Strona 1/8
- 1 -
Exit Stopper®
STI-6400 Series
Features
· Helps prevent unauthorized exits/entries through doors.
· Easy to install. Warning sound when turning on (two flashes/beeps) and off
(one flash/beep).
· Add warning in second language with provided labels (21 languages).
· Select volume, alarm duration and delay settings.
· Mount on top, right, left or next to almost any door.
· Select on-site whether to use an alarm or annunciator.
· Low battery detection, beep and flashes.
· Alarm sounds and high power LED light flashes when activated.
· Dry contact Form C relay.
· Protect anything such as cabinet, extinguisher, etc. with an external reed or
any mechanical switch.
Rely on STI®
- 2 -
Warnings
All units are recommended for indoor use only. Unit must be tested periodically to verify the life
of battery. STI recommends you change the 9 Volt battery twice a year. To hear alarm when
normal work environment is loud, may need to purchase remote horns. When purchasing a
remote unit (STI-6403 or STI-6404) you will need to periodically test the connections to make
sure audibles function at a sound level to alert staff. Maximum of three remote alarms may be
used in parallel.
All specifications and information shown are current as of publication and subject to change
without notice.
WARNING: This product can expose you to chemicals including Dichloromethane, which is known
to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of
California to cause birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov.
Warranty Information
· Three year guarantee against breakage of polycarbonate in normal use (one year on electro
mechanical and electronic components).
· Electronic warranty form at www.sti-usa.com/wc14
- 3 -
Specications
Polycarbonate Enclosure
Dimensions 5.375” W x 5.375” H x 2 “ D (137mm x 137mm x 51mm)
Flammability UL94 V-2
Wall Thickness 0.12 in (3.05mm)
Electronics: STI-6403 and STI-6404 - Remote Horn Unit
Power Source 9 VDC operating power* only
Horn Volume at 1 ft. 95 dB low / 105 dB high
Stand by Current 0 A
Alarm Current 50mA at 95 dB/ 200 mA at 105 dB
* Power source for the STI-6403 and STI-6404 Remote Horn uses a separate power
source from the STI-6400 alarm. The Remote Horn contains an internal 9 volt battery.
Horn operates when the Form C contact at main unit is activated on alarm.
9 VDC battery
If not using, slide switch 6 “on”
12VDC - 24VDC, 300mA
Installed battery will act as backup power if switch 6 is “off”
30 cm high volume 112dB; low volume 97dB
100 cm high volume 102dB; low volume 88dB
Flash 1x / minute; beep 1x / 3 minutes
0.5A 125VAC / 1A 30VDC
Battery <15μA (Battery Life approx. 2 years dependent on use)
12VDC <0.15mA
24VDC <1mA
<286mA @12VDC <149mA @24VDC
14°F to 122°F (-10°C to 50°C)
2 flashes and 2 beeps
1 flash and 1 beep
Power source
Remote power input
Low battery detection
Relay contacts
Stand by current
Alarm current (volume high + relay)
Operating temperature
Power “on” notification
Power “off” notification
Horn volume
Electronics
