BNC Connectors

setting standards

122

C o n t e n t P a g e

UHD BNC - rearTWIST Cable Connectors .............. 124

UHD BNC - Chassis ............................................ 124

rearTWIST HD Cable Connectors .......................... 125

Cable to Connector Guide .................................. 126

Connector to Cable Guide .................................. 128

HD BNC Chassis & Cable Jack Panel Version ......... 130

Technical Data .................................................. 131

Accessories ....................................................... 132

N E U T R I K®

7 5 Ω B NC C on ne ct o r s

Neutrik offers a variety of 75 cable and chassis Ω

BNC connectors. The rearTWIST cable connectors are

easy to handle in high density applications such as

video patchbays and switches, provide a tactile and

fast assembly and offer colour coding as a standard.

All parts of our BNC series are precisely machined to

our high quality standards.

B N C C o n n e c t o r s B N C C o n

NEUTRIK®, crystalCON®, etherCON®, maxCON®, miniCON®,

nanoCON®, neutriCON®, opticalCON®, powerCON®, Profi®,

rearTWIST®, silentPLUG®, speakON®, DIWA® ,XIRIUM®, are

registered trademarks of Neutrik AG.

www.neutrik.com 123

4K8K

With the transition to 4K or even 8K-signals the impedance of BNC

connectors became more important than ever. Every deviate impedance

has a negative influence on return loss and VSWR (Voltage Standing

Wave Ratio) which are important measurements for reflected signals in

a transmission line. Especially on high data rates up to 24 Gb/s, as they

occur when transmitting ultra high definition (UHD) signals, an impedance

mismatch results in high return loss.

Neutrik´s new rearTWIST UHD-BNC connector is a specificlally for high

frequencies optimized BNC connector; based on the proven rearTWIST

technology. The unique insulator design in combination with the reduced

crimp diameter of the gold plated center pin allows UHD-data transmission

within the required return loss limits.

r e a r T W I S T U H D – B N C C o n n e c t o r

B N C C o n n e c t o r s

F e a t u r e s & B e n e f i t s

Screen and cable jacket crimp instead of screen

crimp only. Grooved inner surface holds the

cable jacket to prevent tearing braids.

High frequency optimized insulator design for

UHD-transmissions.

Reduced pin crimp diameter for performance

improvement (return loss values).

Swiss antraloy plating

rearTWIST boot for easy access in high density

applications.

Specyfikacje produktu

Marka:	Neutrik
Kategoria:	kabel koncentryczny
Model:	NBTC75BSS5
Kolor produktu:	Czarny, Srebrny
Ilość na paczkę:	1 szt.
Impedancja:	75 Ω
Certyfikaty:	IEC 60803, IEC 60352-2
Napięcie pracy:	50 V
Zakres temperatur (eksploatacja):	-30 - 85 °C
Obsługiwane produkty:	AT&T 735, ComTech RGBHV
Złączka 1:	BNC
Złącze 1:	Męska
Materiał izolujący:	Policzterofluoroetylen (PTFE)
Connector type:	BNC
Rezystancja izolacji:	5000 MΩ
Siła utrzymywania:	30 N
