INSTRUCTION MANUAL
First applying the Air Bubble Washing System in the world.
Improving washing performance by more than 35%, while
reducing power consumption by 40%.
Applying One-Touch Operation System.
Realizing calm washing through the innovational low-noise
design.
Before operating this washer, please read this instruction
completely. Thank you.
Model: KL 15 TL
=
Full-Auto Electric Washing Machine
➣Your washer is equipped with the
bubble generator that generates a
great deal of air bubble.
➣The air bubbles knock the dirt out
of the clothes during wash and
they push up the heavy dirt to
remove it during rinse.
➣Because the double washing
method using both air bubble &
water current is applied to this
washer, wash efficiency is excellent
in comparison with the original
washer system.
Air Bubble Washing System in the World
CONTENTS Page
PA
RTS AND FEATURES.......................................................2
WASHER SAFETY.................................................................3
INSTALLATION INSTRUCTIONS.........................................4
ELECTRICAL REQUIREMENTS..........................................5
INLET HOSE CONNECTION................................................6
OPERATING YOUR WASHER.............................................7
THE FUNCTIONS OF THE CONTROL PANEL.................8
WASHING PROCEDURE AND COURSE SELECTION
.......9
GENERAL PROCEDURE FOR OPERATION...................11
CARING FOR YOUR WASHER.........................................12
HOW TO CLEAN THE FILTER...........................................13
REMOVING STAINS............................................................14
TROUBLE SHOOTING........................................................15
SPECIFICATION..................................................................16
A NOTE TO YOU
Thank you for buying a Kelvinator appliance.
Kelvinator washers are easy to use, save time, and help you manage your home better.
This manual contains valuable information about how to operate and maintain your washer properly and safely.
Please read it carefully.
®
2
WATER TAP ADAPTER INLET HOSE
PARTS AND FEATURES
COVER UNDER (OPTION)
HOSE DRAIN (FOR NON-PUMP) HOSE DRAIN (FOR PUMP)
UP
The parts and features of your washer are illustrated on this page.
Become familiar with all parts and features before using your washer.
NOTE
•
The drawings in this book may vary from your washer model.
They are designed to show the different features of all models covered by this book,
Your model may not include all features.
ACCESSORIES
• HOT WATER TAP
• COLD WATER TAP
After using the washer,
close the water tap, In case
of the single valve model,
there is no hot water valve.
After using the washer,
close the water tap
• CASE DETERGENT
AND SOFTENER
• BLEACH INLET
• ADJUSTABLE LEG
• CONTROL PANEL
• HOSE DRAIN
• POWER CORD
In case of 3-wire power cord
ground wire will not be provided
• GROUND WIRE(OPTION)
• LINT FILTER(2EA)
• DOOR
3
Read all instructions before using your washer
Save these instructions
Your safety is important to us.
To reduce the risk of fire, electrical shock, or injury when using your washer, follow
basic precautions including the following:
Understanding your responsibilities
• Do not wash items that are soiled with vegetable or cooking oil.
These items may contain some oil after laundering.
Due to the remaining oil, the fabric may smoke or catch fire by itself.
• Do not use chlorine bleach and ammonia or acid (Such as vinegar or rust remover) in the
same wash. Hazardous fumes can form.
• Unplug power supply cord before attempting to service your washer.
• Do not wash fiber glass materials.
Small particles can stick to fabrics and cause skin irritation.
• ˚ Do not use hot water that temperature is over 50 C (120˚F).
It can cause a deformation of plastic parts.
• Do not spray water on the control panel and back cover of the washer.
It can cause a fire or an electric shock.
• Flammable fluids (dry-cleaning solvents,
kerosene, gasoline, etc.) should not be
used or stored in near your washer.
.Do not add flammable fluids to your wash
water.These substances give off vapors
that can create a fire hazard or explosion.
• Do not allow children to operate, play
with, or crawl on or inside your washer.
Supervise children closely when your
washer is used near them.
• After starting a cycle, do not reach into
the spin basket unless all motion stops.
• Do not tamper with the controls.
Please ...
• Have only a qualified person install, repair,
or replace parts on washer.
• Maintain washer properly.
• Protect washer from the weather and
keep it where the temperature will not fall
below freezing.
• Do not install the washer at a place of
extremely high humidity. It could cause an
Electrical shock or a short circuit.
• Connect washer to the correct outlet,
electrical supply, water supply, and drain.
• Ground washer properly.
WASHER SAFETY
• If the supply cord is damaged, it must be
replaced by the manufacturer or its service
agent or a similarly qualified person in order
to avoid a hazard
• If the appliance is supplied from a cord
extension set or electrical portable outlet
device it should be positioned so it is not
subjected to splashing or ingress of moisture.
