Strona 1/2

Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

I T: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

P T: Guia do usuário - pt.startech.com

Manual Revision: 03/28/2019

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• 1 x MDP2HDMIUSBA adapter

Installation

1. Make sure the computer system and display device are

turned o.

2. Connect the mini DisplayPort® connector into the host

computer system’s video card.

3. Connect the USB connector on the adapter into an

available USB port on the host computer system.

4. Connect a standard male/male HDMI® cable (not included)

from the adapter to an available HDMI® connector on the

display device.

5. Power on the display device.

6. Power on the computer system. The Power LED on the

adapter should light up.

7. The computer system should automatically detect the display

device. Driver installation or special setup requirements

depend on the connected display device. Consult any

documentation included with your display device.

8. The operating system should also automatically detect and

install a new audio output device.

9. If you wish to send audio over HDMI®, check the audio

properties for the operating system, to make sure the USB

adapter is set as the default audio device.

NOTE: This will disable audio output from any speakers/

headphones currently connected to the computer system.

10. If you do not wish to use audio over HDMI®, set the default

audio device back to the original audio output device (e.g.

sound card) for your system.

System Requirements

• DisplayPort® enabled computer system with available mini

DisplayPort® port

• USB enabled computer system with available port

• HDMI® enabled display device

MDP2HDMIUSBA

Mini DisplayPort® to HDMI® Adapter with USB Audio

*actual product may vary from photos

Mini

DisplayPort®

connector

USB connector

HDMI®

connector

(output)

Power LED

Specications

Bus Interface Mini DisplayPort® 1.1a

USB 2.0

Video Signal High speed HDMI®

Connectors

1 x Mini DisplayPort® male

1 x USB type A male

1 x HDMI® female

LEDs 1 x Power

Integrated Cable Length 60cm / 2ft

Maximum Video Resolution 1920x1200 / 1080p

Audio Support Yes - 2 channel LPCM

HDCP Support Yes

Operating Temperature 5°C ~ 35°C (41°F ~ 35°F)

Storage Temperature 0°C ~ 70°C (32°F ~ 158°F)

Humidity 0 ~ 80% RH

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s)

to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all

trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective holders.

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and access

our comprehensive selection of online tools, documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a three-year warranty.

In addition, StarTech.com warrants its products against defects in materials and workmanship for the periods noted, following the initial date of purchase. During this period, the products may be returned

for repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental,

consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some states do not allow

the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.
