CTA Digital - Innovative Accessories

Product Name: Wireless Bluetooth Controller for iPad®, iPhone® and Android Devices

Product Model: PAD-BTC

Thank you for choosing CTA Digital's product. We hope that you will enjoy using it.

Please follow the guidelines and instructions as laid out in this instruction manual.

Introduction

The Wireless Bluetooth Controller is a compact gamepad for mobile gaming that supports

various iOS and Android games.

• Wirelessly connects with Bluetooth enabled mobile devices without any drivers or extra software

• Powered by a rechargeable Lithium-ion battery that provides sustainable, safe and stable long-term use

• Retractable grip can securely hold smartphones up to 2.75 inches wide for integrated use

• Bluetooth 3.0 wireless connection with 6-8 meter transmission range

• Automatically switches oﬀ to save power when not in use.

• Compatible with iPhone, iPod Touch, iPad and most Android smartphones and tablets

Compatibility Notes:

Note: Compatible with Android 2.3+ Bluetooth enabled smartphones and tablets. Certain compatibility

issues may exist with some Android 4.0+ platforms and apps. Not compatible with ALL iOS or Android apps.

Recommended for many iOS iCade style games, racing, platform, shooter and tower defense style games

and classic game emulators.

Setup Instructions:

iOS iCade Mode: This mode is only compatible with the iOS system and supports many

iPhone and iPad games, such as Helium Boy, League of Evil 2, Muﬃn Knight Free, Stardash,

Temple Run.

Steps:

1. First press and hold the "Y" button, then press the "HOME" button until the Bluetooth

LED lights ash;

2. Go to Settings General click on the device name (as shown in Figure a2)> > > Bluetooth

No password necessary. When the LED light stays lit, then the controller is connected.

Android Mouse Mode: This mode supports many touch and tower defense games for

Android, such as Angry Birds, Fruit Ninja, Airbag Frank 3D Plants vs. Zombies, Gunsn Glory.

Steps:

1. First press and hold the "B" button, then press the "HOME" button until the Bluetooth

LED light ashes;

2. Go to Settings > Bluetooth > Scan > click on the device name (as shown in Figure b2)

 No password necessary. When the LED light stays lit, then the controller is connected.

Android Keyboard Mode: This mode supports many simulator and emulator games for

Android, such as FC simulator, GBA emulator, arcade emulator, SFC simulator, N64 emulator.

Steps:

1.First press and hold the "A" button, then press the "HOME" button until the Bluetooth

LED lights ash

2.Go to Settings > Bluetooth > Scan > click on the device name (as shown in Figure c2)

No password necessary. When the LED light stays lit, then the controller is connected.

Android Joystick Mode: This mode supports many role play and racing games for Android,

such as Shadowgun, Sonic CD, Cordy Zenonia4, 9 Innings 2013, Soulcraft.

Steps:

1.First press and hold the "A" button, then press the "HOME" button until the Bluetooth

LED lights ash

2.Go to Settings > Bluetooth > Scan > click on the device name (as shown in Figure c2)

No password necessary. When the LED light stays lit, then the controller is connected.

Charging controller: Use the included USB cable to connect the controller to a 5V power supply for charging (PC device or power adapter). While charging, the LED charge

indicator will be on and will turn oﬀ once fully charged.

Powering ON/OFF: Press the "HOME" button for about 5 seconds until the LED light is oﬀ. The controller is now turned oﬀ. To turn ON and reconnect with a paired device press

the "HOME" button for about ve seconds, until the LED light ashes slowly and then stays lit. The controller is now ON and connected with the last paired device. When the

connection is inactive the controller will automatically turn oﬀ after about 10 minutes.



Note: To change the controller function mode, rst turn oﬀ the controller, and then reset to the desired controller mode follwoing the setup instructions above.

Attention

1. Please do not store this product in wet or hot areas.
