Instrukcja obsługi IHome iB90

IHome zestaw słuchawkowy iB90

Przeczytaj poniżej 📖 instrukcję obsługi w języku polskim dla IHome iB90 (1 stron) w kategorii zestaw słuchawkowy. Ta instrukcja była pomocna dla 3 osób i została oceniona przez 2 użytkowników na średnio 4.5 gwiazdek

Pobierz PDF

Strona 1/1

1. Connect the micro USB plug on the charging cable to the micro USB port on the headphone.

2. Connect the standard USB plug on the charging cable to any standard USB power port such as found

on a notebook computer, or the charging adapter for an iPod, iPhone, etc.

The Power/Charging/Pairing indicator will glow RED while the headphone is charging. The indicator will

turn oﬀ when the battery is fully charged.

Reminder: Allow the battery to charge fully before ﬁrst time use. Normal recharge time should take

about 3.5 hours. When fully charged the battery provides up to 43 hours of working time, or 90 days of

standby time.

Because your iB90v2 headphones use Bluetooth version 4.1 the battery level indicator of the

headphones may also appear on your iPhone home screen, usually adjacent to the phone’s own battery

level indicator, if your speciﬁc phone supports this display function.

3. Multi-Function Button (MFB)

Pressing the MFB button turns the headphones “On”, initiates pairing, answers/ends phone calls,

controls Play/Pause function and turns the headphones “Oﬀ’.

4. Switching the Power On and Oﬀ

1. Press and hold the Multi-function button for approximately 3 seconds. The voice prompt will say

“Power On” and the LED indicator turns BLUE and ﬂashes two times per second.

2. When the power is “On” press and hold the Multi-function button for approximately 3 seconds. The

voice prompt will say “Power Oﬀ”. The LED indicator remains on brieﬂy and then shuts oﬀ. This

indicates that the power is “Oﬀ”.

5. Manually Pairing With a Bluetooth Enabled Smartphone or Music

Player For The First Time

If your smartphone or music player, such as the iPod touch, is Bluetooth enabled (supports the A2DP

Bluetooth Proﬁle) you may pair these iHome headphones with your phone, music player, tablet or

computer to listen to music and make or receive calls as long as the two devices are within the Bluetooth

operating range of approximately 33-feet of each other.

Note: Your iHome headphones must be in the Power “Off” mode to begin the manual pairing process.

1. Make sure that your iHome iB90v2 headphones are switched “Oﬀ”. Make sure that your smartphone

or music player is “On”.

2. Press and hold the Multi-function button on your iB90v2 headphones for about 6 seconds until you

hear the “Power On” and “Pairing” voice prompts. The LED indicator begins alternately ﬂashing blue

and red to indicate it is trying to pair with a compatible device.

3. If necessary, turn on the Bluetooth function of your phone or music player so that it begins searching

for a compatible device.

4. “iHome iB90v2” should appear on your phone or music player’s compatible devices list. You may also

see a message such as “Not Paired”. Tap on that message to complete the pairing process. If your

phone or music player asks for a “password” to complete the pairing process, enter ‘0000’ on the

keypad of your phone or music player.

5. When pairing is successful the screen on your phone should show “iHome iB90v2 Connected” or

similar message and you will hear the voice prompt say “Your device is connected”. The LED

indicator on the iB90v2 headphones will begin flashing blue two times per second. Your headphones are

now ready for use.

NOTE: If your iB90v2 headphones are not able to ﬁnd a Bluetooth device that is in range and

“discoverable” after 3 minutes, the headphones will automatically power “Oﬀ” to preserve the battery.

6. Auto-Linking With A Previously Paired Device

If your iB90v2 headphones were previously paired with a Bluetooth enabled smartphone or music

player they will attempt to auto-link with that device again whenever that device is within the Bluetooth

operating range.

Press and hold the Multi-function button on your iB90v2 headphones for about 3 seconds until you hear

the “Power On” voice prompt. If a previously paired device is found to be within range and turned ‘On’

the iB90v2 will re-link with it automatically. You will hear the voice prompt say “Your device is

connected.”

Note: If no previously paired device is found after 3 minutes the auto-linking function stops and your

iB90v2 headphones shut oﬀ automatically to preserve the battery life.

7. Wearing Your Headphones

Your iHome iB90v2 Bluetooth headphones are supplied with padded ear cushions for long wearing

comfort. The headband can be extended to accommodate almost any head size. There are ‘L’ and ‘R’

markings on the inside of the headband, When the headphones are worn properly the controls will be

on your right side.

8. Using Your Headphones

Note: Some of the functions described below may not be supported on your speciﬁc smartphone. Check

with your smartphone owner’s manual to conﬁrm the features supported by your phone.

Introduction

Speciﬁcations

9. Auxiliary Input Jack

1. Controls and Indicators

2. Charging Your Headphones

Model: iB90v2

Premium Wireless

Headphones

Action Required

When headphones are “Oﬀ” press and hold the MFB inward for 3-5 seconds until you

hear the "Power On" voice prompt.

When headphones are “Oﬀ” press and hold the MFB inward for 6 seconds until you hear

the "Pairing" voice prompt. The LED indicator ﬂashes blue and red rapidly.

Make sure your Bluetooth device is “On” and in the Pairing Model. When iHome iB90v2

appears on your devices menu, select it to complete pairing.

In pairing mode, press and hold the “>>” button for 3-5 seconds to reset headphone and

enter pairing mode again.

Short press the MFB to start playback. Short press to pause playback.

Short press to resume playback.

Press the >> button during playback

Press the << button playback

Press and hold the “+” button during playback

Press and hold the “ - ” button during playback

Short press the MFB when you hear the incoming ring sound. NOTE: Music will

automatically pause when you are answering a call and resume when you end the call.

Press and hold the MFB for 1 - 2 seconds to decline the incoming call.

Short press the MFB to end the call and “hang up”.

While the call is in progress press & hold the MFB 2 seconds to transfer the call between

the phone and the headphone.

When phone is paired with headphone but no call is in progress, double press the MFB

to redail the last number

Double press the MFB to place current call on hold and answer an incoming 2nd call.

Double press again as needed to switch between calls.

Press and hold the MFB for 3 seconds until your hear the “Power Oﬀ” prompt and LED

indicator shuts oﬀ.

Press and hold the “<<” button for 3-4 seconds

While listening to audio, press and hold the “<<” button for 3-4 seconds to send voice

command.

Function

Turn headphones “On”

Enter Pairing Mode

Pairing

Reset Bluetooth

Play / Pause

Skip to next track

Skip to beginning of current track

or go to the previous track.

Increase volume

Decrease volume

Answer an incoming phone call

Decline an incoming phone call

End a call

Transfer a call between the

phone and the headphones

Last number redial

Answer second call/

call waiting

Turn headphones “Off”

Siri/Google Voice function

Voice command

PREPARATION FOR USE

• It is dangerous and illegal (in some jurisdictions) to use headphones when you are driving a car, riding a

bike or motorcycle, or operating a watercraft. Be aware of local laws and regulations.

•

Do not use these headphones in situations where they might cause distractions or prevent you from

hearing warning sounds.

• There are no user serviceable parts in these headphones. Do not attempt any service or repairs on your

own. Refer to the warranty for service, repair or replacement information.

Your new iHome Bluetooth stereo headphones are designed to link with your Bluetooth enabled

smartphone or music player to allow you to wirelessly listen to music and answer phone calls within

the normal 10 meter (33 feet) Bluetooth operating range.

What’s Included

18 9

Computer USB port

USB Adaptor

(not included)

1. Multi-function button: Power On/Oﬀ,

Answer/End, Pair and Play/Pause.

2. Power/Pairing/Charging LED Indicator

3. Volume Up (+) Button

4. Skip Track Forward Button ( )

5. Volume Down Button ( - )

6. Skip Track Reverse Button ( )

7. Microphone

8. Micro USB Charging Port

9. Auxiliary Input Jack

Right side Left side

CARE AND MAINTENANCE

1. Reception is noisy or intermittent

Make sure that the headphones and the paired device are within the Bluetooth operating range of

approximately 33-feet. Make sure the headphones are fully charged as well.

2. No Sound

Make sure that your headphones are properly paired and connected with your Bluetooth enabled

smartphone or music player. Refer to the “Pairing” instructions in this manual and in the manual

supplied with your phone or music player if necessary.

The rechargeable battery in your headphones may be exhausted and need to be recharged. Refer to

the “Charging Your Headphones” instructions in this manual.

3. Unable to Pair/Connect

The pairing settings between the headphones and your smartphone or music player may have been

erased or deleted. Follow the “Pairing” instructions in this manual to re-pair and reconnect the devices.

Turn oﬀ any other Bluetooth devices that are not being used to reduce external interference.

4. Some Functions Do Not Work

Your speciﬁc model of smartphone may not support some of the functions described in this manual.

Refer to the manual supplied with your phone for further information.

TROUBLESHOOTING

LIMITED 1 YEAR WARRANTY

• USB Charging Cable

• Bluetooth Stereo Headphones

iHome Products, a division of SDI Technologies Inc. (hereafter referred to as SDI), warrants this product to be free

from defects in workmanship and materials, under normal use and conditions, for a period of one (1) year from the

date of original purchase.

Should this product fail to function in a satisfactory manner, it is best to ﬁrst return it to the store where it was originally

purchased. Should this fail to resolve the matter and service still be required by reason of any defect or malfunction

during the warranty period, SDI will repair or, at its discretion, replace this product without charge. This decision is

subject to veriﬁcation of the defect or malfunction upon delivery of this product to the Factory Service Center

authorized by Customer Service.

If service is required, please call Customer Service at 1-800-288-2792 to obtain a Return Authorization Number and

shipping instructions. A copy of the sales receipt is required to validate in-warranty coverage.

Disclaimer of Warranty

NOTE: This warranty is valid only if the product is used for the purpose for which it was designed. It does not cover (i)

products which have been damaged by negligence or willful actions, misuse or accident, or which have been modiﬁed

or repaired by unauthorized persons; (ii) cracked or broken cabinets, or units damaged by excessive heat; (iii) damage

to digital media players, CD’s or tape cassettes (if applicable); (iv) the cost of shipping this product to the Factory

Service Center and its return to the owner.

This warranty is valid only in the United States of America and does not extend to owners of the product other than to

the original purchaser. In no event will SDI or any of its aﬃliates, contractors, resellers, their oﬃcers, directors,

shareholders, members or agents be liable to you or any third party for any consequential or incidental damages, any

lost proﬁts, actual, exemplary or punitive damages. (Some states do not allow limitations on implied warranties or

exclusion of consequential damages, so these restrictions may not apply to you.) This warranty gives you speciﬁc

legal rights, and you may also have other rights which vary from state to state.

Your acknowledgment and agreement to fully and completely abide by the above mentioned disclaimer of warranty is

contractually binding to you upon your transfer of currency (money order, cashier's check, or credit card) for purchase

of your SDI product.

Questions? Visit www.ihome.com

or call 1-800-288-2792 Toll Free

Bluetooth is a registered trademark of Bluetooth SIG Inc.

Bluetooth technology is incorporated under license from Bluetooth SIG Inc.

Siri is a trademark of Apple, Inc., registered in the U.S. and other countries.

Google Voice is a trademark of Google, Inc.

Always remember to turn your headphones oﬀ if they will not be used for a long period of time. Do not

expose your headphones to extremely hot or cold temperatures for extended periods. Do not expose

them to direct sunlight or leave them in places such as the dashboard of your car on a hot day. Prevent

water or any other liquids from entering the cabinets of your headphones.

Protect Your Hearing

Using these, or any headphones at high volume levels for long periods can result in permanent hearing

damage. Always start listening with volume controls on your headphones and your paired smartphone

or music player at a low level and then gradually increase the volume controls to a comfortable listening level.

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:

(1) this device may not cause interference, and

(2) this device must accept any interference, including interference that may cause undesired operation of the device.

• Warning: Changes or modications to this unit not expressly approved by the party responsible for compliance could void the user’s

authority to operate the equipment.

• NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules, operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation.

FCC Information

FCC ID: EMOIB90

IC: 986B-IB90

iB90v2-090716-A Printed in China

IMPORTANT: Your headphones operate on a built-in rechargeable lithium-ion battery. Although the

battery was fully charged when it left our factory, like all rechargeable batteries it can begin to

discharge during periods of non-use. We recommend that you charge the battery for at least 3.5 hours

before ﬁrst time use.

Computer connected

to working outlet

The auxiliary input jack allows you to use your iB90v2 Bluetooth headphones as normal headphones

that you can listen to music on any non-Bluetooth device that is equipped with a 3.5mm headphone jack.

Connect a stereo audio cable (not included) with 3.5mm plugs on

both ends to the auxiliary input jack on the bottom of the ‘L’ earpiece

of your iB90v2 headphones, and to the headphone jack of your

auxiliary music source.

Your iB90v2 headphones should be in the Power “Oﬀ” mode. Use

the volume and track navigation controls on your music player as

your would with any normal headphones.

Important Notes

Bluetooth speciﬁcation: Supports V4.1+ EDR with Handsfree Proﬁle 1.5, Headset Proﬁle 1.1 and A2DP

proﬁle 1.2 (Class ll) and Audio/Video Remote Control Proﬁle AVRP

Battery: 1000mAh

Standby time (unpaired): up to 90 days (with fully charged battery)

Talk time: up to 43 hours (with fully charged battery)

Music Playing time: up to 43 hours (with fully charged battery)

Operating Distance: up to 10 meters / approximately 33 feet

Certiﬁcations: CE, FCC, RoHS, BQB

With Mega 43 Hour Battery

Specyfikacje produktu

Marka:	IHome
Kategoria:	zestaw słuchawkowy
Model:	iB90
Kolor produktu:	Black, Red
Typ produktu:	Zestaw słuchawkowy
Styl noszenia:	Opaska na głowę
Typ zestawu słuchawkowego:	Stereofoniczny
Czas odtwarzania muzyki:	12 h
Technologia łączności:	Bezprzewodowy
Bluetooth:	Tak
Zasięg bezprzewdowego router'a:	9.1 m
Ilość:	1
Budowa słuchawek:	Okolicz fonetyczny
Regulacja głośności:	Cyfrowy
Złącze 3,5 mm:	Nie
Przyciski operacyjne:	Play/pause, Track <, Track >
Złącze 6,35 mm:	Nie
