Strona 1/24
WSBWM1-B2
UNIVERSAL EXTENDABLE
SOUNDBAR WALL MOUNT
INSTRUCTION MANUAL
WE’RE HERE TO HELP
If you have any questions along the way, our install experts are standing by to help.
Or, chat at: US: SANUS.com/chatSP
Call us at: US: +1 (800) 359-5520
Call us at: EMEA: +31 (0) 495 580 852
Call us at: UK: +44 (0) 800 056 2853
Texto en español, página 16 Deutscher Text Seiten 18 Svensk text sida 20
中文文字说明请参见第 22 页
Texte français page 17 Nederlandse tekst op pagina 19
Русский текст: стр. 21 日本語は 23 ページ
2
Drill Bit
20 lbs.
(9.07 kg)
CAUTION: To avoid potential personal injuries and property damage:
• Please read through these instructions completely to be sure you’re comfortable with this easy install process.
• This product is designed for use with wood studs, solid concrete and concrete block walls, and drywall only.
• Do not use this product for any purpose not explicitly specified by manufacturer.
• Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.
• If you do not understand these instructions or have doubts about the safety of the installation, assembly or use
of this product, contact Customer Service.
Before getting started, let’s make sure this product is perfect for you!
IMPORTANT SAFETY INSTRUCTIONS
READ ENTIRE MANUAL PRIOR TO USE. SAVE THESE INSTRUCTIONS.
Weight Limit
DO NOT EXCEED
Tools Needed
Drywall Install
Pencil Level Electric Drill
HammerDrill Bit
13/32 in.
(10 mm)
Concrete
Concrete Install
13/32 in.
(10 mm)
Wood Stud Install
Drill Bit
1/8 in.
(3 mm)
Wood
DIMENSIONS
Screwdriver
3
SUPPLIED PARTS AND HARDWARE
NOTE: Not all hardware included in this kit will be used.
WARNING:
This product contains small items that could be a choking hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, DO NOT
return the damaged item to your dealer; Contact Sanus (See back page).
Never use damaged parts!
1
Wall Plate
(qty. 2)
7
Under Mounting Bracket
(qty. 2)
5
Left Soundbar Bracket
(qty. 1) 6
Right Soundbar Bracket
(qty. 1)
12
Washer
(qty. 4)
11
Spacer
(qty. 2)
9
M4 Screw
(qty. 2)
8
M5 X 8mm Screw
(qty. 2)
2
#08 Screw
(qty. 4)
4
Fischer Doutec 10
Drywall/Concrete Anchor
(qty. 4)
(qty. 4)
3
Washer (#8 Screw)
2.5 mm
