Strona 1/1

BACK PANEL

FEATURES & FUNCTIONS

TOP PANEL

iW18-053119-A Printed in China

Questions? Visit www.ihome.com

or call 1-800-288-2792 Toll Free

WARRANTY

For product support information and warranty please visit:

www.ihome.com/support

USB Charging Port

(5V/1A)

QUESTIONS? visit www.ihome.com or call 1-800-288-2792

Model: iW18

FCC ID: EMOIW18

IC: 986B-IW18

Model: iW18

Quick Start Guide

-1 +1 Auto

DS T

us b cha rgin g

LEFT PANEL RIGHT PANEL

pres s down whole unit to s nooze

BOTTOM PANEL

GETTING STARTED

DST Switch DC Jack

(9V/2.5A)

Alarm

Set

Time Set/

Display Dimmer

Forward

Reverse

Battery Backup

Compartment

Wireless

Charging

Area

Before use, remove the battery pull

tab from the bottom of the unit.

Connect the included AC adapter to

the DC jack located on the back of

the unit and connect the other end

to a working wall outlet.

Connecting the Unit

Step One

RESE T

TEST

Setting Your Clock

Step Two

•

Press and hold the Time Set

Button until the display ﬂashes.

• Press the to adjust – or + Buttons

selections and press Time Set to

conﬁrm.

• Do this for time, year, month and

date.

• All done!

Daylight Savings Time (DST) Switch:

By default, the DST Switch is set to Auto and will automatically

adjust the time each March and November.

DISPLAY ICONS

PM Indicator

Wireless

Charging

Indicator

Low Backup

Battery Indicator

Alarm

Indicator

SETTING THE ALARM

Note: Each step must be completed while display is ﬂashing or

setting will time-out with any changes saved.

1. Press and hold the for 2 seconds until the alarm time Alarm Button

display and alarm icon ﬂash.

2. Press the – or + Buttons to adjust the alarm time to the desired time

(hold for rapid setting).

Make sure you set the correct AM/PM alarm

time. The PM indicator appears to the left of the display.

3. Press the to conﬁrm the alarm time setting. The alarm Alarm Button

schedule will ﬂash: 7 (every day), 5 (weekdays) or 2 (weekend only).

Press the to select the desired alarm schedule.– + Buttonsor

4. Press the to conﬁrm the alarm schedule. 2 beeps will Alarm Button

conﬁrm alarm setting is complete. The alarm icon will remain on the

display, indicating the alarm is armed.

5. To turn o a sounding alarm and reset it to come on the next day at

the same time, press the Alarm Button to reset alarm.

Press and release the desired Alarm Button as needed to preview the

alarm and to toggle the alarm ON (indicated by the alarm icon) or

OFF (no alarm icon).

PREVIEWING THE ALARM

PROGRAMMABLE SNOOZE

To adjust the brightness of the display, press the Time Set Button

repeatedly to cycle through brightness settings, including OFF.

Snooze

(press down on unit)

WIRELESS CHARGING

Check the lightning icon on the iW18 display for charging status:

Slow blinking icon: Device is charging properly.

Solid icon: Device is charged.

Rapid blinking icon: Device is not charging properly. Reposition

device.

Note: The lightning icon may continue to blink slowly when iOS

devices are fully charged.

CAUTION:

Remove metal protective or magnetic case from phone before

charging. When charging phone, do not place magnetic-striped or

other metal objects on the charger. Doing so could damage the

object or this unit. Qi compatible phones with metallic looking

ﬁnishes will charge normally.

USB CHARGING

BATTERY BACK-UP

The unit comes with a CR-2450 back-up battery installed to

provide continuous alarm operation and clock settings in the event

of a temporary power failure. Remove the battery pull tab before

use. When the battery icon on the clock display is ﬂashing, it is time

to replace the back-up battery. The battery compartment is

located on the bottom of the unit.

1. Make sure the AC adapter is

connected, or you will lose your time

and alarm settings during battery

replacement.

2. Use a Phillips screwdriver to open

the battery compartment door.

3. Remove the exhausted battery from

the compartment and insert 1

CR-2450 battery, checking that the

+ side is facing you. Replace the

compartment door. Do not

overtighten.

WARNING: Lithium batteries can explode or cause burns if disassembled,

shorted, recharged, exposed to water, ﬁre, or high temperatures. Do not

place loose batteries in a pocket, purse, or other container containing metal

objects, mix with used or other battery types, or store with hazardous or

combustible materials. Store in cool, dry, ventilated area. Follow applicable

laws and regulations for transport and disposal.

• Do not ingest the battery, Chemical Burn Hazard. This product contains a

coin/button cell battery. If the coin/button cell battery is swallowed, it can

cause severe internal burns in just 2 hours and can lead to death.

• Keep new and used batteries away from children. If the battery

compartment does not close securely, stop using the product and keep it

away from children. If you think batteries might have been swallowed or

placed inside any part of the body, seek immediate medical attention.

• Attention should be drawn to the environmental aspects of battery

disposal.

IMPORTANT SAFETY INSTRUCTIONS

Supports:

• Qi compatible phones (also works with plastic cases up to 3mm thick)

• AirPods with wireless charging case

Place Qi compatible device face up on the charging rest as pictured below:

When used in the directed manner, this unit has been designed and manufactured to ensure your

personal safety. However, improper use can result in potential electrical shock or ﬁre hazards.

Please read and follow all safety and operating instructions carefully before installation and use, and

keep these instructions handy for future reference. Take special note of all warnings listed in these

instructions and on the unit.

1. Water and Moisture – The unit should not be used near water. For example: near a bathtub,

washbowl, kitchen sink, laundry tub, swimming pool or in a wet basement.

2. Ventilation – The unit should be situated so that its location or position does not interfere with

its proper ventilation. For example, it should not be situated on a bed, sofa, rug or similar

surface that may block ventilation openings. Also, it should not be placed in a built-in

installation, such as a bookcase or cabinet, which may impede the ﬂow of air through the

ventilation openings.

3. Heat – The unit should be situated away from heat sources such as radiators, heat registers,

stoves or other appliances (including ampliﬁers) that produce heat.

4. Power Sources – The unit should be connected to a power supply only of the type described in

the operating instructions or as marked on the appliance. Only use the AC adapter that came

with the unit.

5. Power-Cable Protection – Power supply cables should be routed so that they are not likely to

be walked on or pinched by items placed upon or against them. It is always best to have a clear

area from where the cable exits the unit to where it is plugged into an AC socket.

6. Cleaning – Clean only with dry cloth.

7. Objects and Liquid Entry – Care should be taken so that objects do not fall and liquids are not

spilled into any openings or vents located on the product.

8. Attachments – Do not use attachments not recommended by the product manufacturer.

9. Lightning and Power Surge Protection – Unplug the unit from the wall socket and disconnect

the antenna or cable system during a lightning storm or when it is left unattended and unused

for long periods of time. This will prevent damage to the product due to lightning and

power-line surges.

10. Overloading – Do not overload wall sockets, extension cords, or integral convenience

receptacles as this can result in a risk of ﬁre or electric shock.

11. Damage Requiring Service – The unit should be serviced by qualiﬁed service personnel when:

A. the power supply cable or plug has been damaged.

B. objects have fallen into or liquid has been spilled into the enclosure.

C. the unit has been exposed to rain.

D. the unit has been dropped or the enclosure damaged.

E. the unit exhibits a marked change in performance or does not operate normally.

12. Periods of Nonuse – If the unit is to be left unused for an extended period of time, such as a

month or longer, remove batteries before storage

13. Servicing – The user should not attempt to service the unit beyond those methods described

in the user manual. Service methods not covered in the operating instructions should be

referred to qualiﬁed service personnel.

14. Magnetic Interference: This product’s speakers contain powerful magnets which could cause

interference or damage to sensitive equipment such as hard drives, CRT televisions and

monitors, as well as medical, scientiﬁc, and navigational devices. Keep this unit away from these

products at all times.

15. Only use attachments/accessories speciﬁed by the manufacturer. This product is suitable for

use in tropical and/or moderate climates.

16. The unit should be serviced by qualiﬁed service personnel when the enclosure damaged or

does not operate normally.

17. No naked ﬂame sources, such as lighted candles, should be placed on the apparatus.

18.

WARNING: To reduce the risk of ﬁre or electric shock, do not expose this product to rain or moisture.

19. CAUTION – Danger of explosion if battery is incorrectly replaced. Replace only with the same

or equivalent type.

20. Do not dispose of batteries in the household trash or ﬁre

21. The mains plug of power adaptor is used as the disconnect device, it shall remain readily

operable.

1. To program Snooze, press down on the

front of the unit for 2 seconds during

normal operation (when no alarm is

sounding).

2. Press the

– + Buttonsor to select a snooze time (between 01 and

29 minutes).

3. Press down and release the front of the unit to conﬁrm setting.

While the alarm is sounding, press down on the front of the unit to

temporarily silence the alarm (9 minutes is the default). Snooze

can be used several times during the one hour alarm cycle.

Connect the standard size end of a

USB cable (not included) to the USB

port on the back of the unit and

connect the other end to the charging

port on your device.

(Make sure the unit is plugged into a

working outlet in order to charge

devices.)

This device complies with Part 15 of the FCC Rules, operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired operation.

• Warning: Changes or modiﬁcations to this unit not expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.

• NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by turning the

equipment o and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

CAN ICES-3 (B)/NMB-3(B), CAN RSS216 / CNR-216

This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.

This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following

two conditions:

(1) This device may not cause interference and (2) This device must accept any interference received,

including interference that may cause undesired operation

This equipment should be installed and operated with minimum distance 20cm between the radiator &

your body.

IC Statement

This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and

Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two

conditions:

(1) This device may not cause interference.

(2) This device must accept any interference, including interference that may cause undesired operation

of the device.

The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and

compliance with RSS-102 RF exposure, users can obtain Canadian information on RF exposure and

compliance.

This equipment should be installed and operated with a minimum distance of 20 cm between the

radiator and your body.

L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR

d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts

de licence. L’exploitation est autorisée aux deux conditions suivantes :

(1) L’appareil ne doit pas produire de brouillage;

(2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible

d’en compromettre le fonctionnement.

Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS 102 et

la conformité à l'exposition de RSS-102 rf, utilisateurs peut obtenir l'information canadienne sur

l'exposition et la conformité de rf.

Cet équipement doit être installé et utilisé avec une distance minimale de 20 cm entre le radiateur et

votre corps.

FCC INFORMATION

DC 9V, 2.5A

Designed and Engineered in the USA

Mfd. & Srvcd. by SDI Technologies, Inc.

Model No: iW18

Service No: iW18-A-A

AC Adaptor:

DC 9V, 2.5A

USB Output:DC 5V, 1A

www.iHome .com | Made in China

Pa te nts: www.ihome .c om/pa te nts

Toll Free : 1-800-288-27 92

WIRELES S CHARGE R:

FCC ID: EMOIW18

IC: 986 B-IW18

Bedside/Oce Clock

with Dual Charging

Specyfikacje produktu

Marka:	IHome
Kategoria:	radio
Model:	IW18
Kolor produktu:	Czarny
Źródło zasilania:	USB
Wysokość produktu:	55.118 mm
Szerokość produktu:	139.7 mm
Głębokość produktu:	122.174 mm
Ilość na paczkę:	1 szt.
Port USB:	Tak
Liczba portów USB 2.0:	1
Model:	Cyfrowy budzik
Kolorowy wyświetlacz:	Nie
Ładowanie przez łącze USB:	Tak
