Strona 1/2
SPECIFICATIONS
Voltage: 18V
No Load Speed: 15,500/min
Max. Air Speed: 78km/hr
Weight: 1.0kg
CORDLESS
BLOWER /
INFLATOR
ORIGINAL INSTRUCTIONS
ozito-diy.co.uk
PXWBS-200U
WHAT’S IN THE BOX
Cordless Blower / Inator
Ination Adaptors x 3
TROUBLESHOOTING
SPARE PARTS
BLOWER / INFLATOR SAFETY WARNINGS
WARNING! When using mains-powered tools, basic safety precautions, including the
following, should always be followed to reduce risk of fire, electric shock, personal injury
and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
Before you connect the charger to the mains supply make sure that the data on the rating plate are identical to the mains data.
If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid a hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this tool. The insulation system is for
added protection against injury resulting from a possible electrical insulation failure within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the extension lead for signs of
damage, wear and ageing. Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power
input of the tool or which is damaged or defective may result in a risk of re and electric shock.
The power supply for this products charger should be protected by a residual current device (rated at 30mA or less). A residual current
device reduces the risk of electric shock.
GENERAL POWER TOOL SAFETY WARNINGS
ELECTRICAL SAFETY
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the
warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power
tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will reduce risk
of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of
electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the
risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your
nger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct power
tool will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool
before making any adjustments, changing accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts
and any other condition that may affect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to
bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
5. Battery tool use and care
a. Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of
battery pack may create a risk of re when used with another battery pack.
b. Use power tools only with specifically designated battery packs. Use of any other battery packs may
create a risk of injury and re.
c. When battery pack is not in use, keep it away from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal objects, that can make a connection from one
terminal to another. Shorting the battery terminals together may cause burns or a re.
d. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or burns.
6. Service
a. Have your power tool serviced by a qualified repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
• Keep air intake clean and air vents free of debris to avoid overheating the motor.
• Do not use cleaning agents to clean the plastic parts of the tool.
A mild detergent on a damp cloth is recommended. Water must never come into contact with
the tool.
• If the blower vibrates abnormally, stop motor immediately. Abnormal vibration usually indicates
a mechanical problem continued operation could lead to injury or damage.
WARNING! ALWAYS ENSURE THE TOOL HAS
COMPLETELY STOPPED AND THE BATTERY IS
REMOVED PRIOR TO ANY MAINTENANCE.
Problem Cause Remedy
Blower is not
starting
Battery is low in charge Charge battery
Battery not inserted
properly
Insert battery pack correctly
Possible clogging Clean the blower tube and blower outlet of
any leaves or debris.
Blower is not
operating at
full capacity
Possible clogging Clean the blower tube and blower outlet of
any leaves or debris.
Motor stops
while blowing
Battery has no power Charge battery
Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the
blower by an unauthorised person or by mishandling of the blower. This tool is designed for DIY use
- use in commercial or industrial environments will void the warranty.
• Always wear adequate protective clothing when operating the blower to avoid injuries to face, eyes,
hands, feet, head or hearing. Use safety glasses or a face shield, high boots or sturdy shoes, long
trousers, work gloves and ear defenders.
• Do not start the tool when it is upside down or when it is not in the operating position.
• Switch the motor off and remove the battery when the tool is not being used, left unattended, being
cleaned or being moved from one place to another.
• Do not operate the tool near people, especially children or pets. Turn it off if they get too close.
Maintain a safe distance of at least 5m from other people when using the tool.
• Never direct the blower direction nozzle towards bystanders or pets. Never blow debris in the
direction of bystanders or pets. The operator is responsible for accidents or hazards occurring to
other people or their property.
• Do not handle the battery or the tool with wet hands and do not use the tool in
the rain.
• Keep all the air intakes and the blower tube free of dust, lint, hair and other material that may cause
a reduction in air ow.
• Keep a balanced and stable stance while using the tool. Do not switch on the tool in enclosed or
poorly ventilated spaces or in the presence of inammable and/or explosive substances such as
liquids, gasses and powders.
• Do not get distracted and always concentrate on what you are doing. Use common sense. Never
operate the tool when you are tired, sick or under the inuence of alcohol or other drugs.
• Do not operate this appliance with long loose hair or loose tting jewellery. Tie long loose hair back
and remove loose tting jewellery.
• Only operate the tool during broad daylight or with adequate articial light.
• When the tool is not in use, store it in a dry place and out of reach of children.
• Only use the tool according to the instructions given in this manual.
• Check regularly that the screws are tight.
WARNING! When servicing, use only identical replacement parts. Use of any other parts
may create a hazard or cause product damage. To ensure safety and reliability, all repairs should
be performed by a qualied service technician.
WARNING! This appliance is not intended for use by young or inrm persons unless
supervised by a responsible person to ensure that they can use the appliance safely. Young
children should be supervised to ensure that they do not play with the appliance.
Battery & Charger sold
separately
DESCRIPTION OF SYMBOLS
THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING INSTRUCTIONS FOR YOUR
BATTERY CHARGER.
1. Before using the charger read all instructions and cautionary markings on the charger, battery pack and the product
using the battery pack.
2. This charger is not intended for any uses other than charging rechargeable batteries. Any other use may result in risk
of re, electric shock or electrocution.
3. Do not place any object on top of the charger or place the charger on a soft surface that may result in excessive
internal heat. Place the charger in a position away from any heat source.
4. To reduce risk of damage to the electric plug and cord, pull by the plug rather than the cord when disconnecting the
charger.
5. Make sure the cord is located so that it will not be stepped on, tripped over, or otherwise subjected to damage or
stress.
6. An extension cord should not be used unless absolutely necessary. Use of an improper extension cord could result in the risk
ofre, electric shock or electrocution.
7. Do not operate the charger if it has received a sharp blow, been dropped or otherwise damaged in any way. Have it
checked by an electrician or power tool repairer.
8. Do not disassemble charger. Take it to an electrician or power tool repairer when service or repair is required. Incorrect
reassembly may result in a risk of electric shock, electrocution or re.
9. To reduce risk of electric shock, unplug the charger from the outlet before attempting any cleaning. Removing the
battery pack will not reduce this risk.
10. Never attempt to connect 2 chargers together.
11. DO NOT store or use the tool and battery pack in locations where the temperature may reach or exceed 40ºC (such as inside
sheds or metal buildings in summer).
12. The charger is designed to operate on standard household electrical power (240 volts). Do not attempt to use it on any
other voltage!
13. The battery pack is not fully charged out of the carton. First read the safety instructions and then follow the charging
notes and procedures.
14. The longest life and best performance can be obtained if the battery pack is charged when the air temperature is
between 18 - 24ºC. Do not charge the battery pack in an air temperature below 10ºC or above 40ºC. This is important
and will prevent damage to the battery pack.
15. Do not incinerate the battery pack even if it is seriously damaged or is completely worn out. The battery can explode in
a re.
16. Never attempt to open the battery pack for any reason. If the plastic housing of the battery pack breaks or cracks, immedi-
ately discontinue use and do not recharge.
17. During charging, the battery must be placed in a well ventilated area.
BATTERY AND CHARGER SAFETY WARNINGS
MAINTENANCE
WARRANTY
OZITO UK Unit 9 Stadium Court, Wirral International Business Park, Plantation Road, Bromborough, Wirral, CH62 3QG 0516
All of our products undergo strict quality checks to ensure that they reach you in perfect
condition. In the unlikely event that your device develops a fault, please contact our service
department at the address shown on this guarantee card. You can also contact us by
telephone using the customer service number shown. Please note the following terms under
which guarantee claims can be made:
1. These warranty terms regulate additional warranty services, which the manufacturer
mentioned below promises to buyers of its new products in addition to their statutory
guarantee claims are not affected by this guarantee. Our guarantee is free of charge to you.
2. The warranty services only covers defects due to material or manufacturing faults on
a product which you have bought from the manufacturer mentioned below are limited to
either the rectication of said defects on the product or the replacement of the product,
whichever we prefer.
Please note that our devices are not designed for use in commercial, trade or professional
applications. A guarantee contract will not be created if the device has been used by
commercial, trade or industrial business or has been exposed to similar stresses during the
guarantee period.
3. The following are not covered by our guarantee:
- Damage to the device caused by a failure to follow the assembly instructions or due to
incorrect installation, a failure to follow the operating instructions (for example connecting
it to an incorrect mains voltage or current type) or a failure to follow the maintenance and
safety instructions or by exposing the device to abnormal environmental conditions or by
lack of care and maintenance.
- Damage to the device caused by abuse or incorrect use (for example overloading the
device or the use or unapproved tools or accessories), ingress of foreign bodies into the
device (such as sand, stones or dust, transport damage), the use of force or damage caused
by external forces (for example by dropping it).
- Damage to the device or parts of the device caused by normal or natural wear or tear or by
normal use of the device.
4. Your Product is guaranteed for a period of 60 months from the original date of purchase
and is intended for DIY (Do It Yourself) use only. Lithium Ion batteries and chargers are
covered by a 12 month warranty. Warranty excludes consumable parts. Guarantee claims
should be submitted before the end of the guarantee period within two weeks of the defect
being noticed. No guarantee claims will be accepted after the end of the guarantee period.
The original guarantee period remains applicable to the device even if repairs are carried
out or parts are replaced. In such cases, the work performed or parts tted will not result
in an extension of the guarantee period, and no new guarantee will become active for the
work performed or parts tted. This also applies if an on-site service is used.
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU MUST RETURN THE PRODUCT TO
THE PLACE OF PURCHASE WITH YOUR REGISTER RECEIPT.
Please refer to the restrictions of this warranty concerning wearing parts, consumables and
missing parts as set out in the service information in these operating instructions.
CUSTOMER SERVICE HELPLINE
GB: 0151 294 4488
IRL: 1850 882711
Ozito-diy.co.uk
Read instruction manual
Do not use in the rain or leave the blower outdoors while raining.
Keep bystanders away. Do not operate whilst people especially
children or pets are in the area.
Wear eye and ear protection.
Spare parts can be ordered from the Special Orders Desk at your local
Bunnings Warehouse or Homebase store.
For further information, or any parts visit
www.ozito-diy.co.uk or contact Ozito Customer Service:
Great Britain: 0151 294 4488
Ireland: 1850 882711
E-mail: enquires@ozito-diy.co.uk
2. FITTING THE BATTERY
Battery Charge Indicator
The purchased battery is equipped with a
battery charge indicator to show the state of
the battery charge.
Press the charge indicator button and look to
see which LED lights.
Battery requires
immediate charging
Low state of charge, requires charging soon.
Mid state of charge
Full state of charge.
Note: The battery needs to be removed from the tool to check the state of charge.
1 Connect the charger into a mains power outlet.
4 The charger LED will illuminate red signifying that the battery is charging.
3 With the battery sitting on a at
surface, align the raised ribs on the
battery with the recess in the charger
and slide onto the battery ensuring a
rm connection.
2 The charger LED will ash green
showing power is being supplied
to the charger.
5 When removing the charger from the
battery, rst press the battery release
tab, then slide the charger from its
position.
Charging your lithium ion battery - Eco Charger
Charger LED Indicator
LED Indicator Situation
GREEN (Flashing) Stand By (no battery pack is inserted)
RED (Illuminated) Battery is charging (low charge)
GREEN (Illuminated) Battery is charged and ready for use
RED (Flashing) Battery or Charger fault
RED & GREEN (Flashing) Battery pack is too hot or too cold (remove battery from
charger and store at room temperature 20ºC. Insert
battery again when at correct charging temperature). If
this happens again, the battery is defective and needs
to be replaced.
The purchased battery will be shipped in a low charge condition, and requires charging
prior to use. Allow several cycles of charging and discharging (through use of the tool)
for the battery to reach its optimum performance / runtime.
1 Connect the charger into a mains power outlet.
4 The charger LED will illuminate
red signifying that the battery is
charging.
3 With the charger sitting on a at
surface, align the raised ribs on
the battery with the recess in the
charger and slide onto the charger
ensuring a rm connection.
2 The charger LED will ash green
showing power is being supplied
to the charger.
5 The charger LED will illuminate
green once the battery is charged.
Charging your lithium ion battery - Fast Charger
Charger LED Indicator
LED Indicator Situation
GREEN (Flashing) Stand By (no battery pack is inserted)
RED (Flashing) Battery is charging (low charge)
RED (Illuminated) Battery is charging (mid charge)
GREEN (Illuminated) Battery is 85% - 100% charged and ready for use
BOTH(Illuminated) Battery pack is too hot or too cold (charging will begin
automatically when battery reaches correct charging
temperature).
BOTH (Flashing) Defective battery. Never charge a defective battery
pack!
Remove battery pack from charger.
1. BATTERY & CHARGING (sold separately)
Inserting & Removing the Battery (not included)
1 Align the ribs of the battery with the recess at the rear of the blower and
push in until it clicks into place.
2 To remove, press and hold the battery release tab and pull the battery
away from the blower.
a
b
Battery protection system
The tool is equipped with the battery protection system, which helps to ensure a long service
life.
The output power automatically cuts off during operation when the tool and/or battery are
placed under the following situations:
• When the tool is overloaded:
If this occurs, release the trigger switch and remove causes of overload, then pull the
switch trigger again to restart.
• When the remaining battery capacity becomes low:
Recharge the battery pack.
Note: The battery protection system does not in any way damage the tool.
Note: The indicated capacity may be lower than the actual level during use or immediately
after using the tool.
KNOW YOUR PRODUCT
3. ASSEMBLY 5. OPERATION4. CONTROLS 6. USING THE INFLATION ADAPTORS
SETUP & PREPARATION OPERATION
Switching On and OffConnecting the blower nozzle
Blowing
The blower is ideal for dirt, clippings and other debris.
Inflation Adaptors
The PXWBS-200U comes complete with 3 ination adaptors in varying sizes
which are suited for use on devices that require a large air volume, at a low
pressure. These include items such as air mattresses and pool toys.
CORDLESS BLOWER / INFLATOR
1 2 3 4 5
6
1 Blower Nozzle
2 Blower Housing
3 On/Off Switch
4 Sure Grip Handle
5 Battery Seating
6 Ination Adaptors x 3
WARNING! DO NOT USE THE BLOWER WITH ANY
ACCESSORIES OR ATTACHMENTS OTHER THAN THOSE
SUPPLIED. SUCH USAGE MIGHT BE HAZARDOUS.
WARNING! DO NOT PUT PART OF YOUR BODY SUCH
AS HANDS AND FINGERS NEAR THE INLET OR OUTLET
OPENING.
WARNING! DO NOT SWITCH THE BLOWER ON IN
POORLY VENTILATED SPACES OR IN THE PRESENCE
OF FLAMMABLE AND/OR EXPLOSIVE LIQUIDS, GASES
AND POWDERS.
WARNING! ENSURE THE BLOWER OUTLET IS NOT
BLOCKED DURING USE.
2 To stop the blower release the
on/off switch.
2 Both the blower nozzle and
central ination adaptor are
tted with internal nodes that
line up and slot into the blower
housing.
4 To lock into place, rotate nozzle
in clockwise direction until
nozzle clicks into place.
5 To remove blower nozzle,
rotate in anti-clockwise
direction.
3 Line up the internal nozzle
nodes with the blower housing
and slide into place.
2 Move the blower from side
to side while walking slowly
forward.
3 Connect ination adaptor to
the blower housing and rotate
adaptor clockwise until it
clicks into locked position.
4 To t ination adaptor to a
small inlet, use either of the
other 2 adaptor ends. Fit larger
end of smaller adaptor piece to
central adaptor.
5 Fit small end of adaptor to
the inlet on the device to be
inated. Once tted, use On/
Off switch to inate device.
6 To Remove adaptor, turn in
anti-clockwise direction.
Note: Be aware of other people and animals in the area where you are to be
operating the blower.
Note: Avoid collisions with hard objects which could damage your machine.
Note: The PXWBS-200U Blower / Inator is not suited to inating devices
that require high air pressure - such as sporting equipment and car types.
1 To start the blower squeeze
the on/off switch.
1 The blower end is equipped
with slots to ensure nozzles
and adaptors lock into place
and remain tted during use.
1 Hold the blower rmly,
squeeze the on/off switch.
1 Remove blower nozzle.
2 Line up nodes on inside of
centre ination adaptor with
the blower connection slot.
CAUTION: THE CHARGER FOR THIS PRODUCT
SHOULD BE PROTECTED BY A RESIDUAL CURRENT
DEVICE (RATED AT 30mA OR LESS).
WARNING! ENSURE THE TOOL IS SWITCHED OFF AND
DISCONNECTED FROM THE POWER SUPPLY BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to the
online manual.
BATTERY & CHARGER (sold separately)
This tool is compatible with all battery and chargers from the Ozito
Power X Change Range.
PXWBS-200U

Specyfikacje produktu

Marka: Ozito
Kategoria: nieskategoryzowany
Model: PXWBS-200U

Potrzebujesz pomocy?

Jeśli potrzebujesz pomocy z Ozito PXWBS-200U, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą


Instrukcje nieskategoryzowany Ozito

Ozito

Ozito PXMBC-004 Instrukcja

29 Maja 2024
Ozito

Ozito PXCPPS-018U Instrukcja

28 Maja 2024
Ozito

Ozito OAST-050 Instrukcja

26 Maja 2024
Ozito

Ozito PXHTK-400 Instrukcja

24 Maja 2024
Ozito

Ozito PXWBS-200U Instrukcja

21 Maja 2024
Ozito

Ozito ATAK-009 Instrukcja

21 Maja 2024
Ozito

Ozito UJC-860 Instrukcja

20 Maja 2024
Ozito

Ozito PXBCSS-184 Instrukcja

20 Maja 2024
Ozito

Ozito PXCBLK-218 Instrukcja

19 Maja 2024
Ozito

Ozito PXSMSK-800MS Instrukcja

13 Maja 2024

Instrukcje nieskategoryzowany

Najnowsze instrukcje dla nieskategoryzowany

Asko

Asko DBI644MIB.S.TW/1 Instrukcja

28 Października 2024
Asko

Asko DFS233IB.S.TW/1 Instrukcja

28 Października 2024
Emko

Emko EZM-9920 Instrukcja

27 Października 2024
Emko

Emko ESM-3712-H Instrukcja

27 Października 2024
Emko

Emko ATS-10 Instrukcja

27 Października 2024
Emko

Emko EAOM-11.2 Instrukcja

27 Października 2024
Emko

Emko EPM-3790 Instrukcja

27 Października 2024
Emko

Emko EPM-7790 Instrukcja

27 Października 2024
Livarno Lux

Livarno Lux IAN 108340 Instrukcja

27 Października 2024
Livarno Lux

Livarno Lux HG06009A-BS Instrukcja

27 Października 2024
