XSource
Streaming Media Player
Installation Manual
2Russound XSource Installation Guide
NOTICE:
IF YOU ARE NOT A RUSSOUND CERTIFIED INSTALLER,
YOU WILL NOT BE ABLE TO INSTALL AND CONFIGURE THIS PRODUCT
INTERNET CONNECTION REQUIRED FOR PRODUCT INSTALLATION
There are two things that must be done at the time of installation of this product that require a working internet connection:
1. Enter valid Russound Certied Installer credentials. The XSource is shipped in a locked state. It cannot be operated
without rst being congured by a Russound Certied Installer.
If you are a custom installation professional and wish to become authorized as a Russound Certied Installer, please contact
your Russound Sales Representative for more information.
Note: If you are a Russound Certied Installer and you plan on installing this product on a job site that may not have working
internet access, please congure the unit at your shop or other location where internet access is available BEFORE you take it to
the job site.
2. Firmware may be updated easily through Web Cong conguration. An internet connection is required for obtaining
the most recent rmware.
Note: If an internet connection will not be available at the place of installation, please download the latest rmware from the
Russound website to a laptop going to the job site.before
Russound Certied Installer credentials must be entered
through the Web Cong conguration web pages.
When the XSource is shipped from Russound, it will only operate
in a "locked" state. In this state, no audio or control is available.
In order to unlock the system, valid Russound Certied Installer
credentials must be entered using our convenient Web Cong
browser-based conguration utility.
When the XSource is rst powered on, a message will appear
on any compatible user interfaces and the MyRussound App
indicating that the device must be unlocked. The message
will contain the IP address of the controller. Using your mobile
device or computer, browse to the controller’s IP address (type
http:// and then the IP address).
If you are using the MyRussound App, the IP address appears
as a link that will direct you to Web Cong via your local web
browser.
If you do not have a valid Russound Certied Installer
credential, please contact your Russound Sales Representative.
LOCKDOWN FEATURE
Lockdown Feature
3Russound XSource Installation Guide
Table of Contents
Product Overview ...............................................................................3
Web Conguration..........................................................................4-5
Ethernet Connection and Factory Reset .....................................5
Installation Overview .........................................................................6
Installation ............................................................................................. 7
Conguration ..................................................................................8-12
Troubleshooting ................................................................................13
Audio Connection with MCA-Series Controllers ....................14
Additional Audio Connections .....................................................15
Network Best Practices ....................................................................16
Technical Specications ..................................................................17
Safety Instructions ............................................................................18
TABLE OF CONTENTS / PRODUCT OVERVIEW
Product Overview
The XSource Streaming Audio Player is designed to oer a
simple-to-install and simple-to-congure streaming media
solution to add high quality streaming audio content to any
audio system. The XSource can be used as a single stereo
audio streaming source for a single room, or supply a single
audio stream to a larger whole-house system through its
easy-to-use analog line-level/digital (coax/optical) outputs.
The XSource allows for expansion to up to 16 streaming
rooms of audio in a single installation with any combination
of other XStream®™ Series streaming products from
Russound. When paired with a Russound multi-room
controller, system expansion is possible up to 8 independent
audio sources and up to 48 total rooms of audio.
In addition to oering streaming audio from popular
internet sources, the XSource also oers streaming of
local DLNA™-compliant audio. In addition a built-in USB
port allows users to connect an external ash drive or an
externally-powered USB hard drive for use as additional
music sources.
Features
• Independent streaming audio player
• Built-in AirPlay streaming with full metadata to iOS/
Android apps or XTS touchscreens
• Hi-Res audio streaming support up to 24-bit/192 kHz
• USB for Flash or external USB Hard drive-based music
collections
• Digital coax/optical or analog output
• Can be integrated (as a source) with a Russound multi-
room system or standalone (as a zone) when used with any
brand of amplier or receiver
• Controlled with the MyRussound App and fully compatible
with the Russound XTS in-wall touchscreen
• Bass, Treble, and Loudness settings available through the
MyRussound App
• Supports local favorites
• Onboard browser-based conguration, accessible from a
smartphone or tablet
• Mix and match with other XStream® Series components
for versatile system designs
• Built-in slide connectors for physical coupling of multiple
units
