EonStor GS Family
www.infortrend.com
Cloud-Integrated Unified Storage
HIGHLIGHTS
Witness the power of consolidated file, block,
and object storage
The volume of digital data currently being produced is growing at unprecedented
rates, in big part due to our increasing demand for unstructured data types such as
files, images and videos, which push the boundaries of storage capacity and
performance. Because of this, many organizations are making cloud storage, with
its cost-effective flexibility and infinite scalability, an integral part of their
strategy. Now more than ever, choosing a local storage solution that can easily
integrate with cloud services is a must.
EonStor GS family is a unified storage solution that incorporates remote cloud
storage into local applications to offer the best of both worlds – unlimited cloud
storage and high performance local storage – as well as automatic data lifecycle
management, to allow SMBs and SMEs running local SAN/NAS applications to
easily and cost-effectively integrate and expand their storage architecture into
cloud services.
UNIFIED STORAGE
▪ Consolidate SAN, NAS and object
storage in a single system to enjoy
powerful storage features and
simplify deployment and
management
EFFICIENCY
▪ Integrated object based storage
reduces the cost of deploying
applications from the cloud
▪ EonStor GS family makes efficient use
of available bandwidth and greatly
speeds up data extend when uploading
data to the cloud with its data
reduction technology
▪ EonStor GS has perfectly integrated the
LDAP Server function into the system,
so customers do not need to construct
additional LDAP Servers.
EXCEPTIONAL COST
PERFORMANCE
▪ High Block/file level Performance, it
delivers up to 450K IOPS, 11,000MB/s
block and 3,300MB/s CIFS bandwidth.
▪ Future-proof expansion solution offers
ample data capacity of up to 444 drives.
▪ Comprehensive data services,
including SSD Cache and automated
storage tiering improve performance
and speed up data access.
▪ Support for all-flash and hybrid
configurations provides flexibility of
choice to meet your needs.
▪ Select from a wide range of product
series and multiple host options.
Powerful All-around High Performance & Efficiency
Based on much improved hardware and firmware, EonStor GS family can handle file
level protocols including CIFS/SMB, NFS, AFP and FTP; block level protocols such as
Fiber Channel, iSCSI and SAS; and object level protocols, which allow users to access
files directly via browsers through the file's unique URL and reduces the cost of
deploying applications from the cloud.
By integrating all of these protocols and harnessing the power of Intel's multicore
CPU, EonStor GS family delivers not only outstanding flexibility but also incredible
performance in two configurations: all-flash and hybrid. As an all-flash system, it
delivers up to 450K IOPS, 11,000MB/s block and 3,300MB/s CIFS bandwidth.
Moreover, by offering hybrid features such as SSD Cache, protocol translation
between local NAS/SAN and cloud storage services, and automated storage tiering,
EonStor GS family guarantees exceptional performance at every level of operation.
This great performance and efficiency can also be found in our cloud storage
integration thanks to deduplication and compression features, which ensure the
efficient use of bandwidth to effectively extend data to the cloud and lower overall
costs.
GS Portfolio
Per formanc e
Series
GS 1000
* The above specifications are based on redundant system
GS 2000
GS 3000
CPU: Intel Broadwell-DE 4C
• Max. RAM: 128 GB
• Four Host Boards
• Drive side: 12Gb/s SAS
• Supports up to 444 disks
•
• CPU: Intel Broadwell-DE 4C
• Max. RAM: 256 GB
• Four Host Boards
• Drive side 12Gb/s SAS
• Supports up to 444 disks
• CPU: Intel Avoton 8C
• Max. RAM: 64 GB
• Two Host Boards
• Drive side: 6Gb/s SAS
• Supports up to 360 disks
GS 4000
• CPU: Intel Broadwell-DE 4C
• Max. RAM: 256GB
• Four Host Boards
• Drive side 12Gb/s SAS
• Supports up to 444 disks
EonStor GS Family
CLOUD READY
▪ The EonStor GS can integrate with cloud
storage, and data can be optimally
allocated between EonStor GS and
Cloud through our smart algorithms, so
users can enjoy the best performance
and the safest storage.
▪ EonStor GS offers comprehensive cloud
integration functions for users to choose
from: Cloud Tiering, Cloud Cache and
Cloud Backup.
▪ Support for private and public cloud
services enables users to choose the
option that best suits their budget or
data security requirements
AVAILABILITY & RELIABILITY
▪ SMB 3.0 transparent failover and
multipathing support guarantee non-
disruptive operations.
▪ Dual controllers and non-single-point-of-
failure hardware design ensure system
continuity in case of faults.
▪ Cache protection with Super capacitor
and Flash to ensure data safety
▪ IDR support ensures all hard drives are
healthy to prevent from rebuild
DATA PROTECTION & SECURITY
▪ Whether inactive or mid transfer, data is
always encrypted to ensure full
protection from malicious attacks
SIMPLICITY
▪ EonOne management interface provides
a single control center for system
management and resources monitoring
Infinite Storage Capacity on Cloud
Comprehensive Data Protection and Security
®
Integration with Windows AD and LDAP
One of the key benefits of cloud storage solutions is their unlimited scalability and
flexible “scale on demand” model, which allows you to expand your storage capacity
as needed, without upfront investment, to fit your capacity requirements as they
evolve.
By integrating Intelligent Cloud Gateway Engine and supporting a wide range of both
private cloud and public cloud services, including Amazon, Azure, and Google, the
EonStor GS offers various cloud functions such as Cloud Tiering, Cloud Cache and
Cloud Backup to make the most of cloud's advantages. These functions perfectly
combine local and cloud storage, automatically and optimally allocating data, while
saving setup and maintenance costs in the process.
As security is of utmost importance when it comes to data storage in the cloud, the
EonStor GS family provides AES 256bit Encryption for data-in-flight and data-at-rest,
as well as self-encrypting drives (SED) compatibility, ensuring data is always
protected from malicious threats. Furthermore, with integrated SSL, links between
server and client are also encrypted.
Security threats are by no means the only concern when it comes to safeguarding
data. Unexpected disk failures, natural disasters and power outages all up the risk of
data loss. EonStor GS family ensures this risk is minimal with its integrated backup
functions such as Intelligent Drive Recovery (IDR), snapshot, local replication,
remote replication and file-level rsync.
In case a failure is experienced, the system's integrated SMB 3.0 transparent failover
and multipathing support guarantee non-disruptive operations. Also, designed with
redundant dual controllers and non-single-point-of-failure hardware components, it
ensures business continuity at all times.
The EonStor GS Family provides easy integration with existing business network
environments through Windows® AD and LDAP directory services, which allow MIS
to easily configure access rights of every user account in a share folder through ACL.
Furthermore, EonStor GS has perfectly integrated the LDAP Server function into the
system, so customers do not need to construct additional LDAP Servers.
Amazon web services S3
Wind ows Azure
Google Clou d Platform
Alibaba AliClou d
Public
Cloud
Hosts
FC/iSCSI
CIFS/NFS
AFP
Object
Cloud Gateway Engine
Infortrend
RAID
Controller
Linux
NAS
Object
Private
Cloud
* All de sign and spec ification declared are subj ect to chan ge w ithout noti ce in adva nce. All ri ghts r eser ved. Plea se refer to Infortren d we bsit e for f urther inf orma tion or loc aliz atio n updates .
EonStor GS Series
PHYSICAL SPECIFICATIONS
GS 1000
* 1
GS 1000T
Specifications (per system)
Form factor
2U 24-bay
3U 16-bay
4U 24-bay
Storage controller
Max Drives
Max SSD Cache Pool
Cache backup techniques
Power Supply Unit*4
CPU
*2
Cache memory *5
Max. number of host board
GS 2000
* 1
GS 2000T GS 3000
Dual-redundant/ Single upgradable to redundant
360
1.6TB
444
3.2TB
444
3.2TB
Super capacitor + Flash module
Power supply: Two redundant 460W;
Voltage and Frequency: 100-240 Vac, 50-60Hz
2x Intel Avoton 4C/ 8C 2x Intel Broadwell-DE 2C/ 4C 2x Intel Broadwell-DE 4C
8GB, 16GB, 32GB,64GB 8GB, 16GB, 32GB, 64GB, 128GB 8GB, 16GB, 32GB, 64GB, 128GB, 256GB
2 4 4
2 x 6Gb/s SAS wide por ts 2 x 12Gb/s SAS wide por ts 4 x 12Gb/s SAS wide por ts
0
8
0
8
4
4
Onboard iSCSI por ts (10Gb RJ-45)
Onboard iSCSI ports (1Gb RJ-45)
2U 12-bay
* All desi gn and spe cific atio n declared are subj ect to cha nge witho ut not ice in advance. All right s rese rved . Please refer to Infortrend w ebsite f or furt her in form atio n or lo cali zati on updates.
GS 4000
444
3.2TB
Power supply: Two redundant 530W;
Voltage and Frequency: 100-240 Vac, 50-60Hz
2x Intel Broadwell-DE 4C
4
4 x 12Gb/s SAS wide por ts
16
0
0
*6
Onboard converged ports 0 0 0
Max iSCSI Initiators
File Level
Max. File System Size
number of user accounts Max.
number of user groups Max.
number of folder sharing Max.
(NFS/CIFS/AFP/FTP)
number of Rsync jobs Max.
number of Rsync concurrent
processes
Max.
number of connections for a
folder (NFS/CIFS/AFP/FTP)
Max.
RAID Options
Protocol Suppor t
Cloud Gateway
Green design
Regulatory
1. Model name "T" means high IOPS solution
2. GS 4000/3000/2000 Default: DDR4 4GBx2 with ECC per controller, GS 1000 Default: DDR3 4GBx2 with ECC per controller
3. GS 4000/3000/2000 Converged host board suppor t s 4-port 10GbE iSCSI, 4-Port 8 Gb/s FC, 2-por t 16Gb/s FC and 4-por t 10GbE FCoE. GS 1000 Converged host board suppor ts 4-por t 10GbE iSCSI, 4-Port 8Gb/s FC
and 2-port 16Gb/s FC.
4. Power is also supplied in redundant mod e, allowing full operation with half the resources.
5. 8GB is for single controller models; 256GB is for redundant controller models.
6. GS 4000 onboard converged port suppor t s 4-port 10GbE iSCSI, 4-Port 8 Gb/s FC, 2-port 16Gb/s FC and 4-port 10GbE FCoE
8
4
16
8
4
4
4
16
8
24
16
8
8
0
16
8
20
16
12
8
0
32
512TB
1024
16KB, 32KB, 64KB, 128KB, 256KB, 512KB, or 1024KB per logical drive
Write-Back or Write-Through per logical drive. This policy can be modified.
2PB
32
4000
2PB
Up to 256
832
2PB
20000
512
2048
1024
64
2048 per controller
RAID 0, 1 (0+1), 3, 5, 6, 10, 30, 50, 60
Suppor t the integration with following cloud providers: Amazon S3, Microsoft Azure, Google Cloud Platform, Alibaba AliCloud
• 80 PLUS power supplies delivering more than 80% energy efficiency
• Intelligent multi-level drive spin-down
• Electromagnetic Compatibility : CE, BSMI, FCC, KC
• Safety : UL, BSMI, CB, EAC
Max. 8Gb/s FC Ports
*3
Max. 16Gb/s FC ports
*3
Max. 1 GbE/iSCSI ports
Max. 10 GbE/iSCSI (SFP+) por ts
*3
Max. 10 GbE/iSCSI (RJ45) por ts
Max. 12Gb/s SAS por ts
Max. 6Gb/s SAS ports
Max. number of logical drives
Max. logical drive capacity
Max. number of volumes (per pool/ per system)
Configurable stripe size
Configurable Write Policy
Max. size of Pool
Max. number of Pools
Max. number of LUNs Mappable
Max. volume size
Number of tags reserved for each Host-LUN
connection
File Level Protocol CIFS/ SMB: Version 2.0/3.0, NFS: Version 2/3/4, AFP, FTP, WebDAV
Block Level Protocol FC, FCoE, iSCSI, SAS
Object Level Protocol Openstack Swift
128
Max. number of logical drive per pool
32
16
16
32
8
8
0
Max. 10 GbE FCoE ports
*3 0 16 16 32
Host board por ts
2 x 16Gb FC por ts
4 x 8Gb FC por ts
2 x 10Gb iSCSI por ts (RJ-45)
2/4 x 10Gb iSCSI ports (SFP+)
4 x 1Gb iSCSI ports
2 x 6Gb SAS por ts
2 x 12Gb SAS ports
2 x 16Gb FC por ts
4 x 8Gb FC por ts
4 x 10Gb FCoE por ts
2 x 10Gb iSCSI por ts (RJ-45)
2/4 x 10Gb iSCSI ports (SFP+)
4 x 1Gb iSCSI ports
2 x 12Gb SAS ports
SAS expansion por ts
Host board + onboard por ts (max.) 16 24 24 32
Specyfikacje produktu
| Marka: | Infortrend |
| Kategoria: | serwer |
| Model: | GS 1012 |
Potrzebujesz pomocy?
Jeśli potrzebujesz pomocy z Infortrend GS 1012, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą
Instrukcje serwer Infortrend
29 Września 2024
29 Września 2024
29 Września 2024
29 Września 2024
29 Września 2024
29 Września 2024
29 Września 2024
29 Września 2024
29 Września 2024
29 Września 2024
Instrukcje serwer
- serwer Sony
- serwer Supermicro
- serwer Lenovo
- serwer Gigabyte
- serwer Acer
- serwer Technics
- serwer Hikvision
- serwer Fujitsu
- serwer Conceptronic
- serwer StarTech.com
- serwer Asus
- serwer D-Link
- serwer ATen
- serwer APC
- serwer HP
- serwer Tripp Lite
- serwer Cisco
- serwer Moxa
- serwer Synology
- serwer Lindy
- serwer ZyXEL
- serwer Dell
- serwer Linksys
- serwer Digitus
- serwer Vimar
- serwer Netgear
- serwer Black Box
- serwer Intellinet
- serwer HGST
- serwer Revox
- serwer Naim
- serwer SEH
- serwer Planet
- serwer NEC
- serwer Digi
- serwer Axis
- serwer Rocstor
- serwer Western Digital
- serwer Smart-AVI
- serwer Promise Technology
- serwer QNAP
- serwer Chenbro Micom
- serwer Allnet
- serwer Veritas
- serwer IStarUSA
- serwer Silverstone
- serwer Ernitec
- serwer Atlona
- serwer Hanwha
- serwer Quantum
- serwer Eaton
- serwer Monacor
- serwer Sonnet
- serwer In Win
- serwer Teo
- serwer Megasat
- serwer Areca
- serwer AMX
- serwer C2G
- serwer Maxdata
- serwer Matrox
- serwer Flir
- serwer Buffalo
- serwer GeoVision
- serwer LaCie
- serwer Valcom
- serwer Asustor
- serwer Intel
- serwer Fantec
- serwer Seagate
- serwer Iomega
- serwer Ibm
- serwer Provision ISR
- serwer TAIDEN
- serwer SIIG
- serwer Advantech
- serwer Extron
- serwer Avocent
- serwer Silex
- serwer Sun
- serwer MvixUSA
- serwer Dual Bay
- serwer Raidsonic
- serwer EMC
- serwer Opengear
- serwer G-Technology
- serwer EXSYS
- serwer Mr. Signal
- serwer Atlantis Land
- serwer Lantronix
- serwer NETSCOUT
- serwer Mobotix
- serwer Origin Storage
Najnowsze instrukcje dla serwer
13 Października 2024
12 Października 2024
12 Października 2024
11 Października 2024
11 Października 2024
11 Października 2024
10 Października 2024
9 Października 2024
9 Października 2024
9 Października 2024
