[en] Instruction manual

Gas hob

1 Pan supports

2 Control knobs

3 Auxiliary burner (up to 1 kW)

4 Semi-rapid burner (up to 1.75 kW)

5 Rapid burner (up to 3 kW)

6 Double-flame wok burner (up to 3.3 kW)

7 Electric hob 1000 W

ÚÚ Table of contents

[en]Instruction manual

Safety precautions..................................................................... 3

Your new appliance ................................................................... 3

Accessories .........................................................................................3

Gas burners................................................................................ 4

Switching on manually .......................................................................4

Switching on automatically................................................................4

Safety system ......................................................................................4

Switching off a burner........................................................................4

Power levels.........................................................................................4

Warnings...............................................................................................4

Cooking guidelines.............................................................................5

Electric hob ................................................................................ 5

Power control switch ..........................................................................5

Suggestions .........................................................................................5

Cooking pans ............................................................................. 6

Suitable pans.......................................................................................6

Precautions for use ............................................................................6

Cleaning and maintenance ....................................................... 6

Cleaning................................................................................................6

Maintenance ........................................................................................6

Trouble shooting........................................................................ 7

Technical Assistance Service................................................... 7

Warranty conditions............................................................................7

Used appliances and packaging .............................................. 7

Environmentally-friendly waste management ................................7

2&$









2&$(

























ã=Safety precautions

Read these instructions carefully. Reading these instructions

will enable you to use your appliance safely and effectively.

Keep the operation and installation instructions and provide

them along with the appliance if it is passed on to another user.

The manufacturer is exempt from all responsibility if the

requirements of this manual are not complied with.

The graphics in this instruction manual are given as a guide

only.

Do not remove the appliance from its protective packaging until

it is installed in the unit.

Do not switch on the appliance if it is damaged in any way.

Contact our Technical Assistance Service.

This appliance is class 3 type, according to the EN 30-1-1

regulation for gas appliances: built-in appliance.

This appliance can only be installed in a well-ventilated place in

accordance with existing regulations and ventilation

specifications. The appliance must not be connected to a

combustion product removal device.

The place in which the appliance is installed must have fully-

functioning ventilation, in accordance with the regulations.

Before installing your new hob, ensure that it is being installed

according to the assembly instructions.

This appliance leaves the factory set to the type of gas that is

indicated on the specifications plate. If this needs to be

changed, please consult the assembly instructions.

All operations relating to installation, regulation and conversion

to other types of gas must be carried out by an authorised

installation engineer, respecting the applicable regulations,

standards and the specifications of the local gas and electricity

providers. You are recommended to contact the Technical

Assistance Service to convert to another type of gas.

This appliance has been designed for home use only, not for

commercial or professional use. This appliance cannot be

installed on yachts or in caravans. The warranty will only be

valid if the appliance is used for the purpose for which it was

designed.

This appliance is only intended for cooking purposes, not as a

heating system.

This appliance is not intended for operation with an external

clock timer or a remote control.

Never leave the appliance unattended during operation.

This appliance may be used by children 8 years old and older

and by persons with reduced physical, sensory or mental

capacity or a lack of experience or knowledge if they are

supervised or they have been instructed about the safe use of

the appliance and have understood the associated dangers.

Never let children play with the appliance. Cleaning and user

maintenance must not be carried out by unsupervised children.

The hotplates and surrounding area become very hot. Never

touch the hot surfaces. Children under 8 years old must be

kept at a safe distance from the appliance.

The hotplates become very hot. Never place combustible items

on the hob. Never place objects on the hob.

Do not store or use corrosive chemicals, steamers,

inflammable materials or non-food products below or near this

domestic appliance.

Fat or oil which is overheated can catch fire easily. Do not leave

oil or fats to heat up unattended. If oil or fats do catch fire,

never use water to put the fire out. Risk of burns! Put the fire out

by covering the pan with a lid and switch off the hotplate.

Pans which are damaged, are not the right size, hang over the

edge of the hob or are not positioned correctly can cause

serious injuries. Follow the advice and warnings provided

relating to the cooking pans.

Do not subject the appliance to draughts. These might blow out

the burners.

While using your hob, prevent any draughts and do not spill any

cold liquids on it, as this may cause the glass to break.

Do not clean the hob using a steam cleaner. Risk of electrocution!

In the event of a malfunction, turn off the appliance’s gas and

electricity supply. For repairs, call our Technical Assistance

Service.

Do not tamper with the appliance's interior. If necessary, call

our Technical Assistance Service.

If one of the control knobs will not turn, do not force it. Call the

Technical Assistance Service immediately, so that they can

repair or replace it.

Cracks or fractures in the glass may cause electric shocks.

Switch off the circuit breaker in the fuse box. Contact the after-

sales service.

Your new appliance

Page 2 shows an overall view of your new appliance as well as

the burner power.

Accessories

The following accessories can be purchased from the

Technical Assistance Service:

--------

The manufacturer accepts no liability if these accessories are

not used or are used incorrectly.

Additional wok pan support

Only for use on wok burners

with pans with a round base.

The additional wok pan sup-

port should be used to pro-

long the appliance's useful

life.

Additional coffee maker sup-

port

Only for use on the auxiliary

burner with pans which are no

more than 12 cm in diameter.

Specyfikacje produktu

Marka:	Profilo
Kategoria:	piec
Model:	OA26H6110D
Kolor produktu:	Czarny
Typ kontroli:	obrotowy
Wbudowany wyświetlacz:	Nie
Długość przewodu:	1 m
Położenie urządzenia:	Wbudowany
Częstotliwość wejściowa AC:	50 - 60 Hz
Napięcie wejściowe AC:	220-240 V
Wysokość produktu:	45 mm
Szerokość produktu:	590 mm
Głębokość produktu:	520 mm
Waga produktu:	12000 g
Szerokość opakowania:	580 mm
Wysokość opakowania:	145 mm
Głębokość opakowania:	650 mm
Szerokość przedziału instalacji:	560 mm
Prąd:	3 A
Certyfikaty:	CE
Wysokość przedziału instalacji:	45 mm
Waga wraz z opakowaniem:	13000 g
Rodzaj płyty grzejnej:	Gaz
Rodzaj gazu:	Gazu płynny (LPG)
Typ górnej powierzchni:	Szkło
Liczba palników/stref gotowania:	4 stref(y)
Liczba palników:	4 stref(y)
Liczba płytek elektrycznych:	0 stref(y)
Zapłon elektroniczny:	Tak
Pozycja palnika/strefy grzewczej 1:	Lewy tylny
Źródło zasilania palnika/strefy grzewczej 1:	Gaz
Typ palnika/strefy grzewczej 1:	Regularny
Moc palnika/strefy grzewczej 1:	1700 W
Pozycja palnika/strefy grzewczej 2:	Lewy przód
Źródło zasilania palnika/strefy grzewczej 2:	Gaz
Typ palnika/strefy grzewczej 2:	Bardzo duży
Moc palnika/strefy grzewczej 2:	3300 W
Pozycja palnika/strefy grzewczej 3:	Prawy tył
Źródło zasilania palnika/strefy grzewczej 3:	Gaz
Typ palnika/strefy grzewczej 3:	Regularny
Moc palnika/strefy grzewczej 3:	1700 W
Pozycja palnika/strefy grzewczej 4:	Prawy przód
Źródło zasilania palnika/strefy grzewczej 4:	Gaz
Typ palnika/strefy grzewczej 4:	Wrzenie
Moc palnika/strefy grzewczej 4:	1000 W
Materiał podtrzymujący naczynie:	Stal nierdzewna
Przyłącza (prąd):	1 W
Pozycja panelu sterowania:	Górna prawa strona
Przyłącza (gaz):	7700 W
Kształt strefy gotowania 1:	Okrągły
Strefa gotowania 3 kształt:	Okrągły
Strefa gotowania 4 kształt:	Okrągły
Kształt strefy gotowania 2:	Okrągły
Normalny palnik:	1700 W
Głębokość komory instalacji (min):	480 mm
Głębokość komory instalacji (maks):	490 mm
Kolor ramy:	Czarny
Palnik woka:	Tak
Duży palnik:	1700 W
Palnik o wolnym ogniu:	1000 W
Bardzo duży palnik o dużej prędkości:	3300 W
Pozycja palnika woka:	Lewy
