak up water in

the sump.

After every wash

After every wash, turn off the water supply to the appliance and leave the door slightly

open so that moisture and odors are not trapped inside.

for a while

Remove the plug

Before cleaning or performing maintenance, always remove the plug from the socket.

No solvents or abrasive cleaning

To clean the exterior and rubber parts of the dishwasher, do not use solvents or

abrasive cleaning products. Only use a cloth with warm soapy water.

To remove spots or stains from the surface of the interior, use a cloth dampened with

water an a little vinegar, or a cleaning product made specifically for dishwashers.

When not in use for a long time

It is recommend that you run a wash cycle with the dishwasher empty and then remove

the plug from the socket, turn off the water supply and leave the door of the

appliance slightly open. This will help the door seals to last longer and prevent odors

from forming within the appliance.

Moving the appliance

If the appliance must be moved, try to keep it in the vertical position. If absolutely

necessary, it can be positioned on its back.

Seals

One of the factors that cause odours to form in the dishwasher is food that remains

trapped in the seals. Periodic cleaning with a damp sponge will prevent this from

occurring.

INSTALLATION INSTRUCTION

Ensure the voltage and frequency of the power being corresponds to those on the

rating plate. Only insert the plug into an electrical socket which is earthed properly. If

the electrical socket to which the appliance must be connected is not appropriate for

the plug, replace the socket, rather than using a adaptors or the like as they could

cause overheating and burns.

Electrical requirements

Electrical connection

Ensure that proper earthing exists before use

About Power Connection

WARNING

For personal safety:

Do not use an extension cord or an adapter

plug with this appliance.

Do not, under any circumstances, cut or remove

the earthing connection from the power cord.

The installation of the pipes and electrical equipments should be done by professionals.

Attention

WARNING

Electrical Shock Hazard

Disconnect electrical power before

installing dishwasher.

Failure to do so could result in death or

electrical shock.

Please look at the rating label to know the rating voltage and connect the dishwasher

to the appropriate power supply. Use the required fuse 10A/13A/16A, time delay fuse

or circuit breaker recommended and provide separate circuit serving only this appliance.

Water Supply And Drain

Cold water connection

Connect the cold water supply hose to

a threaded 3/4(inch) connector and

make sure that it is fastened tightly in

place.

If the water pipes are new or have not

been used for an extended period of

time, let the water run to make sure

that the water is clear. This precaution

is needed to avoid the risk of the

water inlet to be blocked and damage

the appliance.

safety supply hose

ordinary supply hose

About the safety supply hose

The safety supply hose consists of the double walls. The system guarantees its

intervention by blocking the flow of water in case of the supply hose breaking and

when the air space between the supply hose itself and the outer corrugated hose is

full of water.

How to onnect the safety supply hosec

1. Pull safety supply hoses out from storage compartment located at

rear of dishwasher.

2. the screws of the safety supply hose to the faucet with thread 3/4inch.

3. Turn water fully on before starting the dishwasher.

the

Tighten

the

WARNING

A hose that attaches to can burst if it is installed on the same water

line as the dishwasher. If your sink has one, it is recommended that the

hose be disconnected and the hole plugged.

a tap

How to disconnect the safety supply hose

1. Turn off the water.

2. Unscrew the safety supply hose from the faucet.

Connection Of Drain Hoses

Please securely fix the drain hose in either position A or position B

MAX 1000 mm

Counter

Drain hose

Insert the drain hose into a drain pipe with a minimum diameter of 4 cm, or let it run

into the sink, making sure to avoid bending or crimping it. The height of drain pipe

must be less than 1000 mm. The free end of the hose must not be immersed in water

to avoid the back flow of it.

Extension hose

Water outlet

How to drain excess water from hoses

Syphon connection

If the connection to the drain pipe is positioned higher than 1000 mm, excess water

may remain in the drain hose. the hose

It will be necessary to drain excess water from

into a bowl or suitable container that is held outside and lower than the sink.

Connect the water drain hose. The drain hose must be correctly fitted to avoid water

leaks. Ensure that the water drain hose is not kinked or squashed.

The waste connection must be at a height less than (maximum) from the

bottom of the .

1000 mm

dishwasher

If you need a drain hose extension, make sure to use a similar drain hose.

It must not be longer than 4 meters, otherwise the cleaning effect of the dishwasher

could be reduced.

Back of dishwasher

Water Inlet

Drain Pipe

Mains Cable

40 mm

Drain Pipe

Positioning The Appliance

Position the appliance in the desired location. The back should rest against the wall

behind it, and the sides, along the adjacent cabinets or walls. The dishwasher is

equipped with water supply and drain hoses that can be positioned either to the right

or the left sides to facilitate proper installation.

Built-In Installation (for the integrated model)

Step 1. Selecting the best location for the dishwasher

The installation position of dishwasher should be near the existing inlet and drain

and power .

Illustrations of cabinet dimensions and installation position of the dishwasher.

1. Less than 5 mm between the top of dishwasher and cabinet and the outer door

aligned to cabinet.

the

hose socket

90 ° 90 °

580mm

820mm

100

Electrical, drain

and water supply

line

line connection

connection

Electrical, drain

and water supply

line connection

Space between cabinet

bottom and floor

Space between cabinet

bottom and floor

600 mm( )for 60 cm model

450 ( )mm for 45 cm model

Step 2. Aesthetic panel's dimensions and installation

2. If dishwasher is at the corner of the cabinet,

there should be some space when the door is opened.

installed

CabinetDishwasher

Door of

dishwasher

Minimum space

of 50 mm

NOTE:

Depending on where your electrical outlet is, you may need to cut a hole in the

opposite cabinet side.

Follow the specific installation instruction for attaching the

aesthetical door panel.

Follow the specific installation instruction for attaching the

aesthetical door panel.

Velcro stripe

Seperate velcro stripe A and velcro stripe B and attach velcro stripe A on the inner side

of the aesthetic panel. Attach the felted velcro stripe B on the outer door of dishwasher

(see figure A). After positioning of the panel, fix the panel onto the outer door by

screws and bolts (See figure B)

Semi-integrated model

2 Pin up the four long screws.

1 Take away the four short screws.

Step 3. Tension adjustment of the door spring

1. The door springs are set at the factory to

the proper tension for the outer door. If

aesthetic panel are installed, you

will have to adjust the door spring tension.

Rotate the adjusting screw to drive the

adjustor to strain or relax the steel cable.

2. Door spring tension is correct when the

door remains horizontal in the fully opened

position, yet rises to a close with the slight

lift of a finger.

Install the hook on the aesthetic panel and put the hook into the slot of the outer

door of dishwasher (see figure A). After positioning of the panel, fix the panel onto

the outer door by screws and bolts (See figure B).

2.Pin up the four long screws

A1 Take away the four short screws.

Fully-integrated model

Step 4. Dishwasher installation steps

1. Affix the condensation strip under the work surface of cabinet. Please ensure the

condensation strip is flush with edge of work surface. (Step 2)

2. Connect the inlet hose to the cold water supply.

3. Connect the drain hose.

4. Connect the power cord.

5. Place the dishwasher into

6. Level the dishwasher. The rear foot can be adjusted from the front of the

dishwasher by turning the Philips screw in the middle of the base of dishwasher

use Philips screw . To adjust the front feet, use a flat screw driver and turn

the front feet until the dishwasher is level. (Step 5 to Step 6)

7. Install the furniture door to the outer door of the dishwasher. (Step 7 to Step 10)

8. Adjust the tension of the door springs by using turning in a

clockwise motion to tighten the left and right door springs. Failure to do this could

cause damage to your dishwasher. (Step 11)

9. The dishwasher must be secured in place. There are two ways to do this:

A. Normal work surface: Put the installation hook into the slot of the side plane

and secure it to the work surface with

B. Marble or granite work top: Fix the side with .

.the cabinet

a driver

a Philips screw driver

the screws.

screws

Please refer to the specific installation steps in the installation

drawings.

Please refer to the installation steps in the installation

drawings.

specific

Specyfikacje produktu

Marka:	Teka
Kategoria:	Pomywaczka
Model:	DFI 44800

Potrzebujesz pomocy?

Jeśli potrzebujesz pomocy z Teka DFI 44800, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą

Twoje imię*

Twój email*

Napisz tutaj swoje pytanie

Instrukcje Pomywaczka Teka

Teka DW655FI Instrukcja

31 Marca 2025

Teka DW8 57 FIM Instrukcja

20 Lutego 2025

Teka DFS 26 610 SS Instrukcja

6 Lutego 2025

Teka DFI 46960 Instrukcja

5 Stycznia 2025

Teka DFI 44800 Instrukcja

5 Stycznia 2025

Teka DFI 76960 Instrukcja

5 Stycznia 2025

Teka DFI 46710 Instrukcja

2 Stycznia 2025

Teka DFS 24610 WH Instrukcja

2 Stycznia 2025

Teka DFI 46950 ME Instrukcja

2 Stycznia 2025

Teka LC 24700 WH Instrukcja

2 Stycznia 2025

Instrukcje Pomywaczka

Najnowsze instrukcje dla Pomywaczka

Oranier GAVI 7592 XL Instrukcja

9 Kwietnia 2025

Amica DIM44D6EBq Instrukcja

9 Kwietnia 2025

Sharp QW-I1GI47EX Instrukcja

9 Kwietnia 2025

Zanussi DA 4142 Instrukcja

8 Kwietnia 2025

AEG F88010VIL Instrukcja

8 Kwietnia 2025

AEG FSK73747P Instrukcja

8 Kwietnia 2025

Miele G 5432 SCU Instrukcja

8 Kwietnia 2025

Miele G 5495 SCVi XXL Active Plus Instrukcja

8 Kwietnia 2025

AEG Favorit 675I B I Instrukcja

7 Kwietnia 2025

Asko DFI545N Instrukcja

7 Kwietnia 2025
