SuperSpeed USB 3.0

Gigabit LAN Adapter

User Reference Guide

Introduction

SuperSpeed USB 3.0 Gigabit LAN Adapter adds a RJ45

Ethernet port to a USB-enabled computer.

LOT Number Sticker

For future product return or exchange, this LOT

number is required. Please keep it for your reference.

04-1016A

Specifications

System Requirements

•Windows® 10 (32-/64-bit) / 8.1 (32-/64-bit) /

8 (32-/64-bit) / 7 (32-/64-bit) / Vista (32-/64-bit) /

XP (32-/64-bit)

•Windows® Server 2012 / 2008 R2 / 2008 / 2003

(32-/64-bit)

•Mac OS X® v10.6 to 10.11

Package Contents

•SuperSpeed USB 3.0 Gigabit LAN Adapter (Black /

White)

•Driver CD

•User Reference Guide

Product Layout

•RJ45 Ethernet Port: Connects to an Ethernet cable

(not included)

•USB 3.0 Type A: Connects to an available USB

port of the computer

LED Indicators

•Activity LED (Yellow): Blinking when network

activity is detected

•Connectivity LED (Green & Blue): On when

network is connected

Windows Driver Installation

1. Browse the driver CD.

2. Click and enter the folder according to your

operating system.

3. Click and select setup.exe file.

4. At the User Account Control, click Yes.

5. At the InstallShield Wizard window, select Next /

Install.

6. Wait for the InstallShield Wizard to complete,

click Finish.

7. Plug the adapter into an available USB port, then

connect your Ethernet cable.

8. Restart computer and the adapter is ready for use.

To Verify Installation on Windows

1. On the desktop, right click This PC, Computer or

My computer option, then click Manage.

2. Select Device Manager, and double click Network

adapters section.

3. Realtek USB GbE Family... should be shown.

Mac Driver Installation

1. Insert the driver CD, and the icon will display on

the desktop automatically.

2. Double click Drivers icon, and choose MAC \

RTUNICv....

3. At Introduction, click Continue.

4. At Read me, click Continue.

5. At License, click Continue / Agree.

6. At Installation Type, click Install or Upgrade.

7. Enter Name and Password, then click OK or Install

software.

8. Click Continue Installation.

9. At Summary, click Restart to restart the computer.

10. After rebooting, connect the adapter to the

computer and to your Ethernet cable.

To Verify Installation on Mac

1. Click on the left-top corner of the taskbar, and

choose About This Mac.

2. Choose More Info..., then select System Report....

3. Expand Hardware / USB section. USB 10/100/1000

LAN should be shown.

Uninstall the driver on Mac OS

1. Insert the driver CD.

2. Double click the Drivers icon on desktop, then

choose MAC folder.

3. Select uninstall.zip, and enter uninstall folder.

4. Choose uninstall.command, and enter your

password.

5. The uninstallation is completed.

FAQ & Solutions

If the adapter is not working properly:

•Make sure both connections of the adapter are

secure.

•Try other USB ports of the computer.

•Go to Device Manager to check whether the

driver is installed successfully. (Refer to page 3 or

4 for details)

Technical Support and Warranty

QUESTIONS? SIIG’s Online Support has answers! Simply visit our web site at

www.siig.com and click Support. Our online support database is updated daily with

new drivers and solutions. Answers to your questions could be just a few clicks away.

You can also submit questions online and a technical support analyst will promptly

respond.

SIIG offers a 1-year manufacturer warranty with this product. This warranty covers the

original purchaser and guarantees the product to be free of any defects in materials or

workmanship for one (1) year from the date of purchase of the product.

SIIG will, at our discretion, repair or replace (with an identical product or product having

similar features and functionality) the product if defective in materials or workmanship.

This warranty gives you specific legal rights, and you may also have other rights which

vary from state to state. Please see our web site for more warranty details.

If you encounter any problems with this product, please follow the procedures below.

A) If it is within the store's return policy period, please return the product to the store

where you purchased from.

B) If your purchase has passed the store's return policy period, please follow the steps

below to have the product repaired or replaced.

Step 1: Submit your RMA request.

Go to www.siig.com, click Su pport, t hen REQUEST A PR ODUCT

REPLACEMENT to submit a request to SIIG RMA or fax a request to 510-657-5962.

Your RMA request will be processed, if the product is determined to be defective,

an RMA number will be issued.

Step 2: After obtaining an RMA number, ship the product.

• Properly pack the product for shipping. All accessories that came with the

original package must be included.

• Clearly write your RMA number on the top of the returned package. SIIG

will refuse to accept any shipping package, and will not be responsible for a

product returned without an RMA number posted on the outside of the

shipping carton.

• You are responsible for the cost of shipping to SIIG. Ship the product to the

following address:

SIIG, Inc.

6078 Stewart Avenue

Fremont, CA 94538-3152, USA

RMA #:

• SIIG will ship the repaired or replaced product via Ground in the U.S. and

International Economy outside of the U.S. at no cost to the customer.

About SIIG, Inc.

Founded in 1985, SIIG, Inc. is a leading manufacturer of IT connectivity solutions (including

Serial ATA and Ultra ATA Controllers, FireWire, USB, and legacy I/O adapters) that bridge

the connection between Desktop/Notebook systems and external peripherals. SIIG continues

to grow by adding A/V and Digital Signage connectivity solutions to our extensive

portfolio.

SIIG products offer comprehensive user manuals, many user-friendly features, and are

backed by an extensive manufacturer warranty. High quality control standards are evident

by the overall ease of installation and compatibility of our products, as well as one of the

lowest defective return rates in the industry. SIIG products can be found in computer retail

stores, mail order catalogs, through major distributors, system integrators, and VARs in the

Americas and the UK, and through e-commerce sites.

SuperSpeed USB 3.0 Gigabit LAN Adapter is a trademark of SIIG, Inc. SIIG and the SIIG logo are

registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of

Microsoft Corporation. All other names used in this publication are for identification only and

may be trademarks of their respective owners.

PRODUCT NAME

SuperSpeed USB 3.0 Gigabit LAN Adapter

FCC RULES: TESTED TO COMPLY WITH FCC PART 15, CLASS B OPERATING

ENVIRONMENT: FOR HOME OR OFFICE USE

FCC COMPLIANCE STATEMENT:

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

THE PARTY RESPONSIBLE FOR PRODUCT COMPLIANCE

SIIG, Inc.

6078 Stewart Avenue

Fremont, CA 94538-3152, USA

Phone: 510-657-8688

1 2 43

RJ45 Ethernet Port USB 3.0 Type A

Connectivity LED

Activity LED

Host Interface USB 3.0

Connectors RJ45 Ethernet, Female &

USB 3.0 Type-A, Male

Housing Material Solid Plastic

Built-in Cable

Length 5.90" (150mm)

Power USB bus-powered

Output Cable

Range CAT-5e 100m (Max.)

Operating

Temperature 32 ~ 140

Storage

Temperature -4 ~ 140

Humidity 5% to 85% RH

Dimensions 2.56" (W) x 0.79" (H) x 1.18'' (D)

Weight 0.07 lbs

Note: Windows 7 and later have built in driver support

for this adapter. Simply plug in the adapter and the driver

will load automatically. If the built in driver doesn’t load prop-

erly, please follow the instructions below.

For earlier Windows OS, please follow the instructions below.
