Instrukcja obsługi Evolveo StrongPhone SGP-Q7

Evolveo smartfon StrongPhone SGP-Q7

Przeczytaj poniżej 📖 instrukcję obsługi w języku polskim dla Evolveo StrongPhone SGP-Q7 (1 stron) w kategorii smartfon. Ta instrukcja była pomocna dla 4 osób i została oceniona przez 2 użytkowników na średnio 4.5 gwiazdek

Pobierz PDF
Strona 1/1
ENG
StrongPhone Q7 LTE
Q UICK START GUIDE
4G LTE
ANDROID SMARTPHONE
QUAD CORE
WATERPROOF
O U T D O O R
ENG
Dear customer, thank you for choosing an EVOLVEO
mobile phone. Here are some recommendations
related to its safe use:
EVOLVEO StrongPhone Q7 LTE is designed to be a lot
more durable than a regular cellphone, however, it is not
completely indestructible.
EVOLVEO StrongPhone Q7 LTE complies with IP68
certification. However, even this compliance doesn't assure
it's complete waterproofness.
It is crucial to keep the headphone jack as well as the
microUSB port clean, as well as to keep all screws on the
back side firmly tightened, in order to maintain the water
and dust resistance of the phone.
Display of the phone can break upon hitting hard surface,
when exposed to a strong impact, or when the screen is
being bent or otherwise deformed. In case the screen is
damaged, do not attempt to repair it. Glass broken as a result
of a misuse or abuse is not a subject to warranty.
Clean the cellphone immediately if it gets in contact with
products which can cause stains, such as ink, color,
makeup, food, oil, etc. Disconnect all cables, turn the
phone off and use a soft cloth. Do not use window
cleaners, household cleaning products, aerosol sprays
canisters, solvents, alcohol, amoniac or abrasives.
This phone is a complex electronic device, therefore it
should be protected against impact and electromagnetic
field effects, it is not resistant to metal dust or other metal
particles.
In case your phone falls in water, brush it with a dry cloth,
and let it dry before turning it back on again.
Do not attempt to dry using external heat source, such as
microwave or a hairdryer.
EVOLVEO StrongPhone Q8 LTE is intended for use in
operating temperatures from 0° to 40°C and can be stored
in a temperature range from -20º to 45ºC. Lower or higher
temperatures can affect the cellphone operation or battery
life.
Do not use outside during storm, we hold no responsibility
for eventual device damage or injury caused by such
Do not puncture the speaker, do not insert any objects in
ports. Do not paint the phone with color as all of operations
listed above affect the phone functionality and sealing.
Description of this phone operation may differ from this
Use a forceps to remove the microSIM with the reducing
manual, based on the firmware version of your phone and
adapter to avoid bending it. This way you prevent the
microSIM card slot from damage.
specific terms and conditions of your mobile operator.
operation.
EVOLVEO StrongPhone Q8 LTE was tested in compliance
to EU radio waves, WiFi and Bluetooth standards. In case you
want to limit the effects of high-frequency energy, limit the
duration of your direct exposition to the electromagnetic
emissions, e.g. by using a Bluetooth hands-free set, or
keep a greater distance between your body and the
cellphone.
Never attempt to repair the phone by yourself, any
disassembly, including removing of outer screws and back
cover, can lead to a damage of the device, which is not
covered by the warranty.
Manufacturers, resellers and vendors hold no
responsibility for any data loss and direct or indirect
damage, related to the use of this phone, no matter how
exactly it is caused.
Repair and maintenance can only be handled at an
authorized service center for EVOLVEO phones (more at
otherwise the phone can be damaged
and warranty could be void.
www.evolveo.com),
Disposal
www.evolveo.com
0700
DECLARATION OF CONFORMITY
The symbol of crossed out container on the product, in
the literature or on the wrapping means that in the
European Union all the electric and electronic products,
batteries and accumulators must be placed into the
separate salvage after finishing their lifetime. Do not
throw these products into the unsorted municipal waste.
Hereby, the company Abacus Electric, s.r.o. declares
that GSM phone EVOLVEO StrongPhone Q7 LTE
is in compliance with the requirements of the norms and
regulations, relevant for the given type of device.
The complete text of Declaration of Conformity can be
found on ftp://ftp.evolveo.com/ce
All rights reserved. Design and specification can be
changed without prior notice.
The guarantee does not apply to:
• installation a different firmware then the original
EVOLVEO factor y firmware or ROOT of Android OS
• electromechanical or mechanical damage to the
phone caused by improper use by the user (such as
cracked screen or touch screen, cracked the front or
back cover of the phone, damaged microUSB
connector, slot for a SIM cards, microSD card slot,
headphone jack, etc.).
• damage to the speaker and headphone caused by
metal particles
• damage caused by natural causes such as fire, water,
static electricity, high or low temperature etc.
• defects caused by normal usage of phone
• unauthorized repair damage
• phone firmware if that requires updating because of
changes in the parameters of mobile networks
• defects of mobile phone operator network
• battery, if after 6 months of usage has not adhere
to its original capacity (warranty for the battery
capacity is six months)
• willful damage
Customer ser vice
Repairs and service may only be performed by an
authorized service location for phones EVOLVEO
(more informations: www.evolveo.com), otherwise you
can damage your mobile phone and lose your warranty.
Push up the TF card cover as
shown, insert the microSDHC card
in the specified slot.
Push up the SIM card cover,
insert the micro SIM card in the
specified card slot.
4G LTE
ANDROID SMARTPHONE
QUAD CORE
WATERPROOF
O U T D O O R
Phone
Earphones Camera
Volume +/-
SOS button
microUSB Flash
Programable
button
Power ON/OFF
Calling/phone dialer
Display turn OFF
End of the call
Quick access to phone settings
Drag the top information bar in
main screen down with your
finger in order to show
information such as WiFi,
Bluetooth, GPS or Data transfer
status, Audio profiles,
Brightness, Phone settings, etc.
Android OS was designed by Google and therefore it s '
possible to find some of its applications in phone (such
as Google Gmail, Google Maps and more).
Other apps can be installed using Google Play, in order
to do so it s necessary to set up a Google account '
(Settings > Accounts > Add account > Google).
Troubleshooting
Phone cannot be turned on
No sound can be heard
PIN error
Mobile phone turns off automatically,
Phone is "freezed" and unresponsive to touch
freezes or restarts
The phone behaves unexpectedly, some required
actions can't be carried
RECOVERY MODE (revert to factory defaults)
Hold the Power ON/OFF button for at least 20 seconds.
* Charge the battery, first charge for about half an hour, then
disconnect the charger, reconnect it again and finish the
charging
Make sure the volume isn't on minimum * Make sure the
phone isn't in „Airplane mode“
Contact your operator
* Make sure the auto-turn off feature is turned off
1. Hold the On/Off button until the phone restarts
* Hold the ON/OFF button for at least 20 seconds
* Return to Factory settings (Settings Backup r >& eset >
Factory data reset Reset phone)>
Settings > Back up and Reset > actor data resetF y
Erase all data on phone
Warning!
The phone will be reverted to default factory settings,
all passwords will be lost, as well as installed apps, etc.
(for up to 20 seconds).
* Check or replace the SIM card
Start
4G LTE
ANDROID SMARTPHONE
QUAD CORE
WATERPROOF
O U T D O O R
4G LTE
ANDROID SMARTPHONE
QUAD CORE
WATERPROOF
O U T D O O R
Insert microSDHC card
After inserting the SIM card firmly push
Open rear cover Close rear cover
14
3
Insert SIM card
Installation completed
25
against the marked places of rear cover,
otherwise it can not be guaranteed
watertight integrity of phone.
612 hour charging
We recommend to charge
the battery for at least
12 hours before first use.

Specyfikacje produktu

Marka: Evolveo
Kategoria: smartfon
Model: StrongPhone SGP-Q7
