Intended use
The Rhinestone Applicator is intended exclusively for use in dry interior
areas. The Rhinestone Applicator is an electric heating tool for fixing
rhinestones onto paper, textile, suede, leather, wood, cork and other
materials by means of heated metal tips. The Rhinestone Applicator is
suitable for thermo-glue-coated rhinestones rivets, halves of pearls and
shaped stones. These stones and pearls are provided with a thermo
glue coat on the back side. The glue starts to liquefy already from
approximately 120°C and hence makes the connection between the
material and the stone possible. Any other use is not permitted. Such
use can lead to injuries (burns) of the user and damages of the material.
In these cases, the manufacturer carries no liability. This device is only
intended for use in private households. Never use the device for
commercial purposes.
Safety instructions
 CAUTION! When not in use, this Rhinestone Applicator must be placed
on the security stand (picture VIII).
 When the device is placed on the stand, the surface underneath must
be firm, not flammable and horizontal.
 This appliance is not intended for use by persons (including children)
with restricted physical, sensory or intellectual abilities or lacking
experience and/or lacking knowledge unless they are supervised by
a person responsible for their safety or they receive instructions on
how to use the appliance.
 Children should be supervised in order to ensure that they do not play
with the appliance.
 In order to avoid hazards, if the mains connection of this appliance is
damaged, it must be replaced by the manufacturer or his customer
service or a similarly qualified person.
 A fire can break out if the appliance is not handled carefully.
 Ensure that the connecting cable does not come into contact with
heat, oil or sharp edges. Damaged connecting cables can cause fires,
short-circuits and electric shocks.
 Before use, remove combustible objects, liquids and gases from the
working area of the appliance. Keep your working area clean in order
to prevent accidents.
 Before use, check that the tool tip is correctly attached to the appliance.
The hot tips and their receptacles must not be brought into contact
with skin, hair, etc. Risk of burns.
 After use, place the Rhinestone Applicator on the stand and allow it
to cool down before packing it away.
 As long as it is in use, do not leave the appliance unsupervised.
 Do not emerge the appliance into water and do not expose it to
moisture. Risk of electric shock!
 When the appliance is not in use, store it in a safe place protected
from dust and moisture.
 Check the appliance for damage. Do not use if damaged!
 During use, ensure adequate ventilation. Ensure that no poisonous
gases or vapours can be inhaled. Wear protective clothing (e.g. long
sleeved clothing, protective goggles).
 For longer work interruptions, disconnect the appliance from the voltage
source.
Avoid use of the appliance on all plastic or synthetic material surfaces.
NOT SUITABLE for surfaces of electronic devices, such as e.g. mobile
phones, as the setter reaches a high temperature and may melt the
material and/or the surfaces.
 Do not decorate clothes of small children with rhinestones (small parts
could get swallowed).
 After fixing the rhinestones wash your hands carefully.
 Observe national and international safety, health and work protection
regulations.
Preparation
Please take your time and read the operating instructions carefully
before putting the appliance into operation and keep the operating
instructions for future reference.
It is not allowed to change settings or make modifications from those
set by the manufacturer. It could be dangerous to change the structure
of the device on your own authority, to remove parts or to use parts
which are not approved by the manufacturer. (If you change the structure
of the device on your own authority you risk e.g. an electric shock, a
short circuit and burns.)
Scope of delivery
1 Operating Instructions
1 Rhinestone Applicator
8 tip-piece-kit for various stone sizes and forms (tool tips)
1 security stand
2 x 200 rhinestones
Please check the goods for completeness
Instructions for Use
No. 48450
Rhinestone Applicator Kit
IAN 89584
EN
Explanation of the pictures
Rhinestone Applicator
flat tip approximately Ø 5 mm (suitable for all stones smaller than
ø 5 mm).
flat tip approximately Ø 9,5 mm (suitable for all stones bigger than
ø 5 mm and smaller than ø 9,5 mm).
concave tip approximately Ø 7 mm (tip with marking 34. Suitable
for stones from ø 5 mm to ø 7 mm).
concave tip approximately Ø 5 mm (tip with marking 20. Suitable
for stones from ø 4 mm to ø 5 mm).
concave tip approximately Ø 4 mm (tip with marking 16. Suitable
for stones from ø 3 mm to ø 4 mm).
concave tip approximately Ø 3 mm (tip with marking 10.Suitable
for stones from ø 2 mm to ø 3 mm).
concave tip approximately Ø 2 mm (tip with marking 8. Suitable
for stones smaller than ø 2 mm).
mini iron-shaped tip (suitable for all stones with a big surface 
maximum ø 14 mm).
security stand (for safe putting down of the hot Rhinestone Applicator).
Explanation of the symbols
Do touch the tip of the tool! The tip is very hot! Risk of burns!not
Do emerge the appliance into water and do not expose it tonot
moisture. Risk of electric shock!
The temperature on tool tip is very high during operation! Risk
of burns!
Do screw on the tip with force!not
Put away the appliance correctly on the stand, if the tip is hot
and the applicator is not in use (picture VIII).
Important information before start up
 Read the security instructions before putting the applicator into
operation!
 Before starting up unpack the Rhinestone Applicator Kit completely
and check the contents.
 In the delivery the flat tip ø 9,5 mm is fitted. You must screw this tip
off first, before you start working with another tip.
CY
IE
Löt- und Gasgeräte GmbH
Bahnhofstraße 50, D-74254 Offenau
Tel. +49 7136 9594-0
Fax +49 7136 9594-44
Internet: www.cfh-gmbh.de
E-Mail: info@cfh-gmbh.de
Stand: VO-07.13
 To fix stones provided in the delivery, we recommend the use of the
concave tip with marking 16 on it.
 Before you start work, try the appliance and fix a rhinestone on a
unnoticeable place on the material (e.g. on the inner side of the material.
Through this test application you avoid a damage of the material on
a noticeable area).
 The workmanship can be improved if the tip warms up only the stone
and does not come into contact with the glue.
 The correct application of a stone on the material is guaranteed only
if the cut side of the stone is pointing up (picture IV).
 Do not adjust the stone with the glue coated side pointing up (picture
V), otherwise the stone and the tip will stick together.
Start up
 Screw the suitable tool tip onto the Rhinestone Applicator. Do not screw
on the tip with force!
 Now place the Rhinestone Applicator onto the security stand (see 
picture VIII.).
 Plug in the appliance.
 Let the appliance preheat for 5 minutes till the optimal working
temperature is reached. (The temperature of the tip depends on the
size of the tip.)
 Now place the rhinestone with the cut side pointing up onto the intended
spot of the material (e.g. a leather belt). The side of the rhinestone
coated with glue is placed on the material.
 Now place the Rhinestone Applicator with its preheated tip on the top
of the stone carefully and press it lightly. Within seconds the glue will
liquefy and the stone will be stuck to the material.
 To connect a rhinestone to the material you will need approximately
3 - 15 seconds. (This time is necessary for liquefying of the glue and
thus for a successful connection of the stone and material. The length
of the application depends on the size and make of the rhinestones).
Afterwards it is possible to apply the next rhinestone.
 Repeat this procedure until the desired motive is completed.
 Should a rhinestone get blocked in the tip during the application, remove
it with a pair of tweezers. (See picture VI  use a pair of tweezers to
avoid getting burned on the hot tip). Only afterwards a new stone can
be applied.
 In case you need to change the tip when it is still hot, use a tool (e.g.
a pair of tweezers) to avoid getting burned (see picture III).
Shut down
Place the Rhinestone Applicator on the security stand, as shown on
picture VIII. (Improper handling can cause burns and a fire can start.)
Now disconnect the appliance from the voltage supply source (unplug
it). Let the Rhinestone Applicator cool down completely. As long as it
has not completely cooled down, do not leave the appliance unsupervised.
(The cooling down time depends on the tip in use. You will need e.g.
appx 20 minutes till the tip with marking 16 cools down after use down
to 25°C. The ambient temperature also has an influence on the cooling
down time. A general rule is that the higher the ambient temperature is,
the longer the cool down takes.
When the completely cooled down appliance is not in use, store it in a
safe place protected from dust and moisture.
Cleaning and maintenance
Only clean the Rhinestone Applicator with a dry cloth when it has cooled
down. Only clean the surface of the tool tip with a dry cloth or a cleaning
fleece (e.g. CFH No. 52349) when it has cooled down. A cleaning fleece
is available in many building stores and can be obtained there. The
Rhinestone Applicator is maintenance-free.
Warranty
You are granted a 2-year warranty for this device as of the date of
purchase. The warranty period starts on the date of purchase. Please
keep the original sales receipt for further reference. The receipt will be
required as a proof of purchase. If a material or manufacturing fault
appears within 2 years as of the date of purchase of this product, CFH
will, at its discretion, repair or replace this product free of charge. This
warranty will only be granted provided the defective device and the
purchase of evidence (sales receipt) is presented within 2 years as well
as a short written description stating the character of the defect and time
when it appeared. After the defect has been resolved through our
warranty, you will get the repaired or the new product back. In case of
a warranty claim, please contact us by e-mail under info@cfh-gmbh.de.
We will get in touch with you immediately.
Disposal
The crossed through dustbin on this product indicates that at the end
of its service life the appliance has to be disposed of separately and not
together with household waste. In future, please bring the Rhinestone
Applicator to the established municipal collecting points in your local
community.
For disposal information and location of the nearest recycling park please
contact Office for Municipal Sanitation or see Yellow Pages.
Technical Data
Power requirement: 230 V ~ 50 Hz
Output: 6 W
Max. working temperature: approx. 260 °C (depending on the tool tip)
Subject to technical and optical changes.
Service Address & Manufacturer:

Specyfikacje produktu

Marka: Crelando
Kategoria: Niesklasyfikowane
Model: IAN 89584

Potrzebujesz pomocy?

Jeśli potrzebujesz pomocy z Crelando IAN 89584, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą


Instrukcje Niesklasyfikowane Crelando

Crelando

Crelando IAN 368017 Instrukcja

1 Października 2024
Crelando

Crelando IAN 115769 Instrukcja

1 Października 2024
Crelando

Crelando IAN 73860 Instrukcja

1 Października 2024
Crelando

Crelando IAN 107904 Instrukcja

1 Października 2024
Crelando

Crelando HG05278A Instrukcja

1 Października 2024
Crelando

Crelando IAN 367544 Instrukcja

1 Października 2024
Crelando

Crelando IAN 275590 Instrukcja

1 Października 2024
Crelando

Crelando IAN 317077 Instrukcja

1 Października 2024
Crelando

Crelando IAN 275317 Instrukcja

1 Października 2024
Crelando

Crelando IAN 110416 Instrukcja

1 Października 2024

Instrukcje Niesklasyfikowane

Najnowsze instrukcje dla Niesklasyfikowane

Black Diamond

Black Diamond BD1121530000ALL1 Instrukcja

15 Października 2024
Husqvarna

Husqvarna K 970 SmartGuard Instrukcja

15 Października 2024
Stihl

Stihl HT 70 Instrukcja

15 Października 2024
Ernesto

Ernesto H14270 Instrukcja

15 Października 2024
Uniden

Uniden BT MIC KIT Instrukcja

15 Października 2024
Vaude

Vaude Omnis Bike 26 Instrukcja

15 Października 2024
ART

ART ProChannel II Instrukcja

15 Października 2024
Aukey

Aukey DR02J Instrukcja

15 Października 2024
Master Lock

Master Lock 653EURD Instrukcja

15 Października 2024
Roland

Roland FR-18 Diatonic Instrukcja

15 Października 2024
