FEATURESTECHNICAL SPECS
Thank you for purchasing Erica Synths Pico Series module!
With Pico Series we challenged ourselves – can we make ANY
superior functionality synth module 3HP wide and affordable?
Erica Pico DRUMS module gives you two independent great
sounding drums (samples) with versatile control over several
parameters and extensive collection of drum samples. Chain up
several Pico Drums and get one of the smallest modular drum
setup in the modular world!
2 independent drums (samples)
Memory of 64 samples assignable for each drum
USB interface for user samples upload
Independent control over Pitch, Decay and Level for each drum
Voltage controlled Pitch, Decay, Level and Sample select for
the first drum
Separate triggers for each drum
Audio output of mixed drum sounds
Exclusive switch to select how the two drums interact with
each other when triggered at the same time
12bit resolution, 44kHz sampling frequency
Resolution 12 bit
Sample rate 44 kHz
Power consumption +35mA, -15mA
Module width 3HP
Module depth 35mm
PICO
DRUM
OUT
TR2
TR1
CV IN
DRUM2
DRUM1
IND
EXCL
CTRL
PICO
DRUMS
PICO
DRUM
6 LEDs indicate, the drum selected in
binary code. You can select one of 64
samples for each drum. A module
comes with 64 preinstalled samples,
but you can upload your own samples
via programmer.
Also LEDs indicate LOAD/SAVE slots
for your personalized module
configuration
The inluminated encoder is the main
control for all features. See the
table below for all features
description!
Switch between EXCLUSIVE or
INDEPENDENT modes! This defines, how
the two drums interact with each
other when triggered at the same time
Patch here the CV to control Pitch,
Decay, Volume or Sample select for
the first drum
This is Trigger input for the first drum.
The LED indicates the incoming trigger
Switch between 2 drums TO SELECT
DESIRED SAMPLE AND ADJUST PARAMETERS.
When switching between drums,
settings for not active drums are
saved automatically
This is output for both drums mixed
according to level setting
This is Trigger input for the second
drum. The LED indicates the incoming
trigger
SAMPLE SELECT
If encoder is not lit, this means you are in sample
select mode. Rotate the encoder to select
the sample!
6 LEDs will indicate selected sample in
a binary code.
PITCH ADJUSTMENT
If the encoder is light GREEN, you are in PITCH
adjustment mode. Rotate the encoder to set the
pitch of the drum sample. If you alter the pitch of
the drum, and then wish to return to the original
pitch, rotate the encoder until it flashes red once!
It indicates that you are at the original
pitch setting.
DECAY ADJUSTMENT
If the encoder is light RED, you are in DECAY
adjustment mode. Rotate the encoder to select
desired decay time.
VOLUME ADJUSTMENT
If the encoder is light YELLOW, you are in drum
VOLUME adjustment mode. Rotate the encoder to set
desired drum volume.
If you alter the volume of the drum, and then wish
to return to the original volume setting, rotate the
encoder until it flashes red once! It indicates that
you are at the original volume setting.
