DSP3200
User Guide
DSP3200 User Guide2 EN
Important safety instructions
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with a dry cloth.
Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit
from the apparatus.
Only use attachments/accessories specified by the manufacturer.
Unplug this apparatus during lightning storms or when unused for
long periods of time.
Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.
This apparatus has been designed with Class 1 construction and
must be connected to a mains socket outlet with a protective earthing
connection (the third grounding pin).
This apparatus does not include a power switch. The apparatus may be
isolated from mains power either by unplugging the power connector from
the rear of the unit, or by unplugging the connector at the opposing end
of the power cord or cable from its supply outlet. As a result, either or
both of these connectors should remain accessible
CAUTION: This DSP3200 for use only with the Meridian DSP3200
Stand, part number SP5543. Use with other stands is capable of
resulting in instability causing possible injury.
•
•
•
•
•
•
•
•
•
•
•
•
•
Safety warnings
Do not expose the unit to dripping or splashing.
Do not place any object filled with liquid, such as a vase, on the unit.
Do not place naked flame sources, such as lighted candles, on
the unit.
To avoid overheating leave at least 10cm around the equipment to
ensure sufficient ventilation.
Do not position the unit in direct sunlight, near heat sources such as
a radiator, or directly on top of heat producing equipment, such as a
power amplifier.
To avoid interference do not position the unit near strong electrical or
magnetic radiation, such as near a power amplifier.
Radio interference
FCC Warning: This equipment generates and can radiate radio
frequency energy and if not installed and used correctly in accordance
with our instructions may cause interference to radio communications
or radio and television reception. It has been type-tested and complies
with the limits set out in Subpart J, Part 15 of FCC rules for a Class
B computing device. These limits are intended to provide reasonable
protection against such interference in home installations.
EEC: This product has been designed and type-tested to comply
with the limits set out in EN55013 and EN55020.
Copyright
Meridian Audio Ltd
Latham Road
Huntingdon
Cambridgeshire
PE29 6YE
England
Copyright © 2010 Meridian Audio Ltd.
Visit us on the Web:
http://www.meridian-audio.com
Part no: DSP3200 (P88394)
This guide was produced by: Human-Computer Interface Ltd,
http://www.interface.co.uk/
•
•
•
•
•
•
DSP3200 User Guide 3EN
Unpacking
The DSP3200 is supplied with the following accessories:
Power cord.
This manual.
•
•
If either of these items are missing please contact your dealer.
NOTE: You should retain the packaging in case you need to
transport the units.
Connections
The following diagram gives details of the connections on
the base of the speaker:
L/C R
Input Output
SpeakerLink Digital Channel
Selector
Power
InletFuse
220-240V ~50-60 Hz 200W max
Channel
selector
SpeakerLink
input output Power
Digital connections
Use this connection To connect to this
SpeakerLink input The SpeakerLink output of a Meridian
Sooloos component, Digital Surround
Controller, or Audio Core 200.
SpeakerLink output The Speakerlink input of a second
DSP3200 digital speaker, when daisy-
chaining the speakers.
Miscellaneous
Switch Description
Digital Channel Selector Set to L/C to use the speaker as a left
or centre channel speaker. Set to R
to use the speaker as a right channel
speaker.
Standby indicator
The status of the DSP3200 is shown by a green standby
indicator on the back panel.
Status Description
Dimly illuminated Speaker in standby
Brightly illuminated Speaker operating
The speakers are switched on or into standby as appropriate via
the SpeakerLink connections by the Meridian system they are
connected to.
