USER MANUAL
PORTABLE SPEAKER SYSTEM
WITH BLUETOOTH AND FM
X-787
1
X-787
Operation Manual
Technical support: www.real-el.com
ENG
Congratulations on your purchase of the REAL-EL speaker system!
COPYRIGHT
© 2021. ENEL GROUP OU.
This Manual and information contained in are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
1. BUYER RECOMMENDATIONS
Ϝ Unpack the device carefully. Make sure there are no accessories left in the box. Check up
WKHGHYLFHIRUGDPDJHLIWKHSURGXFWZDVGDPDJHGGXULQJWUDQVSRUWDWLRQDGGUHVVWKHԛUP
which carried out the delivery; if the product functions incorrectly, address the dealer at
once.
Ϝ Check up the package contents and availability of the warranty card.
Ϝ Do not switch on the speaker system immediately after you bring it into a room from
environment with negative temperature! After unpacking, the speaker system should be kept
in conditions of room temperature for at least 4 hours.
Ϝ Before installing and using the speaker system, read this Manual carefully and keep it for
future reference.
2. PACKAGE CONTENTS
Ϝ Portable speaker system — 1 pc
Ϝ FM Antenna / 3.5 mm mini-jack to 3.5 mm mini-jack signal cable — 1 pc
Ϝ USB to Micro USB power cable — 1 pc
Ϝ Remote control (RC) — 1 pc
Ϝ Microphone holder — 2 pcs
Ϝ User manual — 1 pc
Ϝ Warranty card — 1 pc
1
1
2
2
5
7
CONTENTS
1. BUYER RECOMMENDATIONS ..................................................
2. PACKAGE CONTENTS ............................................................
3. SAFETY PRECAUTIONS ..........................................................
4. TECHNICAL DESCRIPTION ......................................................
5. CONNECTION AND OPERATION ...............................................
6. TECHNICAL SPECIFICATIONS ..................................................
2
X-787
Operation Manual
Technical support: www.real-el.com
ENG
3. SAFETY PRECAUTIONS
ϜDo not open the portable speaker system (PSS) and do not perform repairs by yourself.
6HUYLFHDQG UHSDLUV VKRXOG EH SHUIRUPHG RQO\ E\ TXDOLԛHG VSHFLDOLVWV DW DXWKRUL]HG VHUYLFH
FHQWHUV7KHOLVWRIDXWKRUL]HGVHUYLFHFHQWHUVLVon www.real-el.com
ϜMake sure that foreign objects do not get inside the holes of the PSS.
ϜProtect the PSS from high humidity, water and dust.
ϜProtect the PSS from heating: do not place it closer than 1 m from a heat source. Do not
expose it to direct sunlight.
Ϝ Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.
Ϝ In case of PSS does not work properly. Please contact place of purchase or service center.
Special features
Ϝ FM radio
Ϝ Remote control
Ϝ TWS - simultaneous connection of two systems to one audio source
Ϝ Bluetooth audio transmission
Ϝ USB, Micro SD (TF)
Ϝ Two microphone inputs for Karaoke with Echo adjustment
Ϝ AUX connection for use with PC, TV and other sources
Ϝ EQ function
Ϝ Extended running time
Ϝ RGB backlight
4. TECHNICAL DESCRIPTION
Control panel
" MIC: 6.3 mm jack microphone jack
# AUX: 3.5 mm mini-jack for audio signal connecting (phone, MP3 player, etc.)
$ TF CARD: Micro SD card slot
% USB port
& Power ON/OFF
' Indicator
( Charging DC 5V
) ECHO +/-: Microphone echo adjustment
* DEL/TWS:
FM station delete (long press in Radio mode);
Connect an additional speaker (Bluetooth mode only)
+ FM+/ : Next track (short press in Player and Bluetooth mode);
Navigation on the track (long press in Player mode);
Next track/station (in Radio mode)
, FM-/ : Previous track (in Player and Bluetooth mode);
Navigation on the track (long press in Player mode);
Previous station (in Radio mode)
- IR receiver
. Display
/ (46RXQG(ԚHFWPRGHVKRUWSUHVV5HVHWORQJSUHVV
0 MIC PRI: mute with a connected microphone
1 LIGHT: switching backlight modes (short pressing);
7XUQLQJRQRԚWKHEDFNOLJKWORQJSUHVVLQJ
