Operation manual
Daikin room air conditioner English
Operation manual
Daikin room air conditioner
CTXM15R2V1B
CTXM15R5V1B
FTXM20R2V1B
FTXM20R5V1B
FTXM25R2V1B
FTXM25R5V1B
FTXM35R2V1B
FTXM35R5V1B
FTXM42R2V1B
FTXM42R5V1B
FTXM50R2V1B
FTXM60R2V1B
FTXM71R2V1B
Table of contents
Operation manual
2
CTXM15+FTXM20~42R5V1B + CTXM15+FTXM20~71R2V1B
Daikin room air conditioner
3P485919-11S – 2020.06
Table of contents
1 About the documentation 2
1.1 About this document.................................................................. 2
2 User safety instructions 2
2.1 General...................................................................................... 2
2.2 Instructions for safe operation ................................................... 3
3 About the system 5
3.1 Indoor unit ................................................................................. 5
3.1.1 Indoor unit display....................................................... 5
3.2 About the user interface ............................................................ 5
3.2.1 Components: User interface ....................................... 5
4 Before operation 5
4.1 To insert the batteries................................................................ 5
4.2 To mount the user interface holder ........................................... 6
4.3 To set the clock ......................................................................... 6
4.4 To set the brightness of the indoor unit display......................... 6
4.5 To turn on the power supply...................................................... 6
5 Operation 6
5.1 Operation range ........................................................................ 6
5.2 Operation mode and temperature setpoint................................ 7
5.2.1 To start/stop operation mode and to set the
temperature................................................................. 7
5.3 Airflow rate ................................................................................ 7
5.3.1 To adjust the airflow rate............................................. 7
5.4 Airflow direction ......................................................................... 7
5.4.1 To adjust vertical airflow direction............................... 8
5.4.2 To adjust horizontal airflow direction........................... 8
5.4.3 To use 3-D airflow direction ........................................ 8
5.5 Comfort airflow and Intelligent eye operation ............................ 8
5.5.1 Comfort airflow operation............................................ 8
5.5.2 Intelligent eye operation.............................................. 8
5.5.3 To start/stop Comfort and Intelligent eye operation.... 8
5.6 Powerful operation .................................................................... 8
5.6.1 To start/stop Powerful operation................................. 8
5.7 Econo and Outdoor unit quiet operation.................................... 9
5.7.1 Econo operation.......................................................... 9
5.7.2 Outdoor unit quiet operation ....................................... 9
5.7.3 To start/stop Econo and Outdoor unit quiet operation 9
5.8 Flash Streamer (air cleaning) operation .................................... 9
5.8.1 To start/stop Flash Streamer (air cleaning) operation. 9
5.9 OFF/ON timer operation............................................................ 9
5.9.1 To start/stop OFF timer operation............................... 9
5.9.2 To start/stop ON timer operation................................. 10
5.9.3 To combine OFF timer and ON timer.......................... 10
5.10 Weekly timer operation.............................................................. 10
5.10.1 To set Weekly timer operation .................................... 10
5.10.2 To copy reservations................................................... 11
5.10.3 To confirm reservations .............................................. 11
5.10.4 To deactivate and reactivate Weekly timer operation . 11
5.10.5 To delete reservations ................................................ 11
5.11 Wireless LAN connection .......................................................... 12
5.11.1 Precautions when using the wireless LAN.................. 12
5.11.2 To install the Daikin Residential Controller
application................................................................... 12
5.11.3 To set the wireless connection.................................... 12
6 Energy saving and optimum operation 13
7 Maintenance and service 14
7.1 Overview: Maintenance and service ......................................... 14
7.2 To clean the indoor unit and user interface ............................... 15
7.3 To clean the front panel............................................................. 15
7.4 To remove the front panel ......................................................... 15
7.5 To clean the air filters ................................................................ 15
7.6 To clean the titanium apatite deodorising filter and the silver
allergen removal air purifying filter ............................................. 16
7.7 To replace the titanium apatite deodorising filter and the silver
allergen removal air purifying filter ............................................. 16
7.8 To re-install the front panel......................................................... 16
8 Troubleshooting 16
9 Disposal 17
1 About the documentation
1.1 About this document
Thank you for purchasing this product. Please:
▪ Keep the documentation for future reference.
Target audience
Endusers
INFORMATION
This appliance is intended to be used by expert or trained
users in shops, in light industry, and on farms, or for
commercial and household use by lay persons.
Documentation set
This document is part of a documentation set. The complete set
consists of:
▪General safety precautions:
▪ Safety instructions that you must read before operating your
system
▪ Format: Paper (in the box of the indoor unit)
▪Operation manual:
▪ Quick guide for basic usage
▪ Format: Paper (in the box of the indoor unit)
▪User reference guide:
▪ Detailed step-by-step instructions and background information
for basic and advanced usage
▪ Format: Digital files on http://www.daikineurope.com/support-
and-manuals/product-information/
Latest revisions of the supplied documentation may be available on
the regional Daikin website or via your installer.
The original documentation is written in English. All other languages
are translations.
2 User safety instructions
Always observe the following safety instructions and regulations.
2.1 General
WARNING
If you are NOT sure how to operate the
unit, contact your installer.
WARNING
This appliance is not intended for use
by persons, including children, with
reduced physical, sensory or mental
2 User safety instructions
Operation manual
3
CTXM15+FTXM20~42R5V1B + CTXM15+FTXM20~71R2V1B
Daikin room air conditioner
3P485919-11S – 2020.06
capabilities, or lack of experience and
knowledge, unless they have been
given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to
ensure that they do not play with the
appliance.
Cleaning and user maintenance must
not be carried out by children without
supervision.
WARNING
To prevent electrical shocks or fire:
▪ Do NOT rinse the unit.
▪ Do NOT operate the unit with wet
hands.
▪ Do NOT place any objects containing
water on the unit.
CAUTION
▪ Do NOT place any objects or
equipment on top of the unit.
▪ Do NOT sit, climb or stand on the
unit.
▪ Units are marked with the following symbol:
This means that electrical and electronic products may NOT be
mixed with unsorted household waste. Do NOT try to dismantle
the system yourself: the dismantling of the system, treatment of
the refrigerant, of oil and of other parts must be done by an
authorized installer and must comply with applicable legislation.
Units must be treated at a specialized treatment facility for reuse,
recycling and recovery. By ensuring this product is disposed of
correctly, you will help to prevent potential negative consequences
for the environment and human health. For more information,
contact your installer or local authority.
▪ Batteries are marked with the following symbol:
This means that the batteries may NOT be mixed with unsorted
household waste. If a chemical symbol is printed beneath the
symbol, this chemical symbol means that the battery contains a
heavy metal above a certain concentration.
Possible chemical symbols are: Pb: lead (>0.004%).
Waste batteries must be treated at a specialized treatment facility
for reuse. By ensuring waste batteries are disposed of correctly,
you will help to prevent potential negative consequences for the
environment and human health.
2.2 Instructions for safe operation
WARNING: MILDLY FLAMMABLE
MATERIAL
The refrigerant inside this unit is mildly
flammable.
CAUTION
The indoor unit contains radio
equipment, minimum separation
distance between the radiating part of
the equipment and the user is 10 cm.
CAUTION
Do NOT insert fingers, rods or other
objects into the air inlet or outlet. When
the fan is rotating at high speed, it will
cause injury.
WARNING
▪ Do NOT modify, disassemble,
remove, reinstall or repair the unit
yourself as incorrect dismantling or
installation may cause an electric
shock or fire. Contact your dealer.
▪ In case of accidental refrigerant
leaks, make sure there are no naked
flames. The refrigerant itself is
entirely safe, non-toxic and mildly
flammable, but it will generate toxic
gas when it accidentally leaks into a
room where combustible air from fan
heaters, gas cookers, etc. is present.
Always have qualified service
personnel confirm that the point of
leakage has been repaired or
corrected before resuming operation.
CAUTION
ALWAYS use a user interface to adjust
the position of the flaps and louvers.
When the flaps and louvers are
swinging and you move them forcibly
by hand, the mechanism will break.
CAUTION
NEVER expose little children, plants or
animals directly to the airflow.
