Q UICK START GUIDE Phone
Loosen the screws
Turn the screws on battery
cover counter clockwise.
1
3G data transfers are only supported
in SIM1 slot.
Insert the SIM card
3
Insert the microSD card
microSD card contacts point downwards.
microUSB
Headphones
Camera
On/Off
4
Insert the battery
Put the cover on and tighten the
screws by turning them clockwise.
5
Charge for 12 hours
It is recommended to charge the
battery for at least 12 hours before
6
Open the battery cover
Lift the battery cover off.
2
Volume
Back
End callDial
Options
Home
SOS
Camera Flash
StrongPhone D2
ENG
Accept call Turn off display
ENG Troubleshooting
Phone cannot be turned on
No sound can be heard
PIN error
Mobile phone turns off automatically,
freezes or restarts
GPS fix takes too long
The phone behaves unexpectedly, some required
actions can't be carried
RECOVERY MODE (revert to factory defaults)
Quick access to phone settings
Specification
SAR information
Warranty doesn't apply to:
Disposal
www.evolveo.eu
2200
DECLARATION OF CONFORMITY
Dual SIM mode
first use.
Dear customer, thank you for choosing an EVOLVEO
mobile phone. Here are some recommendations
related to its safe use:
EVOLVEO StrongPhone D2 is designed to be a lot more
durable than a regular cellphone, however, it is not
completely indestructible.
EVOLVEO StrongPhone D2 complies with IP67
certification. However, even this compliance doesn't assure
it's complete waterproofness.
It is crucial to keep the headphone jack as well as the
microUSB port clean and sealed, as well as to keep all
screws on the back side firmly tightened, in order to
maintain the water and dust resistance of the phone.
Given many different possible modes of operation (e.g.
with or without USB cable attached, we hold no
responsibility for liquid damage.
The phone display is made of a hardened glass,
which can break upon hitting hard surface, when exposed
to a strong impact, or when the screen is being bent or
otherwise deformed. In case the screen is damaged, do
not attempt to repair it. Glass broken as a result of a
misuse or abuse is not a subject to warranty.
Clean the cellphone immediately if it gets in contact with
products, which can cause stains, such as ink, color,
makeup, food, oil, etc. Disconnect all cables, turn the
phone off and use a soft cloth. Do not use window
cleaners, household cleaning products, aerosol sprays
canisters, solvents, alcohol, amoniac or abrasives.
This phone is a complex electronic device, therefore it
should be protected against impact and electromagnetic
field effects, it is not resistant to metal dust or other metal
particles.
In case your phone falls in water, do not press keyboard
buttons, immediately brush it with a dry cloth, remove the
battery and let it dry before turning it back on again. Do
not attempt to dry using external heat source, such as
microwave or a hairdryer.
EVOLVEO StrongPhone D2 is intended for use in
operating temperatures from 0° to 40°C and can be stored
in a temperature range from -20º to 45ºC. Lower or higher
temperatures can affect the cellphone operation or battery
life.
Do not use outside during storm, we hold no
responsibility for eventual device damage or injury caused
by such operation.
Do not puncture the speaker, do not insert any objects in
ports. do not paint the phone with color-all of operations
listed above affect the phone functionality and sealing.
Description of this phone operation may differ from this
Use a forceps to remove the microSIM with the reducing
manual, based on the firmware version of your phone and
adapter to avoid bending it. This way you prevent the
microSIM card slot from damage.
specific terms and conditions of your mobile operator.
EVOLVEO StrongPhone D2 was tested in compliance to
EU radio waves, WiFi and Bluetooth standards. In case you
want to limit the effects of high-frequency energy, limit the
duration of your direct exposition to the electromagnetic
emissions, e.g. by using a Bluetooth hands-free set, or
keep a greater distance between your body and the
cellphone.
Never attempt to repair the phone by yourself, any
disassembly, including removing of outer screws and back
cover, can lead to a damage of the device, which is not
covered by the warranty.
Manufacturers, resellers and vendors hold no
responsibility for any data loss and direct or indirect
damage, related to the use of this phone, no matter how
exactly it is caused.
Repair and maintenance can only be handled at an
authorized service place for EVOLVEO phones (more at
otherwise the phone can be damaged
and warranty couild be void.
www.evolveo.eu),
Hold the on button for at least 2 seconds or more * Charge
the battery, first charge for about half an hour, then
disconnect the charger, reconnect it again and finish the
charging * Check or replace the SIM card
Make sure the volume isn't on minimum * Make sure the
phone isn't in „airplane mode“
Contact your operator
Make sure the auto-turn off feature is turned off * Uninstall
application that causes the issue * Revert to factory settings
(System settings->Data backup and recovery->Restore
factory settings->Reset phone)
Satellite lookup is affected by weather and eventual
obstacles in the way. Therefore, the triangulation can
sometimes take some time. In order to speed up the location
finding process enable the A-GPS feature or download EPO
file (system settings->Access to the current location
(enable)-> Location sources-> GPS satellites (clock) EPO
A-GPS assistance).
Turn on the phone using the ON button and hold button 4
(volume -) for 4 seconds at the same time.
Choose the „Clear eMMC“ option using the button 4
(volume - button) and accept using the „Home“ icon on
the bottom part. Warning, the phone will be reverted to
default factory settings, all passwords will be lost, as well
as installed apps, etc.
Drag the top information bar in
main screen down with your
finger in order to show
information such as WiFi,
Bluetooth, GPS or Data transfer
status, Audio profiles,
Brightness, Phone settings, etc.
You can edit details related to
SIM1 and SIM2 cards
Settings for prefered SIM for:
* Voicecalls
* Videocalls
* Messages
Data transfers
(3G support only for SIM1)
Android OS was designed by Google and therefore it s '
More informations how to operate Android OS
possible to find some of its applications in phone (such
ftp://ftp.evolveo.eu
as Google Gmail, Google Maps and more). Other apps can
ftp://ftp.evolveo.eu/mobile_phone/strongphone-d2/manual/eng
be installed using Google Play, in order to do so it s '
necessary to set up a Google account (Settings-
>Accounts and Sync->Add account.)
g Waterproof (IP67)
g GSM (head)/10 g: max. 0.101 W/kg
g GSM (body)/10 g: max. 0.188 W/kg
g Processor Dual Core 1.3 GHz
g 4.0“ Gorilla Glass IPS display
g Display resolution 854 x 480 pixels
g Operational memory: 512 MB
g
Android OS and firmware)
Internal memor y: 4GB (part is reser ved for
g microSDHC card support
g camera 5.0 Mpix
g Bluetooth, GPS, WiFi
g GSM/EDGE: 850/900/1800/1900 MHz
g WDCMA/UMTS/HSPA: 850/2100 MHz
g Battery 4 500 mAh
installed in factory or the one available at
ftp://ftp.evolveo.eu or ROOT of Android OS
g electromechanical or mechanical damage caused by
inappropriate use (such as broken display, damaged
microUSB power connector or headphones output etc.)
g damage caused by natural events such as fire, water,
static electricity, heigh temperature etc.
g damage caused by unauthorized ser vicing
g intentional damage
g Installation of a different firmware then the original
The symbol of crossed out container on the product, in
the literature or on the wrapping means that in the
European Union all the electric and electronic products,
batteries and accumulators must be placed into the
separate salvage after finishing their lifetime. Do not
throw these products into the unsorted municipal waste
Hereby, the company ABACUS Electric spol. s r.o. declares
that GSM phone EVOLVEO StrongPhone D2
(EAN: 8594161335856) is in compliance with the
requirements of the norms and regulations, relevant for
the given type of device.
The complete text of Declaration of Conformity can be
found on ftp://ftp.evolveo.eu/ce
Copyright © 2014 ABACUS Electric spol. s r.o.
All rights reserved. Design and specification can be
changed without prior notice.
ANDROID SMARTPHONE
DUAL CORE
WATERPROOF
O U T D O O R
ANDROID SMARTPHONE
DUAL CORE
WATERPROOF
O U T D O O R
