Playing your iPod
To see the iPod options
press followed by Aux, i80.h
Connecting the iPod
The i80 iPod Dock allows you to play the
sound from your iPod through the F80.
This section explains how you control the
iPod from the F80, using the front panel
controls or remote control.
Select the i80 source by pressing h
followed by , .Aux i80
After a delay of up to five seconds the
iPod displays a message showing that it
is connected.
•
Playing and pausing
To play a track
Press . ±
While a track is playing the display shows
the elapsed time, the title of the track,
and its position in the album or playlist
(for example, 1 of 9).
While a track is playing the label ±
changes to .=
To pause the disc
Press .=
While a track is paused a symbol is =
displayed at top right of the display and
the label changes to :=±
Baby be Mine
]
±
=
[)
Menu
1 of 9
iPod 2:45
(
To resume play
Press .±
•
•
•
Stepping between tracks
You can step between tracks while the
iPod is playing or paused.
To step to the start of the next track
Press .]
To restart the current track
Press .[
To select a track
Press or until the display [ ]
shows the track you want to play.
Shuffle and repeat
Press to display the keys for shuffle (
and repeat.
To shuffle the tracks in the current
album/playlist
Press .Shuffle
To repeat the current track/playlist
Press .Repeat
•
•
•
•
•
Scanning through a track
Press to display the keys for )
scanning.
To scan at faster than normal speed
Press for reverse scan or { }
for forward scan.
While scanning a scan symbol is shown
at top right of the display:
Billie Jean
}>(
}
{ Menu
iPod 4:35
Press to revert to normal play.±
Play resumes from the point you
reached.
•
•
Browsing your iPod
Browsing your music
To browse for music
Press from the playing screen.Menu
The first time you press you will Menu
see the main MUSIC screen with the first
menu, , shown:Playlists
Playlists
Enter^¬
>
` Menu
iPod MUSIC
Press or to step between ` ^
the main menus: , Playlists
Albums Artists Songs Genres, , , ,
Composers Podcasts, , and
Audiobooks.
If you subsequently press while Menu
music is playing you will return to the last
menu item you were looking at.
•
•
Navigating the menus
To step between items on the
current menu
Press or .` ^
The name of the current menu or
category is shown at the top of the
display; for example ALBUMS.
Thriller
Enter^¬
>
` Menu
iPod ALBUMS
•
Selecting an item
To show the contents of an item
Select a playlist, album, artist, genre,
composer, podcast, or audiobook.
Press .Enter
To play a track
Select a song.
Press .Enter
•
•
•
•
Returning to the previous
menu
To return to the previous menu
Press .Menu
Pressing from the MUSIC screen Menu
returns to the playing screen.
Returning to the playing
screen
Press , or press and hold on ¬Menu
the remote control.
Alternatively if you do not press anything
the display reverts to the playing screen
after 20 seconds.
•
•
Lady in my Life
Enter^¬
>
` Menu
iPod Thriller
Baby be Mine
]=
>
[ )Menu
1 of 9
iPod 2:34
(
Connecting the i80 dock
To connect the iPod
Connect one end of the i80 Dock
cable to the connector on the back of
the i80 Dock.
Connect the other end of the cable to
the i80 Dock connector on the F80.
Insert the plastic cover supplied with
your iPod onto the i80 Dock.
Mount your iPod on the i80 Dock.
While connected the iPod battery is
recharged from the product.
•
•
•
•
USB Connector
The USB connector optionally allows you
to charge your iPod from an external
USB power supply or computer. The i80
light changes from green to red when
charging.
Setting iPod control
The instructions on this leaflet explain
how to control the iPod from the F80
using the front panel controls or remote
control.
If you prefer to disable iPod control, for
example to view video on the iPod while
playing the sound through the product,
proceed as follows:
To enable/disable iPod control
Press , , to display hAdjust Setup
the SETUP menus.
Press to display the )i80 Ctrl
option.
You can choose between , Enabled
which allows you to control the iPod from
the product, or , which allows Disabled
you to play the iPod without controlling it.
•
•
USB i80
dock cable
i80 iPod dock for F80
Designed and Engineered by
Meridian Audio Limited
Cambridgeshire England
Safety instructions
This product is only intended for use with
an iPod in conjunction with a Meridian
F80. Please refer to the F80 User Guide
for additional safety information.
i80 compatibility
The i80 is fully compatible with the iPod
Mini, iPod Nano, iPod Classic, and
iTouch.
It may also be usable with the iPhone;
when connecting select Airplane Mode
to avoid incoming calls and messages
interrupting the audio.
Acknowledgements
Meridian is a registered trade mark of
Meridian Audio Ltd.
iPhone and iPod are trade marks or
registered trade marks of Apple Inc.
Copyright © 2007-2008 Meridian
Audio Ltd.
Part number: P86017
This guide was produced by:
Human-Computer Interface Ltd,
http://www.interface.co.uk/
Sales and service in the UK
Meridian Audio Ltd
Latham Road
Huntingdon
Cambridgeshire
PE29 6YE, England
Tel +44 (0)1480 445678
Fax +44 (0)1480 445686
Sales and service in the USA
Meridian America Inc
8055 Troon Circle
Suite C
Austell
GA30168-7849, USA
Tel +1 (404) 344 7111
Fax +1 (404) 346 7111
Visit us on the Web:
http://www.meridian-audio.com/
Designed and manufactured in the UK
by Meridian Audio Ltd. Meridian Audio
reserves the right to make changes and
improvements to any of the products
described in this document without prior
notice.
