Strona 1/8
PORTABLE SPEAKER SYSTEM
with BLUETOOTH and FM
USER MANUAL
X-757
Technical support: www.real-el.com
ENG
1
X-757
ENG
Congratulations on your purchase of the REAL-EL speaker system!
COPYRIGHT
© 2020. ENEL GROUP OU.
This Manual and information contained in are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
1. BUYER RECOMMENDATIONS
• Unpack the device carefully. Make sure there are no accessories left in the box. Check up the
device for damage; if the product was damaged during transportation, address the rm, which fi
carried out the delivery; if the product functions incorrectly, address the dealer at once.
• Check up the package contents and availability of the warranty card. Make sure the warranty card
has a shop stamp, a legible signature or the seller’s stamp and purchase date, and the goods
number corresponds to that in the warranty card. Remember: in case of warranty card loss or
discrepancy of numbers you forfeit the right for warranty repairs.
• Do not switch on the speaker system immediately after you bring it into a room from environment
with negative temperature! After unpacking, the speaker system should be kept in conditions of
room temperature for at least 4 hours.
• Before installing and using the speaker system, read this Manual carefully and keep it for future
reference.
2. PACKAGE CONTENTS
• Portable speaker system — 1 pc
• 3.5 mm mini-jack to 3.5 mm mini-jack signal cable — 1 pc
• USB to micro USB power cable — 1 pc
• Remote control (RC) — 1 pc
• User’s manual — 1 pc
• Warranty card — 1 pc
User manual
Technical support: www.real-el.com
ENG
X-757
2
User manual
3. SAFETY PRECAUTIONS
• Do not open the portable speaker system (PSS) and do not perform repairs by yourself. Service
and repairs should be performed only by qualified specialists at authorized service centers. The list
of authorized service centers is on www.real-el.com
• Make sure that foreign objects do not get inside the holes of the PSS.
• Protect the PSS from high humidity, water and dust.
• Protect the PSS from heating: do not place it closer than 1 m from a heat source. Do not expose it
to direct sunlight.
• Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.
• In case of PSS does not work properly. Please contact place of purchase or service center.
Special features
• FM radio
• Remote control
• TWS - simultaneous connection of two systems to one audio source
• Bluetooth audio transmission
• USB, Micro SD (TF)
• AUX connection for use with PC, TV and other sources
• Equalizer adjustment high and low frequency
• Extended running time
• RGB backlight
4. TECHNICAL DESCRIPTION
Control panel
a MIC: 6.3 mm jack microphone jack
b AUX: 3.5 mm mini-jack for audio signal connecting (phone, MP3 player, etc.)
c TF CARD: Micro SD card slot
d Display
e USB port
f Power ON/OFF
g Charging DC 5V
h Indicator
i 0-9: Track number selection (in Player mode);
Station number/frequency selection (in Radio mode)
j MODE: Bluetooth/FM/USB/Micro SD/AUX (short press);
Turn ON/OFF prompt system tone (long press).
k LIGHT: Switching backlight modes
l DEL/TWS:
FM station delete (long press in Radio mode);
Connect an additional speaker (Bluetooth mode only).
m EQ: Sound E ect mode (short press); Reset (long press)ff
n FM+/ : Next track (short press in Player and Bluetooth mode);
Navigation on the track (long press in Player mode);
Next track/station (in Radio mode).
