Using Your New Balance Sport Headphones with Foldable Neck Band
Your New Balance Headphones feature a foldable neckband for compact storage. Unfold the neckband
completely and place it over your head and behind your neck as shown with the earpieces over your ears
and the headphone plug on your left side.
Your New Balance Sport Headphones are
supplied with two additional sets of plastic
color caps to allow you to customize the
look to match your mood. To replace the
original caps simply lift up the edge of the
cap as shown to remove it. Install a new
cap and gently press down on the cap until
it ‘snaps’ into place.
Your New Balance Sport Headphones are also supplied
with two sets of silicon speaker covers. You may wish to
replace the original sponge speaker covers with the
washable silicon speaker covers if you perspire heavily
during exercise.
To replace the speaker covers, carefully lift the sponge
covers off the speaker housing and then stretch the silicon
covers over the housing.
Your New Balance Sport Headphones were designed with a modular cord system. We have provided a 15”
iPod/iPhone control cable that is suitable if your music player will be worn in an armband or clipped to your
clothing at chest level. We have also provided a 36” cable that is suitable if your music player will be clipped
to your belt, placed in your pocket or carried in a fanny-pack. You may connect both cables together in
case you want to control your iPod or iPhone and the 15” or 36”cable is not long enough.
Connect the male headphone plug of the headphones to the female headphone jack of either the 15” or
36” headphone cable depending on your wearing preference. Then connect the male headphone plug of
the 15” or 36” cable to the headphone jack of your music player. Be sure that the plugs are fully inserted
into the jacks. If the plugs are not fully inserted you may only hear sound from one earpiece.
Using the iPod/iPhone Control Cable
Connect the 15” iPod/iPhone cable between your headphones and your iPod/iPhone to perform the
following operations with the remote controller mounted on the cable:
Model: NB464
Behind-The-Neck
Sport Headphones
To Do This Action Required
Activate voice control* Depress the Master Control for 2 seconds
Answer or end a call Press the Master Control once to answer call
Press the Master Control again to end call
Ignore an incoming call Depress the Master Control for 2 seconds
Answer a second incoming call Press the Master Control once to answer second call
and place original call on hold Press the Master Control again to return to first call
Answer a second incoming call, Depress the Master Control for 2 seconds
and end original call 2 low tones will confirm end of original call.
Switch between two calls Press the Master Control once to switch between calls
Play or Pause Press Master Control once to Play, again to Pause
Skip Track or Chapter Forward Press Master Control 2 times quickly
Skip Track or Chapter Back Press Master Control 3 times quickly
Increase Volume Press the "+" button
Decrease Volume Press the " - " button
Activate VoiceOver** Press and hold the Master Control to hear title and
artist of currently playing song
Navigate Playlists using VoiceOver** Press and hold the Master Control until tone is heard,
then release. When the name of the desired playlist is
heard, press the Master Control once to select it.
Click to Increase
Volume Click p1-x2 for Next Track
Click p1-x3 for Previous Track
Press + Hold for iPod
Shuffle VoiceOver
Click to Decrease
Volume
Click to Play/Pause
Master Control
Model: NB464 (Back) (REV 1 )
Print color : Black text on white paper
Size of manual: 140mmW x 280mmH
Date: July 15, 2010
Using the Water Resistant Connection Cover
Your New Balance Ear Buds are also supplied with a silicon sleeve that can be used to cover the
connection between the male headphone plug on the Ear Buds and the female headphone jack on the 15”
or 36” cable. Use this connection cover if you routinely use your Ear Buds in extremely wet or damp
conditions.
Stretch the connection cover over the plug of the Ear Buds as shown.
After connecting the male plug of the Ear Buds to the female jack on the
15” or 36” cable. Slide the connection cover down so that it completely
covers the plug and jack connection point to seal out excess moisture.
Safety Information
To protect your hearing, always start listening with the Volume Control of
your music player set to a low level and gradually increase the volume to
a comfortable listening level.
IMPORTANT! Listening at high volume for long periods of time can result
in long-term hearing damage. For your safety, do not use headphones if
they would prevent you from hearing warning sounds, such as while
driving a car or motorcycle, riding a bike, etc.
NOTE: In extremely cold or dry air conditions you may notice a slight
‘tingling’ feeling in your ears when using in-ear headphones. This is the
result of the build-up of static electricity in your body. This is normal and
not an indication of any problem with your headphones.
Using the Accessory Cord Winder Clip
Your New Balance Ear Buds are also supplied with a cord winder clip that may be used to eliminate excess
slack in the 36” cable if necessary. If you find that that the 36” cable is too long you can store up to 24” of
cable in the cord winder and then clip the cord winder to your clothing.
close the cord winder
wrap cord clockwise around the
spool to reach desired length
open the cord winder
using the small tab
under the clip
pass the plug down
and through the cover
clip it on and go!
wind over
20 inches!
pull the cord back up
and over the spool

Specyfikacje produktu

Marka: IHome
Kategoria: zestaw słuchawkowy
Model: NB464
