Strona 1/12
12016-02-19 #:150-9066-6 (2018-10-22)
ENG
KOP549-XTR, KOP555-XTR
KOP549-S-XTR, KOP555-S-XTR
22016-02-19 #:150-9066-6 (2018-10-22)
Symbols
ENG
WARNING
ENG #
Skip to step.
ENG
x3
Screws must get at least three
full turns and t snug.
ENG
Front of mount.
ENG
F
Do not overtighten screws.
ENG
Tools Needed for Assembly.ENG
ENG - Do not begin to install product until you have read and understood the instructions and warnings
contained in this user guide. Before installing make sure the supporting surface will support the combined load of
the equipment and hardware. Screws must be tightly secured. Do not overtighten screws or damage can occur
and product may fail. Never exceed the Maximum Load Capacity. Always use an assistant or mechanical lifting
equipment to safely lift and position equipment. This product is intended for indoor use only. Use of this product
outdoors could lead to product failure or personal injury. To reduce the risk of electric shock or re, do not expose
product to water or moisture. Be sure power cord is routed so that it will not be tripped on, stepped on, or pinched
by heavy items. Avoid overloading electrical outlets or extension cords. Always disconnect the power cord from
the power outlet when installing, servicing, or not using the product for an extended period of time. Do not block
ventilation slots or fan exhaust on product. Blocking airow could damage product. Arrange product to allow air to
ow freely around product. Keep product away from direct sunlight or any source of heat. For support please call
800-4-SIGNAGE.
WARNING
32016-02-19 #:150-9066-6 (2018-10-22)
Parts List KOP549-XTR
KOP549-S-XTR
Part #
KOP555-XTR
KOP555-S-XTR
Part #Description Qty
Akiosk BLK
kiosk SLV
1 151-T1628
151-4628
150-T1730
150-4730
BM5 x 12mm (not used) 4 520-1027 520-1027
CM5 X 25mm (not used) 4 520-9543 520-9543
DM6 x 12mm (not used) 4 520-1128 520-1128
EM6 x 25mm (not used) 4 520-1208 520-1208
FM8 x 12mm (not used) 4 520-9571 520-9571
GM8 x 25mm (not used) 4 520-1031 520-1031
HM5/M4/M6 multi washer
(not used)
4 580-1398 580-1398
Ispacer (not used) 4 540-1059 540-1059
Jkey 2 565-0301 565-0301
Kt-wrench 1 560-1718 560-1718
Lpower strip 1 600-0370 600-0370
Mcable tie 6 560-1756 560-1756
Ndisplay 1 XHB492 XHB552
Parts (Before beginning, make sure you have all parts shown below).
ENG
A (1)
N (1)
kiosk
B (4)
M5 x 12 mm
C (4)
M5 x 25 mm
D (4)
M6 x 12 mm
E (4)
M6 x 25 mm M8 x 12 mm
F (4)
M8 x 25 mm
G (4)
M5/M4/M6 washer
H (4)
spacer
I (4)
K (1)
T-wrench
L (1)
power strip
cable tie
M (6)
J (2)
key
display
