Strona 1/80
128PS
EN Operator's manual 2-24
ES-MX Manual de usuario 25-50
FR-CA Manuel d’utilisation 51-76
LT28CSHV
Contents
Contents
Contents
ContentsContents
Introduction............................................................... 2
Safety........................................................................5
Assembly................................................................ 10
Operation................................................................ 11
Maintenance........................................................... 15
Troubleshooting...................................................... 22
Transportation, storage and disposal......................22
Technical data.........................................................23
Accessories.............................................................23
Introduction
Introduction
Introduction
IntroductionIntroduction
Intended use
Intended use
Intended use
Intended useIntended use
The product is used for cutting branches and twigs.
Note:
Note:
Note:
Note: Note: National regulations can set limit to the
operation of the product.
Only use the product with accessories that are
approved by the manufacturer. Refer to
Accessories
on page 23
.
Product overview
Product overview
Product overview
Product overviewProduct overview
8
29
13
27
12
1
23
28
26
25
21
16
2
5
6
4
7
3
9
17
11
20
24
19
18
15
10
22
14
1. Chain lubrication adjustment screw
2. Protective guard for saw chain
3. Chain tensioning screw
4. Saw chain
5. Chain oil tank
6. Guide bar
7. Bar nut
8. Transport guard, bar
9. Shaft
10. Shaft coupling
11. Extension shaft
12. Front handle
13. Harness
14. Harness support hook
15. Stop switch
16. Throttle trigger lockout
17. Throttle trigger
18. Choke control
19. Air purge
20. Fuel tank
2
2
2
22 1780 - 002 - 20.04.2022
21. Air filter cover
22. Spark plug cap and spark plug
23. Cylinder cover
24. Starter handle
25. Bar/chain oil
26. Two-stroke oil
27. Combination wrench, chain tensioner
28. Attachment hanger
29. Operator's manual
Symbols on the product
Symbols on the product
Symbols on the product
Symbols on the productSymbols on the product
WARNING! This product is dangerous.
Injury or death can occur to the
operator or bystanders if the product
is not used carefully and correctly.
To prevent injury to the operator or
bystanders, read and obey all safety
instructions in the operator's manual.
Please read the operator's manual
carefully and make sure that you
understand the instructions before use.
Use a protective helmet in locations
where objects can fall on you. Use
approved hearing protection. Use
approved eye protection.
Use approved protective gloves.
Use heavy-duty slip-resistant boots.
Make sure that long hair is put up
above your shoulders.
Fuel.
Air purge bulb.
Choke.
Chain oil.
Adjustment of the oil flow.
The arrows show the limits for the
position of the handle.
50
FT
15
m
50F
T
15 m
Safe distance
Make sure no person is within the
kickback danger zone.
Direction of rotation, saw
chain.
yyyywwxxxx
yyyywwxxxx
yyyywwxxxx
yyyywwxxxxyyyywwxxxx
The rating plate shows the serial
number. is the production
yyyy
yyyy
yyyy
yyyyyyyy
year, is the production week
ww
ww
ww
wwww
and is the sequential num-
xxxx
xxxx
xxxx
xxxxxxxx
ber.
This product is not electrically insulated. If the product touches or comes close to
high-voltage power lines it could lead to death or serious injury. Electricity can jump
from one point to another by arcing. The higher the voltage, the greater the distance
electricity can jump. Electricity can also travel through branches and other objects,
especially if they are wet. Always keep a distance of at least 10 m between the
machine and high-voltage power lines and/or any objects that are touching them. If you
have to work within this safe distance you should always contact the relevant power
company to make sure the power is switched off before you start work.
The operator of the product must ensure, while working, that no persons or animals
come closer than 15 meters.
1780 - 002 - 20.04.2022 3
3
3
33
