Instrukcja obsługi REVO VRS-MULTI
Przeczytaj poniżej 📖 instrukcję obsługi w języku polskim dla REVO VRS-MULTI (5 stron) w kategorii pilot. Ta instrukcja była pomocna dla 15 osób i została oceniona przez 2 użytkowników na średnio 4.5 gwiazdek
Strona 1/5
Overview
USB Mini-B port
Activity indicator
Locking shutter release
Sleep
Grid line
Zoom rocker
Start/Stop
1/4”-20 mount
Remote clip
S1 remote cable
(3-pin connector)
S2 remote cable
(Multi Terminal)
2
4
1
3
9
10
11
8
5
6
7
1
2
3
4
5
6
7
8
9
10
11
Thank you for choosing Revo.
The Revo VRS-Multi is a wired remote for Sony
camcorders, mirrorless and point-and-shoot cameras that
utilize lenses with power-zoom capability. Enjoy smooth
video operation with the variable-speed zoom rocker,
which allows electronic control between wide and
telephoto. Whether capturing photo or video, you can
trigger the shutter for single shooting, or lock it open
when in continuous or bulb modes. Composing your
frame is also a breeze with the ability to cycle through
your available grid-lines at the touch of a button. The
convenient remote clip allows you to mount the remote on
your tripod or rig so your controls are always within reach.
Specifications
•Dimensions (H × W × D): 3.9 × 1.4 × 0.6 ″ ″ ″
(10 × 3.5 × 1.6 cm)
•Weight: 0.9 oz. (26 g)
•Cable length: 3.3 (1 m)’
Locking shutter release: Press halfway to focus, and
press fully to release the shutter. Slide the lock in place to
keep the shutter button pressed for bulb or continuous
shooting. When the camera is set to bulb, the shutter will
remain open with the lock engaged. When your camera's
drive is set to continuous, the shutter will release
continuously (speed varies depending on camera).
Sleep: Put your camera to sleep to conserve battery
power, or wake your camera from sleep mode. The
activity indicator will be green when in use, and turn off
when in sleep mode.
Grid line: Cycles through available grid-line options.
Zoom rocker: Electronic zoom control between wide
and telephoto for select Sony cameras with compatible
power zoom lenses attached. The rocker switch is
pressure sensitive, and the zoom speed will vary
depending on how hard the button is pressed.
Start/Stop: Starts and stops video recording.
Specyfikacje produktu
| Marka: | REVO |
| Kategoria: | pilot |
| Model: | VRS-MULTI |
