Installation assistance available at:

www.rockfordfosgate.com/rftech

R O C K F O R D F O S G A T E . C O M

600 South Rockford Drive • Tempe, Arizona 85281 United States

Direct: (480) 967-3565 • Toll Free: (800) 669-9899

Installation & Operation

Serial Number: Date of Purchase:

RM18D2 RM18D2B RM18D4• •

RM18D4B RM110D2 RM110D2B• •

RM110D4 RM110D4B RM112D2• •

RM112D2B RM112D4 RM112D4B• •

SUBWOOFERS

Dear Customer,

Congratulations on your purchase of the world’s ﬁnest brand of car audio

products. At Rockford Fosgate we are fanatics about musical reproduc-

tion at its best, and we are pleased you chose our product. Through

years of engineering expertise, hand craftsmanship and critical testing

procedures, we have created a wide range of products that reproduce

music with all the clarity and richness you deserve.

For maximum performance we recommend you have your new Rockford

Fosgate product installed by an Authorized Rockford Fosgate Dealer,

as we provide specialized training through Rockford Technical Training

Institute (RTTI). Please read your warranty and retain your receipt and

original carton for possible future use.

Great product and competent installations are only a piece of the puzzle

when it comes to your system. Make sure that your installer is using

100% authentic installation accessories from Rockford Fosgate in your

installation. Rockford Fosgate has everything from RCA cables and

speaker wire to power wire and battery connectors. Insist on it! After all,

your new system deserves nothing but the best.

To add the ﬁnishing touch to your new Rockford Fosgate image, order

your Rockford accessories, which include everything from T-shirts to

hats.

Visit our web site for the latest information on all Rockford products;

www.rockfordfosgate.com

or, in the U.S. call 1-800-669-9899 or FAX 1-800-398-3985. For all other

countries, call +001-480-967-3565 or FAX +001-480-966-3983.

Table of Content

If, after reading your manual, you still have questions regarding this prod-

uct, we recommend that you see your Rockford Fosgate dealer. If you need

further assistance, you can call us direct at . Be sure to 1-800-669-9899

have your serial number, model number and date of purchase available

when you call.

Safety

This symbol with “WARNING” is intended

to alert the user to the presence of important

instructions. Failure to heed the instructions

will result in severe injury or death.

This symbol with “CAUTION” is intended to

alert the user to the presence of important

instructions. Failure to heed the instructions

can result in injury or unit damage.

• To prevent injury and damage to the unit, please read and follow the

instructions in this manual. We want you to enjoy this system, not get

a headache.

• If you feel unsure about installing this system yourself, have it installed

by a qualiﬁed Rockford Fosgate technician.

• Before installation, disconnect the battery negative (-) terminal to

prevent damage to the unit, ﬁre and/or possible injury.

Introduction

Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners. Speciﬁcations subject to change without notice.

PRACTICE SAFE SOUND

Continuous exposure to sound pressure levels over 100dB may cause

permanent hearing loss. High powered auto sound systems may

produce sound pressure levels well over 130dB. Use common sense

and practice safe sound.

PRATIQUEZ UNE ÉCOUTE SANS RISQUES

Une exposition continue à des niveaux de pression acoustique upérieurs à

100 dB peut causer une perte d’acuité auditive permanente. Les systèmes

audio de forte puissance pour auto peuvent produire des niveaux de

pression acoustique bien au-delà de 130 dB. Faites preuve de bon sens et

pratiquez une écoute sans risques

PRACTIQUE EL SONIDO SEGURO

El contacto continuo con niveles de presión de sonido superiores a 100

dB puede causar la pérdida permanente de la audición. Los sistemas de

sonido de alta potencia para automóviles pueden producir niveles de

presión de sonido superiores a los 130 dB. Aplique el sentido común y

practique el sonido seguro.

PRAKTIZIEREN SIE SICHEREN SOUND

Fortgesetzte Geräuschdruckpegel von über 100 dB können beim

Menschen zu permanentem Hörverlust führen. Leistungsstarke

Autosoundsysteme können Geräuschdruckpegel erzeugen, die weit über

130 dB liegen. Bitte wenden Sie gesunden Menschenverstand an und

praktizieren Sie sicheren Sound.

OSSERVATE LE REGOLE DEL SUONO SENZA PERICOLI

La costante esposizione a livelli di pressione acustica al di sopra dei

100dB possono causare la perdita permanente dell’udito. I sistemi

audio ad alta potenza possono produrre livelli di pressione acustica ben

superiori ai 130dB. Si consiglia il buon senso e l’osservanza delle regole

del suono senza pericoli

2 Introduction

3 Speciﬁcations

4-5 Enclosures

Sealed or Vented

Wiring

6-7 Additional Languages

French

Spanish

German

Italian

8 Limited Warranty Information

Enclosures

Carton Contents

• (1) Marine Grade Subwoofer • (1) Socket head driver bit

• (1) Grille • Installation and Operation Manual

• (8) Socket Head Stainless Screws

Recommended Enclosures

This manual outlines two speciﬁc types of enclosures that provide distinctly dif-

ferent performance. This section is to help you decide which type is best for your

application.

Sealed Enclosures

Sealed enclosures are the simplest to build. The most important part of building

a sealed enclosure is to make sure that the enclosure is airtight. Using glue and

some type of sealant on all seams will ensure solid construction and prevent air

leaks. The box volume will directly impact the performance of the speaker. Larger

enclosures will provide ﬂatter response and deeper bass where smaller boxes will

provide a bump in the response curve and generally higher output for greater SPL.

Advantages of sealed enclosures:

• Small enclosures

• Linear (Flat) response

• No port noise

• High power handling at all frequencies

• Excellent for sound quality

• Extended low frequency output when compared to vented enclosures

Vented Enclosures

Vented enclosures vary only from the sealed enclosure in that a vent or port is

added to “tune” the enclosure. The enclosures recommended are designed for

great overall performance. Larger boxes tend to be easy to tune to lower frequen-

cies while medium and small boxes are easier to tune to higher frequencies. The

vented design is less linear in response than the sealed box but with noticeably

more output at the tuning frequency.

Advantages of vented enclosures:

• Higher average output than sealed

• Tuning frequency can be easily adjusted by changing port length

• Deep bass response with lower power requirements

• Great for high output with limited power

Inﬁnite Bafﬂe Design

These designs typically called “IB”, are the easiest enclosure types to build. The

reason is that you are not actually building an enclosure, but rather simulating one.

This is done by closing off a cavity area (ie; car trunk, enclosed area of a boat hull)

with a bafﬂe board. This creates your “IB” sub-woofer system. Essentially, an “IB”

design can just be considered a large sealed enclosure design. Given that an “IB”

design does not rely on a volume of air for its suspension, the low frequency output

is driven by the speaker’s inherent damping or “Qtc”.

Advantages of inﬁnite bafﬂe design:

• Easy to build

• Light-weight

• Deep bass response with lower power requirements

Vented vs Sealed vs Inﬁnite Bafﬂe

The graph shown here is a sample of how SPL and Excursion differs between the

various enclosures.

Building an Enclosure

To work properly, the walls of the enclosure must be rigid and not ﬂex when sub-

jected to the high pressures generated by the speaker’s operation. For optimum

performance, we recommend using 3/4” MDF (Medium Density Fiberboard) and

internal bracing. The enclosure should be glued together and secured with nails

or screws.

Calculating Volume

Calculating volume is merely a matter of measuring the dimensions in inches and

using the formula: H x W x D divided by 1728 (cubic feet). See block below.

Box Volume Height” x Width” x Depth”

Divided by (cubic feet) 1728

If two facing sides are of uneven length, add them together and divide by two to

take the average. Using this number will give you the volume without the necessity

of calculating the box in sections and adding the sections together. The thickness

of the bafﬂe material reduces the internal volume so this must be subtracted from

the outside dimensions to determine the internal volume. The speaker itself also

reduces the internal volume. The amount of air displaced by each model is listed

on the speciﬁcation sheet and should also be subtracted from the gross volume

calculation.

Sealed Enclosure

NOTE: Vb is the internal volume, before any speaker and/or port dis-

placement is added. All external dimensions were based on the use of

3/4” (1.90cm) materials.

NOTE: When using enclosures other than recommended, call Technical Support

for correct application.

Optimum Sealed Enclosure Recommendation

Sealed Enclosures 8” 10” 12”

Total Internal Volume cu. ft. (Liter) 0.55 (15.62) 1.1 (31.15) 1.65 (46.72)

Woofer Displacement cu. ft. (Liter) 0.05(1.41) 0.1 (2.83) 0.12 (3.4)

Vb - Net Internal Volume cu. ft. (Liter) 0.50 (14.2) 1.0 (28.32) 1.53 (43.32)

F3 - 3dB Point (Hz) 47.7 58.4 43.1

Qtc - Enclosure Damping 1.19 0.66 0.88

H - Height - inch (cm) 12 (30.48) 14.0 (35.56) 15.0 (38.1)

W - Width - inch (cm) 12 (30.48) 16.0 (40.64) 16.0 (40.64)

D - Depth - inch (cm) 10 (25.4) 13.25 (33.66) 15.0 (38.1)

Recommended Sealed Enclosure Volume Range

Sealed Enclosures 8” 10” 12”

Vb - Volume range cu. ft.

(Liter)

0.4 to 0.75

( )11.34 - 21.24

0.75 to 1.25

( )21.24 - 35.4

1.25 to 1.75

( )35.4 - 49.55

IMP(ohms)
