Strona 1/3
Technical Support
If you need technical support with your Planet Audio product or have
quesons about its use, please contact us:
805.751.4853
www.PlanetAudioUSA.com
5
Due to ongoing product development, specicaons are subject to change without noce.
AC12D_0414
1
Congratulaons on your purchase of the Planet Audio “AC” Series
Subwoofer. Planet Audio takes great pride in producing products
that sound and look great, but stand up to the daily rigors applied
by audio enthusiasts around the world.
AC12D 12” (30 cm) Subwoofer
Dual 4 Ω Voice Coils
1800 W Peak Power Handling
Customizable Trim Ring
Operates in a sealed or ported enclosure
2
4
Enclosures
The AC12D is designed to work in a sealed or ported enclosure.
Since the woofer has pole-vent, it needs a minimum clearance from the
rear wall of the enclosure of 0.75” (19 mm). Below you will nd the
dimensions to make the enclosure to suit the subwoofer, it has been
designed for maximum output while retaining great sound quality.
The dimensions have already accounted for the volume displacement of
the subwoofer, and using 3/4” (19mm) MDF.
All dimensions are external.
Sealed Dimensions:
Length (L) : 19” (483 mm)
Width (W) : 12” (305 mm)
Height (H) : 12” (305 mm)
Cutout Diameter: 11” (280 mm)
Int. Volume: 1.25 ³
Enclosure Dimensions
Ported Dimensions:
Length (L) : 24” (610 mm)
Width (W) : 16” (406 mm)
Height (H) : 13” (330 mm)
Cutout Diameter: 11” (280 mm)
Port Dimensions: 3” (Dia.) x 5” (76 (Dia.)mm x 203 mm)
Tuning Freq: 34 Hz
Int. Volume: 2.0 ³
4
Mulple Subwoofers
8 Ω 2 Ω
Wiring your Subwoofer
Parallel Series
4 Ω
1 Ω
3
Product Specicaons
Impedance Dual 4 Ω
Resonant Frequency 32 Hz
Qts 0.756
Qms 4.42
Qes 0.912
Vas 2.132 (60.372 liters)
10 mm Xmax
Sensivity (1 W/ 1 m) 88 dB
Peak Power Handling 1800 W
Mounng Depth 5- 3/8” (137 mm)
Cutout Diameter 11” (280 mm)
