Features
• Auto-stop at tape end
• Built-in microphone for voice recording
• Built-in speaker with analog volume control
• Aux In (3.5mm audio input)
• 3.5mm headphone jack
• DC power input
• DC battery power:
requires 4 C batteries (not included)
Includes
• AC/DC power adapter
Cassette Tape Use:
This unit supports casettes up to C90.
Larger tapes with more than 45 minutes of playing
time (C120) per side are not recommended. Longer
duration tapes pose a greater risk of defect for both
the cassette and the cassette player. Use only high
quality tapes with a duration of 45 minutes or less.
• WARNING: This product may contain chemicals known to the State of
California to cause birth defects, or other reproductive harm (California Prop
65). Wash hands after handling.
• This product meets and complies with all Federal regulations.
Overview
Cassette Recorder
User’s Guide for Model PRC257B v1894-01
Important Safety Instructions
• Read these Instructions.
• Keep these Instructions.
• Heed all Warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including ampliers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding - type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. When the provided plug does not t into
your outlet, consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
• Only use attachments/accessories specied by the manufacturer.
• Unplug this apparatus during lightning storms or when unused
for long periods of time.
• Refer all servicing to qualied service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
• Use only with a cart, stand, tripod, bracket, or table specied by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
FCC Warnings
Warning: Changes or modications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Additional Warnings and Precautions
• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE
OF PLUG TO WIDE SLOT, FULLY INSERT.
• Mains plug is used as disconnect device and it should remain readily operable
during intended use. In order to disconnect the apparatus from the mains
completely, the mains plug should be disconnected from the mains socket
outlet completely.
• WARNING: Shock hazard - Do Not Open.
• Caution and marking information is located at the rear or bottom of the
apparatus.
• WARNING: To reduce the risk of re or electric shock, do not expose this
apparatus to rain, moisture, dripping, or splashing.
• CAUTION: Use of controls or adjustments or performance of procedures
other than those specied may result in hazardous radiation exposure.
• WARNING: Changes or modications to this unit not expressly approved by
the party responsible for compliance could void the user’s authority to operate
the equipment.
• CAUTION: Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type.
• WARNING: There is a danger of explosion if you attempt to charge standard
Alkaline batteries in the unit. Only use rechargeable NiMH batteries.
• Objects lled with liquids, such as vases, shall not be placed on the apparatus.
• Battery shall not be exposed to excessive heat such as sunshine, re or the
like.
• Keep new and used batteries away from children. If the battery compartment
does not close securely, stop using the product and keep it away from children.
• If you think batteries might have been swallowed or placed inside any part of
the body, seek immediate medical attention.
• Do not mix old and new batteries.
• Completely replace all old batteries with new ones.
• Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh,
etc) batteries.
• Batteries should be recycled or disposed of as per state and local guidelines.
AUTOMATIC STOP
RECORD PLAY REWIND F.FWD STOP/EJE USECT PA
MIC
DC 5V
AUX
Play
Record
Rewind/
Forward
Headphone Jack
Aux In
Carry Handle
Built-in Speaker
Record/
Low Battery
Indicator
DC Power Input
Cassette Door
Stop/Eject
Pause
Volume
Built-in Microphone
WARNING: To reduce the risk of electric shock, do
not remove cover (or back). No user-serviceable parts
inside. Refer servicing to qualied service personnel.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
This symbol indicates that this product incorporates
double insulation between hazardous mains voltage and
user accessible parts.
The lightning ash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufcient magnitude
to constitute a risk of electric shock to persons.
WARNING: DO NOT INGEST BATTERY,
CHEMICAL BURN HAZARD.
DC 5V
AUX
DC 5V
AUX
Playing a Cassette
This unit supports casettes up to C90. Larger tapes with more than 45 minutes
of playing time (C120) per side are not recommended. Longer duration tapes pose
a greater risk of defect for both the cassette and the cassette player. Use only high
quality tapes with a duration of 45 minutes or less.
1. Press Stop/Eject to open the cassette door and load a cassette.
2. Close the cassette door.
3. Use the recorder’s controls to play, pause, rewind, and fast forward audio
from the cassette. Use the Volume dial to adjust to the desired level.
Recording
Note: The recorder only records in Mono, Stereo is not available. The recorder
will automatically set the recording level, the Volume dial does not control the
recording level.
1. Press Stop/Eject to open the cassette door and load a blank cassette.
2. Close the cassette door.
3. When you are ready, press the buttons at the same time to Play and Record
begin recording audio. Do not force the Record button down if a tape’s erase
protection tabs have been removed, this may cause damage to the recorder.
4. Press the Pause button to pause recording. Press again to resume.
5. Press the Stop/Eject button to stop recording. Recording will stop
automatically if you reach the end of the tape.
Power
Battery Power
For battery power, this unit requires 4 C sized batteries (not included).
AC/DC Power
Using an AC/DC power adapter (included), plug the adapter into a standard power
outlet and the DC Power Input on the unit.
Built-in Mic: remain within 2.5 ft.
External Mic: connect to Aux In
For headphones/earbuds, connect to
Headphone Jack (3.5mm audio)
To download this User’s Guide in English, Spanish, or French, or to get answers to frequently asked questions, visit the
support section at: www.gpx.com
Para descargar este Manual del Usuario en inglés, español y francés, o para obtener respuestas a preguntas frecuentes,
visite la sección de apoyo en: www.gpx.com
Pour télécharger ce guide de l’utilisateur en anglais, espagnol ou français, ou pour obtenir des réponses à des questions
fréquemment posées, consultez la rubrique d’assistance sur: www.gpx.com
For Warranty Information and the most up-to-date version of this User’s Guide, go to www.gpx.com
Customer Service: | Email Support: | Email Parts: 1-888-999-4215 prodinfo@dpiinc.com partsinfo@dpiinc.com
Copyright © 2017 Digital Products International (DPI, Inc.) All other trademarks appearing herein are the property of their
respective owners. Specications are subject to change without notice.
International Support
DC 5V
AUX
