Quick-start guide

FR: Guide de l’utilisateur - fr.startech.com

DE: Bedienungsanleitung - de.startech.com

ES: Guía del usuario - es.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

IT: Guida per l’uso - it.startech.com

JP: - jp.startech.com取扱説明書

Manual Revision: 02/21/2018

For the latest information, technical specications, and support for

this product, please visit www.startech.com.

Package contents

• 1 x HDMI video switch

• 1 x IR remote control (with CR2025 battery)

• 1 x universal power adapter (NA, EU, UK, ANZ)

Requirements

• 1 x HDMI display device (up to 4K @ 60 Hz)

VS221HD20

• 2 x HDMI source devices (up to 4K @ 60 Hz)

• 3 x HDMI M/M cables (sold separately)

VS421HD20

• 4 x HDMI source devices (up to 4K @ 60 Hz)

• 5 x HDMI M/M cables (sold separately)

Note: premium High Speed HDMI cables are required for optimal

performance at 4K 60Hz.

VS221HD20 / VS421HD20

2 / 4-Port HDMI® Video Switch - 4K @ 60 Hz

*actual product may vary from photos

Product diagram

Installation

Note: ensure your HDMI video source devices and the HDMI display

are powered o before you begin installation.

1. Connect an HDMI cable (sold separately) to an output port on

your HDMI source device and to one of the HDMI input ports on

the HDMI switch.

2. Repeat step #1 for each of your remaining HDMI source devices.

Note: each port is numbered, please take note of which number is

assigned to each HDMI source device.

3. Connect an HDMI cable (sold separately) to the HDMI output port

on the video switch and to an HDMI input port on your HDMI

display device.

4. Connect the universal power adapter to an available power

source and to the Power adapter port on the HDMI switch.

5. Power on your HDMI display, followed by each of your HDMI

source devices.

Front View - VS421HD20

Rear View - VS421HD20

IR sensor LED indicators

Power LED

Input selection

button

Power

adapter

port

HDMI output

port

HDMI input

ports

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void the user’s authority to operate the

equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s)

to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all

trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective holders.

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and

access our comprehensive selection of online tools, documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two-year warranty.

StarTech.com warrants its products against defects in materials and workmanship for the periods noted, following the initial date of purchase. During this period, the products may be returned for

repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental,

consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some states do not

allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.

Operation

Manual operation

Manual mode enables you to switch between HDMI video sources

using the Input selection button or the IR remote control.

Input selection button

Press the Input selection button to toggle between each HDMI video

source device.

IR remote control

Press the input port number on the IR remote to select the desired

HDMI video source.

VS421HD20 only: press or to cycle through all the

connected displays. Cycle in one direction until the desired HDMI
