INSTRUCTION MANUAL
ODYS - LOOP
PORTABLE STEREO MUSICSTATION
FOR iPod/iPhone
With FM RADIO
Please read following instructions prior to operating your unit.
Manufacturer of this unit follows a principle of continuous improvement and has no
responsibility for any changes that are made to the unit nor any liability for these changes.
Thanks for your choice of our products.
Disclaimer
All the information, design and specifications contained in this manual were correct
at the time of publication. However, as the product is under development and
upgrading, the final device may have a slightly difference in appearance or modified
functionality than presented in this manual.
Package Content
1. ODYS Loop
2. Remote Control (incl battery)
3. Adapter for iPod/iPhone
4. Manual
5. Warranty Card
Safety Instructions
Although this product is safe, please observe the following information and warnings.
• Do not expose the device to direct sunlight, extreme heat or cold, damp or dusty conditions.
Malfunctions and damage and can occur as a result..
• Do not use the device in an extremely dry environment to avoid static electricity.
• Do not shake the device or subject it to hard knocks. The device may be damaged if it falls.
Do not place any heavy objects on top of the device.
• Clean the device only using a soft, dry cloth and do not use any volatile substances, such as
solvents, to avoid damaging the surface.
• Do not open the casing of the device under any circumstances, and do not attempt to repair
or modify the device.
Disposal
Do not dispose of a defective device in normal household waste disposal containers
Take the defective device to your retailer or to an appropriate waste collection site. This
will ensure that the device is disposed of in an environmentally-friendly way.
Support
URL: http://www.odys.de
See our website for the latest information on this device, on other products by our company
and on our company itself. Any firmware updates for this device are also made available on
our website. If you have questions or problems, please read the FAQs on our website or
contact our customer support service support@odys.de.
2 3
MAIN UNIT
1. HANDLE
2. SLEEP BUTTON
3. LCD DISPLAY
4. STOP BUTTON
5. FM TELESCOPIC ANTENNA
6. SPEAKERS
7. POWER BUTTON
8. SOURCE BUTTON
9. VOLUME - BUTTON
10. VOLUME + BUTTON
11. iPod/iPhone DOCKING PUSH
OPEN AREA
12. TUNING - BUTTON
13. TUNING + BUTTON
14. PLAY/PAUSE BUTTON
15. MEM BUTTON
16. VIDEO OUTPUT JACK
17. LINE IN JACK
18. BATTERY COMPARTMENT
19. AC CORD
20. REMOTE SENSOR
REMOTE CONTROL
1. POWER BUTTON
2. SLEEP BUTTON
3. iPod MENU BUTTON
4. MENU UP BUTTON
5. PREVIOUS & FAST BACKWARD
BUTTON
6. ENTER BUTTON
7. MEM BUTTON
8. MENU DOWN BUTTON
9. TREBLE +/- BUTTON
10. BASS +/- BUTTON
11. MUTE BUTTON
12. SOURCE BUTTON
13. NEXT & FAST FORWARD
BUTTON
14. PLAY/PAUSE BUTTON
15. VOLUME +/- BUTTON
POWER SUPPLY
Plug AC plug into the outlet socket on the unit for connecting the main power.
SLEEP TIMER SETTING
Following the below instructions to set the sleep timer:
During playback, press SLEEP button repeatedly to cycle through the sleep time options:
90 ⎝ 80 ⎝ 70 ⎝ 60 ⎝ 50 ⎝ 40 ⎝ 30 ⎝ 20 ⎝ 10 ⎝ 00
After the sleep time setting, you can play the unit freely. Once the sleep time is expired, the
unit will be switched off.
During playback, press SLEEP button to check the remaining sleep time.
iPod/iPhone OPERATING
PLAYING AN iPod/iPhone
1. Press iPod/iPhone DOCKING PUSH OPEN AREA to pop out the docking. Dock the
iPod/iPhone on to the unit. Power on the unit, then press SOURCE button repeatedly to
switch to iPod mode, and then the playback will start automatically.
2. Press PLAY/PAUSE button to start or pause the playback.
3. Press STOP button to stop the playback.
4. During playback, press TUNING + button on the unit or NEXT/FAST FORWARD button
on the remote to skip to the next track; press and hold TUNING + button on the unit or
NEXT/FAST FORWARD button on the remote to search through the track forward.
5. During playback, press TUNING - button on the unit or PREVIOUS/FAST BACKWARD
button on the remote to skip to the previous track; press and hold TUNING - button on the
unit or PREVIOUS/FAST BACKWARD button on the remote to search through the track
backward.
6. Press iPod MENU button on the remote to return back to the iPod menu, press MENU
UP/DOWN buttons to select your desired track for playback, press ENTER button to
confirm.
FM RADIO
TUNING THE FM RADIO
1. Power on the unit, switch to RADIO mode by pressing SOURCE repeatedly.
2. Press TUNING +/- button on the unit or NEXT/PREVIOUS button on the remote to fine
tune radio station. Press and hold TUNING +/- button on the unit or NEXT/PREVIOUS
button on the remote to auto search radio station forward or backward respectively. When
an available station will be found, the unit will broadcast it immediately and the searching
will be stopped.
1 2 3 4 5
6 7 8 9 6 10 11 12 13
14
15
16 17 18 19
1
23
45
67
8
9
10
11
12
13
14
15
20
4 5
STORING YOUR FAVORITE RADIO STATION
1. During playback, press and hold MEM button on the unit or short press MEM button on
the remote for storing the current station, a memory cell number flashes on the screen.
2. Use TUNING +/- button on the unit or MENU UP/DOWN button on the remote to select
the corresponding memory cell among P01-P20 for storing the station.
3. Confirm your selection by pressing MEM button on the unit or on the remote.
4. During radio playback, press MEM button on the unit, and then press TUNING+/- button
on the unit to recall the stored stations. You also can press MENU UP/DOWN button on
the remote repeatedly to select your desired stored stations for broadcasting.
MUTE THE UNIT
During playback, press MUTE button to switch off the audio. Press the button again to
resume the audio.
VOLUME LEVEL/TREBLE/BASS ADJUSTMENT
Press VOLUME +/- button or TREBLE +/- button or BASS +/- button to adjust the volume
output level or treble effect or bass effect.
CONNECTING WITH OTHER APPLIANCES
LINE IN
Follow steps to connect the unit to another audio device:
1. Connect the device into the player’s LINE IN jack with the LINE OUT cables.
2. Press POWER button to turn the unit on.
3. Press SOURCE button repeatedly to switch the unit to LINE IN mode.
4. Power on the device and begin play.
VIDEO OUTPUT
1. Dock a iPod/iPhone to the unit.
2. Connect RCA cable to the VIDEO OUTPUT jack on the unit and the TV set.
3. Power on the unit and the connected TV set. Press SOURCE button repeatedly to switch
to iPod mode.
4. Change the TV set to the proper input mode.
5. Video from a docked iPhone/iPod can now be played through the bar speaker to the
connected television.
Note: Make sure the docked iPhone or iPod’s TV out option is turned on.
TROUBLE SHOOTING
Symptom Possible Cause Solution
Radio sound distorted. 1. The station is not tuned in.
2. The signal is poor.
1. Fine tune the station.
2. Extend the FM telescopic
antenna, change the direction
of the antenna.
No radio sound. 1. The unit is not in tuner
mode.
2. The volume has been
muted or is on the minimum
setting.
1. Press SOURCE button
repeatedly until switching to
tuner.
2. Adjust the volume level or
press MUTE button to resume
audio.
The iPod will not play 1. The unit is not in iPod
mode.
2. The iPod is not connected
correctly.
1. Press SOURCE button
repeatedly until switching to
iPod.
2. Reconnect the iPod.
No iPod sound. 1. The unit is not in iPod
mode.
2. The volume has been
muted or is on the minimum
setting.
1. Press SOURCE button
repeatedly until switching to
iPod.
2. Adjust the volume level or
press MUTE button to resume
audio.
